Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
GDWT200/260R
GE®Built-In Dishwasher with Hidden Controls
Specification Created 6/09 350208
Listed by
Underwriters
Laboratories
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
55
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 9.1
Calrod®heater watts max........................ 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
†† Add 1/2" for deepest part of contour door.
Allow an additional 2” for the handle on
PDWT500/PDWT400/PDWT200 Series
models.
24
25-1/4*
21-1/4
44 (Adjustable)
27-1/2
22-1/2
34" MIN.
adj. t o 35"
* Allow an additional 2.525” for the handle on
GDWF160/100 Series models.
GDWT200/260R
GE®Built-In Dishwasher with Hidden Controls
Specification Created 6/09 350208
GDWT260RSS
Features and Benefits
• PureCleanwashsystemwith5-stagefiltration-Multiplefiltrationlevelsensure
clean dishes
• ENERGYSTAR®Qualified - Meets or exceeds federal guidelines for energy efficiency for
year-round energy and money savings
• CleanSensor™- A tiny laser measures soil levels and water temperature to adjust to the
ideal cycle time
• SteamPre-Washoption-Steamhelpstoloosentoughsoilsbeforeanycycle
• Electroniccontrolswith3cycles/3options-Moderncontrolsmakeiteasytoprogram
the dishwasher
• QuietPower™52 sound package - 52 dBA - An enhanced sound-deadening system
muffles noises and keeps the kitchen quiet
• SaniWashcycle-Specialcyclereduces99.999%ofharmfulgermsandbacteria
• ModelGDWT260RSS-Stainlesssteel(shown)
• ModelGDWT200RWW-Whiteonwhite
• ModelGDWT200RBB-Blackonblack
