Specification Revised 6/04
350389
GSD5500GWW/CC/BB – GE Triton® Built-In Dishwasher
GE Appliances
Dimensions
(in inches)
Wood Insert Cut-Out
Dimensions (in inches)
Installation Information
(in inches)
Note: Dishwasher must not be installed more than 10 feet from
sink for proper drainage. All plumbing and electrical work must
be in accordance with local codes.
Note: If a flush look is needed, a 25" base cabinet needs to
be used.
24
25-3/4
MAX.
21-1/2
3-1/44 (Adjustable)
34 MIN.
adj. to 35
24-3/4
23-3/8
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34-1/2±1/4"
Underside
of countertop
to floor
5 5
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
White (neutral)
Black (line)
Ground
C
B
Access insert
Detail D
Panel Thickness
Door insert
Front
of
Panel
Dishwashers Installation
(Pub. 1-G003 pg. 131B) May 12, 1993
Wood Insert Cut-Out Dimensions (in inches)
GE/Hotpoint/RCA
A
1-1/2 1/2
When using GPF325
1/4" custom dishwasher
door and access panel kit.
When using GPF375
3/4" custom dishwasher
door and access panel kit.
1/4
3/4
Models/Kits A B C
Panel
Thickness
GE Triton
Models/GPF425 19-3/4" 23-9/16" 3-11/16" 1/4"
GE Triton
Models/GPF475 19-97/8" 23-5/8"*
4-1/4" to
3-11/16"** 3/4"
** Bottom of panel must be notched 1-1/2" x 1/2" to clear access
panel. (See illustration above)
** Adjustment required to match adjacent cabinet fronts due to
leveling adjustment, 4" nominal.
For answers to your Monogram,
® GE Profile™ or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 6/04
350389
GSD5500GWW/CC/BB – GE Triton® Built-In Dishwasher
GE Appliances
GSD5560GSS
Features and Benefits
• TriClean™ wash system with 3 wash arms – Eliminates prerinsing, soaking and scrubbing
• Electronic controls – Provide a smooth easy-to-use, easy-to-clean surface
• ExtraClean™ sensor – Monitors cycle length, water temperature and soil content to ensure dishes
get clean efficiently
• SaniWash™ cycle – Sanitizes tableware by reducing 99.999% of the bacteria found on your dishes
• Super Upper Rack – Includes a deep, tiered upper rack with fold-down utility shelves to double stack
dishes and cups
• QuietPower™ II sound package – Soften the sound of the dishwasher for a more peaceful kitchen
• 2/4/8 hour delay start – Makes it easier than ever to wash dishes at any hour taking advantage of
reduced energy rates or washing dishes even when the family is asleep
• 15 place setting capacity – Accommodates up to 15 place settings in a single load
• Piranha™ hard food disposer – Grinds leftover food into small particles that are easily washed away
• Trimless door design – Features sleek, classic panels for an instant built-in look
• Model GSD5560GSS – Stainless/Black
• Model GSD5500GWW – White on white
• Model GSD5500GCC – Bisque on bisque
• Model GSD5500GBB – Black on black
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
