Specification Created 1/04
330331
JGP637SEJ/WEJ/CEJ/BEJ – GE® 36” Built-In Gas Cooktop
AGA Requirement: All gas cooktop models required 7/16"
free area below cooktop height to combustible material.
0” Clearance is required between left and right sides of
cooktop below countertop. Requires 18" minimum from
countertop to adjacent overhead cabinets.
Note: If installing with a GE Profile™ Telescopic Downdraft
System, consult both cooktop and downdraft installation
instructions packed with product before installing. Cooktop
gas/electric supply may need to be re-routed to install
downdraft.
Electrical Rating: 120V, 60Hz, 5A
Installation With Single Wall Oven Information:
30" Gas Cooktops are approved for use over select GE 27"
Wall Ovens. 30" and 36" Gas cooktops are approved for
use over 30" Wall Ovens. Refer to cooktop and wall oven
installation instructions packed with product for current
dimensional data.
Installation Information: Before installing, consult
installation instructions, packed with product, for current
dimensional data.
Optional Gas Range Wok Accessory
(Available at Additional Cost)
JXWK-Wok Accessory sits on top of maximum burner grate
to hold a round bottom wok.
Cooktop
2-1/2"
(min.)
3-1/16
33-7/8
19-1/8
36 21
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
3-3/4" MIN.
clearance to
side wall
from cut-out
3-3/4" MIN.
clearance to
side wall
18" MIN.
to cabinet
2-1/4" to
rear wall
13" MAX.
depth
Cooktop
2-1/2"
(min.)
3-1/16
33-7/8
19-1/8
36 21
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
3-3/4" MIN.
clearance to
side wall
from cut-out
3-3/4" MIN.
clearance to
side wall
18" MIN.
to cabinet
2-1/4" to
rear wall
13" MAX.
depth
Dimensions (in inches) Counter Installation Dimensions (in inches)
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
Electrical
cord
Electrical
outlet
Shut-off
valve
Pressure
regulator
1/2" pipe
Coupling
Gas Connection
GE Appliances
Specification Created 1/04
330331
JGP637SEJ/WEJ/CEJ/BEJ – GE® 36” Built-In Gas Cooktop
Features and Benefits
• Tempered glass cooktop – Delivers a smooth, uniform surface for an attractive
appearance that’s easy-to-clean
• Sealed cooktop burners – Eliminate the space between the burners and the cooktop to
help contain spills and boil over liquids, ensuring easy cleanup
• High output burner – Provides a powerful 12,000 BTU burner output for efficient
heat-up and boiling
• Precise simmer burner – Offers the low setting of 600 BTUs, ensuring more
temperature control for simmering
• Porcelain drip bowls –Contain minor spills and are removable for cleaning in the
sink or dishwasher
• Dishwasher safe grates – Durable grate construction can be placed into the
dishwashser for easy cleaning and maintenance
• Deluxe cast grates – Constructed from a premium cast iron material for a long-lasting
performance and durability
• Model JGP637SEJSS – Stainless steel
• Model JGP637WEJWW – White on white
• Model JGP637CEJCC – Bisque
• Model JGP637BEJBB – Black on black
JGP637SEJ
