Gateway EC54/EC58

SERVICEGUIDE

Revision History

Please refer to the table below for the updates made on the Gateway EC58 service guide.

transmitted, transcribed, stored in a retral system, or translated into any language or computer language, in any form

or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written

permission of Gateway Incorporated.

PRINTED IN TAIWAN

Date Chapter Updates

CHAPTER

System Specifications

•

Preface

•

Features

•

System Block Diagram

•

Board Layout

•

Notebook Product Tour

•

Hardware Specifications and Configurations

CHAPTER 1: System Specifications

Preface

Conventions

The following conventions are used in this manual:

General Information

Before using this information and the product it supports, please read the

following general information.

1This Service Guide provides you with all technical information relating

to the BASIC CONFIGURATION decided for Gateway’s “global” product

offering. To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the

functionality of a machine (e.g. add-on card, modem, or extra memory

capability). These LOCALIZED FEATURES will NOT be covered in this

generic service guide. In such cases, please contact your regional offices

or the responsible personnel/channel to provide you with further

technical details.

2Please note WHEN ORDERING FRU PARTS, that you should check the

most up-to-date information available on your regional web or channel.

If, for whatever reason, a part number change is made, it will not be

noted in this printed Service Guide. For GATEWAY-AUTHORIZED

SERVICE PROVIDERS, your Gateway office may have a DIFFERENT part

number code to those given in the FRU list of this printed Service Guide.

You MUST use the list provided by your regional Gateway office to order

FRU parts for repair and service of customer machines.

Warning

Alerts you to any damage that might result from doing or not doing

specific actions.

Caution

Gives precautionary measures to avoid possible hardware or software

problems.

Important

Reminds you to do specific actions relevant to the accomplishment of

procedures.

Note

Gives bits and pieces of additional information related to the current

topic.

www.gateway.com

Features

Below is a brief summary of the computer’s many factures:

EC58 Specifications

Operating System1

•Genuine Windows®7 Home Premium 64-bit2

Platform1

•Intel®Centrino®2 processor technology, featuring:

•Intel®Core™ 2 Duo processor SU7300/SU9400 (3MB L2 cache,

1.20/1.40 GHz, 800 MHz FSB, 10 W),supporting Intel®64 architecture

•Mobile Intel®GS45 Express Chipset

•Intel®Wireless WiFi Link 5100 802.11a/b/g/Draft-N Wi-FiCERTIFIED™

network connection, featuring MIMOtechnology3

System Memory1, 4, 5

•Dual-Channel DDR3 SDRAM support

•Up to 4 GB of DDR3 1066 MHz memory, upgradeable to 8 GB using

two SO-DIMM modules

Display

•15.6"HD 1366 x 768 pixel resolution, high-brightness (200-nit)

Gateway Ultrabright™ LED-backlit TFT LCD

•16:9 aspect ratio

CHAPTER 1: System Specifications

Graphics1

•ATI Mobility Radeon™ HD 43306with up to 23047MB of

HyperMemory™ (512 MB of dedicated DDR3 VRAM, up to 1792 MB of

shared system memory), supporting Unified Video Decoder (UVD),

OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.1,

Microsoft®DirectX®10.1

•Mobile Intel®GS45 Express Chipset with integrated 3D graphics8,

featuring Intel®Graphics Media Accelerator 4500MHD (Intel®GMA 4500

MHD) with up to 1659 MB of Intel®Dynamic Video Memory Technology

5.0 (64 MB of dedicated video memory, up to 1631 MB of shared system

memory), supporting Microsoft®DirectX®10

•Dual independent display support 16.7 million colors

•External resolution/refresh rate:

•2048 x 1536: 75/60 Hz

•1920 x 1440: 85/75/60 Hz

•1920 x 1200: 75/60 Hz

•1920 x 1080: 100/85/75/60 Hz

•1680 x 945: 100/85/75/60 Hz

•1600 x 1200: 120/100/85/75/60 Hz

•1600 x 900: 120/100/85/75/60 Hz

•1400 x 1050: 85/75/60 Hz

•1366 x 768: 85/75/60 Hz

•1280 x 1024: 120/100/85/75/60 Hz

•1280 x 768: 85/75/60 Hz

•1280 x 720: 100/85/75/60 Hz

•1024 x 768: 120/100/85/75/60 Hz

•800 x 600: 120/100/85/72/60 Hz

•640 x 480: 120/100/85/75/60 Hz

•MPEG-2/DVD decoding

•WMV9 (VC-1) and H.264 (AVC) decoding

•HDMI™(High-Definition Multimedia Interface) with HDCP

(High-bandwidth Digital Content Protection) support

Audio

•Optimized 2nd Generation Dolby Sound Room®9 audio enhancement,

featuring Dolby® Headphone, Dolby®Natural Bass and Dolby®Sound

Space Expander

•Two built-in stereo speakers

•High-definition audio support

•S/PDIF (Sony/Philips Digital Interface)10 support for digital speakers

•Built-in microphone

•MS-Sound compatible

Storage

•160/250/320/500 GB or larger hard disk drive1.11

•Multi-in-1 card reader, supporting Secure Digital™(SD) Card,

MultiMediaCard (MMC), Memory Stick™(MS), Memory Stick

PRO™(MS PRO), xD-Picture Card™(xD)

www.gateway.com

Communication

•Video Conference1, featuring:

•Integrated high-def video webcam, featuring 1280 x 800 resolution

image capture

•WLAN1.3: Intel®Wireless WiFi Link 5100 802.11a/b/g/Draft-N Wi-Fi

CERTIFIED™network connection, featuring MIMO technology

•WPAN1: Bluetooth®2.1+EDR (Enhanced Data Rate)

•WWAN1.3.12: UMTS/HSPA at 850/900/1900/2100 MHz and quad-band

GSM/GPRS/EDGE (850/900/1800/1900 MHz) upgradeable to 7.2 Mb/s

HSDPA and 5.7 Mb/s HSUPA supporting receiver diversity and equalizing

at 2100 MHz (for 3G models)

•LAN: Gigabit Ethernet, Wake-on-LAN ready

Privacy Control

•BIOS user, supervisor passwords

•Kensington lock slot

Dimensions and Weight1

•377.1 (W) x 254 (D) x 25.7 (H) mm (14.85 x 10 x 1.08/1.01 inches)

•2.4 kg (5.29 lbs.) with 6-cell battery pack

Power1

•ACPI 3.0 CPU power management standard: supports Standby and

Hibernation power-saving modes

•63W 5600mAh 6-cell Li-ion battery pack:

•8-hour battery life13

•3-pin 65W AC adapter

•ENERGY STAR®

Special Keys and Controls

•103/104/107-key keyboard

•12 function keys, four cursor keys, Windows®key, international

language support, independent US dollar and Euro symbol keys

•Multi-gesture touchpad, supporting two-finger scroll, pinch,

•rotate, flip

•Capacitive-touch launch keys: Gateway PowerSave and MyBackup,

Communication®, touchpad lock

CHAPTER 1: System Specifications

I/O Ports1

•Multi-in-1 card reader

•Three USB 2.0 ports

•HDMI™port with HDCP support

•External display (VGA) port

•Headphone/speaker/line-out jack with one jack supporting S/PDIF

•Microphone-in jack

•Ethernet (RJ-45) port

•DC-in jack for AC adapter

Software14

•Gateway 3G Connection Manager

•Gateway Launch Manager

•Gateway MyBackup

•Gateway PowerSave Solution

•Gateway Recovery Management

•Adobe®Reader®

•Adobe®Flash®Player

•CyberLink®PowerDVD™

•CyberLink®Power2Go™

•Google Toolbar™

•Google™Setup

•Microsoft®Works with Office Home and Student 2007 Trial

•Norton™Online Backup

•Norton Internet Security™2009 Trial (60 days)

•Oberon GameZone

•Wild Tangent

Optional Items1

•1 GB / 2 GB DDR3 1066MHz soDIMM module

•6-cell Li-ion battery pack

•Gateway PowerSave 3-pin 65W AC adapter

•External USB floppy disk drive

•External USB 56K modem

Windows Vista®Life without Walls™Gateway recommends Windows 7.

1Specifications vary depending on model.

264-bit software is required to enjoy the advantages of 64-bit processing.

3Actual throughput may vary depending on network conditions and

environmental factors such as network traffic or overhead, building

construction and access point settings.

4All available system memory may be allocated for system resource

requirements.

5Shared system memory may be allocated to support integrated graphics,

depending on system memory size and other factors. Actual system

memory available to the operating system will be reduced by the

amount of dedicated and shared system memory utilized by the graphics

solution and resources required by the operating environment.

www.gateway.com

6For models with discrete graphics.

7For systems with 4 GB of system memory. The total graphics memory

visible to the OS is less than the actual size allocated from the physical

memory installed and varies depending on the configuration under a

32-bit OS.

8For models with integrated graphics.

9Dolby®is a registered trademark of Dolby®Laboratories.

10 Supports 7.1-channel surround sound and 2-channel stereo output

(multiple streaming).

11 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary

depending on preloaded materials and operating environment.

12 Manufacturing option, with the Gobi2000 module.

13 Battery life varies depending on product specifications, computer

settings, and applications or features launched. All batteries' maximum

capacity diminishes with time and use.

14 Bundled software may vary depending on hardware configuration, OS,

and regional availability.

In a continuing effort to improve the quality of our products, information in

this document is subject to change without notice. Images shown are only

representations of some of the configurations available for this model.

Availability may vary depending on region.

As a phenomenon known to thin-film transistors (TFTs), liquid crystal displays

(LCDs) commonly exhibit a small number of discoloration dots, as so-called

"non-conforming pixels." This phenomenon is a limitation of TFT LCD

technology, not a product defect, and as such is not covered by Gateway's

warranty.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

Intel is a registered trademark of Intel Corporation.

About Gateway

Since its founding in 1985, Irvine, Calif.-based Gateway has been a technology

pioneer, offering award-winning products and world-class service to

customers worldwide. Gateway is a wholly owned subsidiary of Acer Inc., the

world's third-largest PC company. See www.gateway.com for more

information.

CHAPTER 1: System Specifications

EC54 Specifications

Operating system1

•Genuine Windows®7 Home Premium 64-bit2

CPU/chipset1

•Intel®Pentium®processor SU4100 (2 MB L2 cache, 1.30 GHz, 800

MHz FSB, 10 W), supporting Intel®64 architecture

•Intel®Celeron®processor SU2300 (1 MB L2 cache, 1.20 GHz, 800

MHz FSB, 10 W), supporting Intel®64 architecture

•Intel®Celeron®processor 743/723 (1 MB L2 cache, 1.30/1.20 GHz,

800 MHz FSB,10 W), supporting Intel®64 architecture

•Mobile Intel®GS45 Express Chipset

System memory1,3,4

•Dual-channel DDR3 SDRAM support

•Up to 4 GB of DDR3 1066 MHz memory, upgradeable to 8 GB using two

soDIMM modules

Display

•15.6" HD 1366 x 768 pixel resolution, high-brightness (200-nit),

Gateway Ultrabright™LED-backlit TFT LCD

•16:9 aspect ratio

Graphics1

•ATI Mobility Radeon™HD 43305 with up to 23046 MB of HyperMemory™

(512 MB of dedicated DDR3 VRAM, up to 1792 MB of shared system

memory), supporting Unified Video Decoder (UVD), OpenEXR High

Dynamic-Range (HDR) technology, Shader Model 4.1, Microsoft®

DirectX®10.1

•Mobile Intel®GS45 Express Chipset with integrated 3D graphics,7

featuring Intel®Graphics Media Accelerator 4500MHD (Intel®

GMA 4500MHD) up to 1695 MB of Intel®Dynamic Video Memory

Technology 5.0 (64 MB of dedicated video memory, up to 1631

MB of shared system memory), supporting Microsoft®DirectX®10

•Dual independent display support

•16.7 million colors

•External resolution/refresh rate:

•2048 x 1536: 75/60 Hz

•1920 x 1440: 85/75/60 Hz

•1920 x 1200: 75/60 Hz

•1920 x 1080: 100/85/75/60 Hz

•1680 x 945: 100/85/75/60 Hz

•1600 x 1200: 120/100/85/75/60 Hz

•1600 x 900: 120/100/85/75/60 Hz

•1400 x 1050: 85/75/60 Hz

•1366 x 768: 85/75/60 Hz

•1280 x 1024: 120/100/85/75/60 Hz

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Gateway Computer portatile

Gateway

Gateway 200ARC Manuale utente

Gateway

Gateway MD24 Manuale elenco delle parti

Gateway

Gateway MG1 Manuale utente

Gateway

Gateway 450ROG Manuale utente

Gateway

Gateway TC73 Manuale elenco delle parti

Gateway

Gateway Notebook Manuale utente

Gateway

Gateway Solo 5100 Istruzioni di montaggio

Gateway

Gateway Solo 2200 Manuale utente

Gateway

Gateway M500 Guida rapida

Gateway

Gateway ID57HR Manuale utente

Gateway

Gateway NV7802u - NV - Core 2 Duo 2.2 GHz Manuale utente

Gateway

Gateway M405 Manuale elenco delle parti

Gateway

Gateway LT2001u Manuale utente

Gateway

Gateway 200ARC Manuale elenco delle parti

Gateway

Gateway M465 Manuale utente

Gateway

Gateway NV55S02U Manuale utente

Gateway

Gateway NE46R Manuale utente

Gateway

Gateway M280 Come usare

Gateway

Gateway NV-40 Manuale elenco delle parti

Gateway

Gateway NV42 Series Manuale utente

Gateway

Gateway T-6817c Manuale utente

Gateway

Gateway M505 Manuale utente

Gateway

Gateway M-1412 Manuale utente

Gateway

Gateway Convertible notebook Manuale utente

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale
