nüvi

2300 series

quick start manual

for use with these nüvi models:

2300, 2310, 2340, 2350, 2360, 2370

2 nüvi2300SeriesQuickStartManual

Getting Started



WARNING

See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

When using your device for the rst

time, complete the following tasks.

1. Mount the device (page 2).

2. Connect the device to vehicle

power (page 3).

3. Register the device (page 5).

4. Check for updates.

• Software updates (page 5).

• Free map update (page 5).

5. Download the full owner’s manual

(page 5).

Mounting Your Device

Notice

Before mounting the device, see

the Important Safety and Product

Information guide for information

about laws pertaining to windshield

mounting.

1. Remove the clear plastic from the

suction cup.

2. Clean and dry your windshield

and the suction cup with a lint-free

cloth.

3. Press the suction cup to the

windshield.

4. While pressing, ip the lever back

toward the windshield.

5. Snap the mount

➊

onto the

suction cup arm

➋

nüvi2300SeriesQuickStartManual 3

➊➋

6. Fit the bottom of your device into

the mount.

7. Tilt your device back until it

snaps into place.

Connecting the Device

to Vehicle Power



WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to

extreme heat, remove the device from

the vehicle when exiting or store it

out of direct sunlight.

Charge your device before using it on

battery power.

1. Plug the vehicle power cable into

the mini-USB connector

➊

on the

mount.

➊

2. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

4 nüvi2300SeriesQuickStartManual

3. If you are using a trafc receiver

in Europe, connect the external

antenna to the trafc receiver and

secure it to the windshield using

the suction cups.

After the device has been connected

to vehicle power, the following

occurs.

• The device turns on.

• The device acquires satellite

signals. When at least one of

the bars is green, your

device has acquired satellite

signals.

NOTE: The device may need

a clear view of the sky to

acquire satellite signals.

• The device charges as you

drive. in the status bar

indicates the status of the

internal battery.

About myDashboard

Use myDashboard to register your

device, check for software and map

updates, access product manuals and

support, and more.

Setting Up myDashboard

1. Connect the USB cable to the

micro-USB connector on the

device.

2. Connect the USB cable to the

USB port on your computer.

3. Double-click to open the

myDashboard Web page.

NOTE: If does not appear, or

you are using Windows® 7 or a

Mac® computer, go to www

.garmin.com/dashboard.

4. Follow the on-screen instructions.

nüvi2300SeriesQuickStartManual 5

Registering the Device

1. From myDashboard, click

2. Follow on-screen instructions.

3. Keep the original sales receipt, or

a photocopy, in a safe place.

Updating the Software

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Under Software Updates, click

Update Now.

4. Follow the on-screen instructions.

nüMaps Guarantee™

Your device is eligible for one

free map update within 60 days of

acquiring satellites while driving with

your nüvi. You are not eligible for

the free map update if you register

by phone or wait longer than 60

days after the rst time you acquire

satellites while driving with your

nüvi. For more information, go to

www.garmin.com/numaps.

Updating Maps

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Under Map Updates, click Update

Now.

4. Follow the on-screen instructions.

Downloading the Owner’s

Manual

The owner’s manual for your device

is available on the Garmin Web site.

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Click Manuals.

A list of the product manuals in

several languages appears.

4. Click Download next to the

manual you want.

5. Click to save the le to your

computer.

6 nüvi2300SeriesQuickStartManual

Device Overview

➊

➋

➊

Power key

➋

microSD

™

card slot

Using the Power Key

Press and quickly release the

Power key to view additional

options.

• Touch and drag the scroll bar

to adjust screen brightness.

• Touch Lock to prevent

accidental screen touches (nüvi

2360 only).

• Touch Power Off to turn off

your device.

• Press and hold the Power key

to reset the device.

• Press and quickly release the

Power key to exit the menu.

About Points of Interest

The detailed maps loaded in your

device contain points of interest,

such as restaurants, hotels, and auto

services.

Finding a Point of Interest by

Category

1. From the Main menu, touch

Where To? > Points of Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select a destination.

5. Touch Go!.

nüvi2300SeriesQuickStartManual 7

You can touch > Save on

this page to save the location to

a Favorites folder on the device.

Use the Favorites folder to save

the location of your workplace,

home, and other common

destinations.

6. If necessary, select an option.

• Touch Drive to calculate a

route you will navigate by

driving.

• Touch Walk to calculate a

route you will navigate by

walking.

• Touch Public Transit to

calculate a route that combines

public transit and walking.

NOTE: You must have

cityXplorer™ maps loaded to

navigate using public transit.

Go to www.garmin.com to

purchase cityXplorer maps.

Using the Main Menu

➊

➋ ➌

➍ ➐ ➑➎ ➏

• Touch

➊

to select a transportation

mode.

• Touch

➋

to nd a destination.

• Touch

➌

to view the map.

• Touch

➍

to stop a route.

• Touch

➎

to detour a route.

• On some models, touch

➏

make a call when connected to a

compatible mobile phone.

See www.garmin.com/bluetooth

for information.

• Touch

➐

to adjust the volume.

• Touch

➑

to open the menu of

tools and settings.

8 nüvi2300SeriesQuickStartManual

Your Route on the Map

Notice

The speed limit icon feature is for

information only and does not replace

the driver’s responsibility to abide

by all posted speed limit signs and to

use safe driving judgment at all times.

Garmin will not be responsible for

any trafc nes or citations that you

may receive for failing to follow all

applicable trafc laws and signs.

➊ ➋

➌

➍ ➎

➏➐

➑➒

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

• Touch

➊

to view the next turn. If

a view of the junctions exists, the

junction view appears.

• Touch

➋

to view the turn list.

• Touch

➌

to zoom in and out.

• Touch

➍

to return to the Main

menu.

Touch and hold from any screen to

return to the Main menu.

• Touch

➎

to change the data eld.

• Touch

➏

to view the Where Am

I? page.

• Touch and drag

➐

to view a

different area of the map.

• Touch

➑

to view the trip

computer.

• Touch

➒

to change the speed limit

if the speed limit icon shown on

the map is incorrect.

nüvi2300SeriesQuickStartManual 9

Using myTrends

As you drive with the device on,

myTrends™ gathers information that

allows the device to predict when

you are traveling to a common

destination, like your workplace or

home. When myTrends is activated,

the destination and estimated time of

travel will appear in the navigation

bar on the map.

myTrends only works for locations

that are saved as Favorites (page 7).

When myTrends information

appears in the navigation bar,

touch the navigation bar to view

route information.

About the Transportation

Modes

Automobile mode

Pedestrian mode

Routes are calculated differently

based on your transportation mode.

For example, in Automobile mode,

estimated time of arrival is calculated

using the speed limit of the roads on

the route. Pedestrian mode calculates

time of arrival based on walking

speed.

Changing Your Transportation

Mode

1. From the Main menu, touch the

transportation mode icon.

2. Select a mode.

3. Touch Save.

10 nüvi2300SeriesQuickStartManual

About Trafc

Notice

Garmin is not responsible for the

accuracy or timeliness of the trafc

information.

Some models can receive FM

Trafc Message Channel (TMC)

trafc content. The FM TMC trafc

subscription is automatically enabled

and does not require an addition

subscription purchase to activate. The

FM TMC trafc receiver is integrated

in the vehicle power cable included

in the box.

For information about trafc receivers

and coverage areas, go to www

.garmin.com/trafc.

Manually Avoiding Trafc on

Your Route

1. From the map, touch .

2. Touch Trafc On Route.

3. If necessary, touch the arrows to

view other trafc delays on your

route.

4. Touch Avoid.

Viewing the Trafc Map

The trafc map shows color-coded

trafc ow and delays on nearby

roads.

1. From the map, touch .

2. Touch Trafc Map to view the

trafc incidents on a map.

Altri manuali per NUVI 2300 series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Garmin GPS

Garmin

Garmin TREAD XL BAJA CHASE EDITION Manuale utente

Garmin

Garmin GPS 150 Manuale

Garmin

Garmin AQUAMAP 80 Series Manuale utente

Garmin

Garmin Gpsmap 430 - marine gps receiver Manuale

Garmin

Garmin StreetPilot C580 - Automotive GPS Receiver Manuale utente

Garmin

Garmin 796 Manuale utente

Garmin

Garmin eTrex Vista Manuale utente

Garmin

Garmin BMW Motorcycles Navigator Manuale utente

Garmin

Garmin GPS II+ Manuale utente

Garmin

Garmin quatix Manuale utente

Garmin

Garmin Oregon 600 Manuale utente

Garmin

Garmin fleet 590 Guida di riferimento

Garmin

Garmin RUNNING DYNAMICS POD Manuale utente

Garmin

Garmin Nuvi 600 Manuale utente

Garmin

Garmin TREAD Manuale utente

Garmin

Garmin Montana 700 Series Manuale utente

Garmin

Garmin iQUE 3600 Manuale utente

Garmin

Garmin Fishfinder 80 Specifiche tecniche

Garmin

Garmin GPS 155XL Manuale utente

Garmin

Garmin GPSMAP 276C Manuale utente

Garmin

Garmin GDL 88 Manuale utente

Garmin

Garmin DRIVE 51 Manuale utente

Garmin

Garmin StreetPilot GPS Manuale utente

Garmin

Garmin Forerunner 305 - Running GPS Receiver Manuale utente

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente

Kenwood

Kenwood DNN9330BT Manuale utente

Safelet

Safelet Indra Manuale utente

Bushnell

Bushnell 360100 Manuale utente

Geneq

Geneq SXBlue Manuale utente

ORIGO

ORIGO ED308 Manuale utente
