Specification Created 7/03

250200

PDW9200/80J – GE Profile™Fully Integrated Built-In Dishwasher

Built-In Dishwasher Dimensions (in inches)

For answers to your Monogram,

® GE Profile™or

GE®appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Listed by

Underwriters

Laboratories

As an ENERGY STAR®partner,

GE has determined that this product

meets the ENERGY STAR®

guidelines for energy efficiency.

This wall area

must be free of

pipes or wires

Countertop

Hot

water

line on

left

2Plumbing and electrical

service must enter

inside shaded area

24" From wall

24" MIN.

90°

19" MIN. from wall

24"

MIN.

34-1/2±1/4"

Underside

of countertop

to floor

90°

Electrical

wiring on

right

Electrical

wiring is

3" from

cabinet

*Allow an additional 2" for the handle on PDW9800/9200 Series models.

25-1/4

21-1/4

44 (Adjustable)

34" MIN.

adj.to 35"

27-1/2

22-1/2

Dishwasher Rough-In Information

Note: Dishwasher must not be installed more than ten feet from sink for proper drainage. All plumbing and

electrical work must be in accordance with local codes.

The power cord and connections must comply with the National Electrical Code Section 422 and/or local

codes and ordinances. The cord must be no longer than six feet from the junction box to the receptacle.

Electrical Rating

Voltage AC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Hertz. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Total connected load amperage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.1

Calrod®heater watts max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 875

For use on adequately wired 120-volt, 15-amp circuit having 2-wire service with

a separate ground wire. This appliance must be grounded for safe operation.

Specification Created 7/03

250200

PDW9200/80J – GE Profile™Fully Integrated Built-In Dishwasher

NTI-

ACTERIAL

OOKWARE

ORMAL

PEED

YCLE

INSE

NLY

2 4 8

DELAY

HOURS

ADDED

HEATHEATED

DRY

STATUS

TOLOCK

CONTROLS:

PRESS

HEATEDDRY

FOR3SEC.

ENHANCEMENTS

SELECTIONS

ANITIZED

LEAN

START

RESET

Features and Benefits

• Fully integrated door design – Blends seamlessly into existing cabinetry.

• Bright annealed stainless steel tub and door liner – A lustrous finish and lasting beauty that

resists stains and corrosion.

• Nylon rack design with color-matched components – Matches the grade 304 stainless steel for

a beautiful, monochromatic interior.

• Removable upper rack – Pulls out completely to provide up to 22" for washing oversized items.

• Tall-Over-Tall™towerless nylon rack system – Holds tall or oversized items, or washes

16 place settings at once.

• QuietPower™VI sound package – Features the fan-assist drying system, the new concealed

ActiveVent and an enhanced insulation package to make this the quietest GE Profile

dishwasher ever.

• Fan-Assist Dry – Employs a quietly running fan to dry dishes quickly and efficiently.

•Anti-bacteria cycle – Sanitizes tableware by reducing 99.999% of the bacteria found on dishes.

• 2/4/6 hour delay start – Programs the dishwasher to start the wash cycle at a more

convenient time or during off-peak hours when utilities are at reduced rates.

• 16 place settings capacity – Accommodates up to 16 place settings in a single load.

• Model PDW9200JWW – White on white

• Model PDW9200JCC – Bisque on bisque

• Model PDW9200JBB – Black on black

• Model PDW9280JSS – Stainless steel

As an ENERGY STAR®partner,

GE has determined that this product

meets the ENERGY STAR®

guidelines for energy efficiency.
