1. DESCRIPTIon
gCE proFIT®is portable oxy-fuel cutting machine
that cuts unalloyed steel by material combustion
with using of oxygen –fuel gas preheating flame.
This machine can also be used for linear and
circular cutting or for cutting curved (patterned)
profiles (figures) by moving manually or by
installing additional parts. there is an option to use
second cutting torch if necessary.
gCE proFIT®can be used for straight cutting,
curved cutting or bevel cutting with one or two
cutting torches at maximum. Maximal material
thickness to be cut is 150 mm with one cutting
torch and 100 mm with two cutting torches.
Complete machine consists of more parts to be
ordered separately, please see instructions and
recommendation below.
gCE proFIT® machine can also be used for plasma ®
Fig.1 Machine GCE proFIT with Zn-coated guide rail
cutting, preheating and welding but with additional equipment (not supplied with the machine) and by
making necessary changes. these operating instructions explain safe and efficient operation of gcE
proFit® .
GCE proFIT®portable cutting machine should be used taking the
warnings specified in the instructions into consideration.
operators of the machine shall have learnt the content of this Instruction for Use and shall be
experienced with oxy-fuel equipment and trained according to request of iso, en or national
standards with respecting all requests of legal authorities.
2. FEaTURES
2.1 TECHnICaL DaTa
Cutting capacity
Cutting speed
up to 150mm with one torch, up to 100mm with two torches
forward and reverse with variable speed
80 –1340 mm (optional up to 2340mm)
485mm (cutting with two torches parallel)
power supply
Engine supply
g1/4“, up to 8bar, hose min. dN8
Fuel gas inlet connection
g3/8“LH, up to 1bar, hose min. dN8
