Specification Created 1/04

330333

JGP337SEJ/WEJ/CEJ/BEJ – GE® 30" Built-In Gas Cooktop

AGA Requirement: All gas cooktop models required 7/16"

free area below cooktop height to combustible material.

0” Clearance is required between left and right sides of

cooktop below countertop. Requires 18" minimum from

countertop to adjacent overhead cabinets.

Note: If installing with a GE Profile™ Telescopic Downdraft

System, consult both cooktop and downdraft installation

instructions packed with product before installing. Cooktop

gas/electric supply may need to be re-routed to install

downdraft.

Electrical Rating: 120V, 60Hz, 5A

Installation With Single Wall Oven Information:

30" Gas Cooktops are approved for use over select GE 27"

Wall Ovens. 30" and 36" Gas cooktops are approved for

use over 30" Wall Ovens. Refer to cooktop and wall oven

installation instructions packed with product for current

dimensional data.

Installation Information: Before installing, consult

installation instructions, packed with product, for current

dimensional data.

Optional Gas Range Wok Accessory

(Available at Additional Cost)

JXWK-Wok Accessory sits on top of maximum burner grate

to hold a round bottom wok.

Cooktop

2-1/2

(Min.)

28-1/2

19-5/8

2-1/2

30 21

Electrical junction

box 12" MIN.

below countertop

30" MIN. to

unprotected

cabinet

Cut should

not interfere

with cabinet

structure at

front

3-3/4" MIN.

clearance to

side wall

from cut-out

3-3/4" MIN.

clearance to

side wall

from cut-out

18" MIN.

to cabinet

13" MAX.

depth

2-1/4" to

rear wall

Cooktop

2-1/2

(Min.)

28-1/2

19-5/8

2-1/2

30 21

Electrical junction

box 12" MIN.

below countertop

30" MIN. to

unprotected

cabinet

Cut should

not interfere

with cabinet

structure at

front

3-3/4" MIN.

clearance to

side wall

from cut-out

3-3/4" MIN.

clearance to

side wall

from cut-out

18" MIN.

to cabinet

13" MAX.

depth

2-1/4" to

rear wall

Dimensions (in inches) Counter Installation Dimensions (in inches)

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center® service, 800.626.2000.

Electrical

cord

45°

Electrical

outlet

Shut-off

valve

Pressure

regulator

1/2" pipe

Coupling

Gas Connection

GE Appliances

Specification Created 1/04

330333

JGP337SEJ/WEJ/CEJ/BEJ – GE® 30" Built-In Gas Cooktop

Features and Benefits

• Tempered glass cooktop – Delivers a smooth, uniform surface for an attractive

appearance that’s easy-to-clean

• Sealed cooktop burners – Eliminate the space between the burners and the

cooktop to help contain spills and boil over liquids, ensuring easy cleanup

• High output burner – Provides a powerful 12,000 BTU burner output for

efficient heat-up and boiling

• Precise simmer burner – Offers the low setting of 600 BTUs, ensuring more

temperature control for simmering

• Porcelain drip bowls –Contain minor spills and are removable for cleaning in

the sink or dishwasher

• Dishwasher safe grates – Durable grate construction can be placed into the

dishwasher for easy cleaning and maintenance

• Deluxe cast grates – Constructed from a premium cast iron material for a

long-lasting performance and durability

• Model JGP337SEJSS – Stainless steel

• Model JGP337WEJWW – White on white

• Model JGP337CEJCC – Bisque on bisque

• Model JGP337BEJBB – Black on black

JGP337SEJ
