GSS1800

Owner’s Manual

Safety Instructions . . . . . . . .2–4

Operating Instructions

Adding Wood Inserts . . . . . . . .11

Care and Cleaning . . . . . . . 12, 13

Control Panel . . . . . . . . . . . . 6, 7

Features . . . . . . . . . . . . . . . . . . .5

Loading the

Dishwasher Racks . . . . . . . .10, 11

Using the Dishwasher . . . . . . 8, 9

Troubleshooting Tips . . . .14–16

Consumer Support

Consumer Support . . .Back Cover

Product Registration . . . . . .17, 18

Warranty . . . . . . . . . . . . . . . . . .19

Write the model and

serial numbers here:

Model # ____________

Serial # ____________

You can find them on

the tub wall just inside

the door.

Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be

followed to minimize the risk of fire, explosion, electric

shock, or to prevent property damage, personal injury,

or loss of life.

Under certain conditions hydrogen gas may be produced

in a water heater that has not been used for two weeks or

more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water has not been used for two weeks or more, prevent

the possibility of damage or injury by turning on all hot water

faucets and allow them to run for several minutes. Do this before

using any electrical appliance which is connected to the hot water

system. This simple procedure will allow any built-up hydrogen gas

to escape. Since the gas is flammable, do not smoke or use an open

flame or appliance during this process.

WATER HEATER SAFETY

DO NOT…

■Do not tamper with controls.

■Do not abuse, sit on, or stand

on the door or dish rack of

the dishwasher.

■Do not discard a dishwasher

without first removing the

door of the washing

compartment.

■Do not store or use

combustible materials,

gasoline or other flammable

vapors and liquids in the

vicinity of this or any other

appliance.

■Do not allow children to

play inside, on or with this

appliance or any discarded

appliance.

WARNING!

GEAppliances.com

Consumer Support

Troubleshooting TipsOperating InstructionsSafety Instructions

Use your dishwasher only for its intended purpose as

described in this Owner’s Manual.

This dishwasher must be properly installed and located in

accordance with the Installation Instructions before it is used.

If you did not receive an Installation Instructions sheet with

your dishwasher, you can receive one by visiting our

Website at GEAppliances.com.

■Connect to a grounded

metal, permanent wiring

system; or run an equipment-

grounding conductor with

the circuit conductors and

connect to the equipment-

grounding terminal or lead

of the appliance.

■Improper connection of

the equipment-grounding

conductor can result in a risk

of electric shock. Check with

a qualified electrician or

service representative if you

are in doubt whether the

appliance is properly

grounded.

■Dispose of discarded

appliances and shipping or

packing material properly.

■Do not attempt to repair

or replace any part of your

dishwasher unless it is

specifically recommended

in this manual. All other

servicing should be referred

to a qualified technician.

■To minimize the possibility

of electric shock, disconnect

this appliance from the power

supply before attempting any

maintenance. NOTE: Turning

the dishwasher off does not

disconnect the appliance

from the power supply.

We recommend having a

qualified technician service

your appliance.

PROPER INSTALLATION

AND MAINTENANCE

Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WHEN USING YOUR DISHWASHER

■Use only powder, tabs or

liquid detergents or wetting

agents recommended for use

in a dishwasher and keep

them out of the reach of

children. Cascade,®Cascade®

Complete and Electrasol®

Automatic Dishwashing

Detergents and Jet-Dry®rinse

agent have been approved for

use in all GE dishwashers.

■Locate sharp items so that

they are not likely to damage

the door seal.

■Load sharp knives with the

handles up to reduce the risk

of cut-type injuries.

■Do not wash plastic items

unless marked dishwasher

safe or the equivalent. For

plastic items not so marked,

check the manufacturer’s

recommendations.

■Non-Dishware Items: Do not

wash items such as electronic

air cleaner filters, furnace

filters and paint brushes in

your dishwasher. Damage to

dishwasher and discoloration

or staining of dishwasher

may result.

■Do not touch the heating

element during or

immediately after use.

■Do not operate your

dishwasher unless all

enclosure panels are

properly in place.

■Close supervision is necessary

if this appliance is used by or

near children.

■Load light plastic items

so they will not become

dislodged and drop to the

bottom of the dishwasher—

they might come into contact

with the heating element and

be damaged.

■Colored aluminum, cast iron,

hand-painted china, wooden,

plastic, rubber and bone-

handled items which are not

marked dishwasher-safe or

equivalent should be washed

by hand.

READ AND FOLLOW THIS

SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

Features of the dishwasher

(a side view). GEAppliances.com

Consumer Support

Troubleshooting TipsOperating InstructionsSafety Instructions

Upper rack

Tower assembly

Lower rack

Lower spray arm

Heating element

Motor

Leveling legs

Door spring

Normal water

fill level

Model & serial #

(on right side of tub)

Float

Console

Options

HEATED DRY ON Turns the heating element on for fast drying. This

option will extend the time of your wash cycle.

HEATED DRY OFF Turns HEATED DRY ON off. Dishes air dry naturally

and energy is saved.

Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support

About the dishwasher control panel.

You can locate your model number on the tub wall just inside the door.

Throughout this manual, features and appearance may vary from your model.

Control Settings

Wash Cycles

POTS & PANS For heavily soiled dishes or cookware with dried-on

or baked-on soils. Everyday dishes may be included.

This cycle will not remove burned-on foods.

HEAVY WASH For heavily soiled dishes or cookware. For dried-on or

baked-on soils, use the POTS & PANS cycle. Everyday

dishes may be included.

NORMAL WASH For loads of everyday dishes, glasses and cookware

with medium soils. NOTE: Many dishes have lighter

soil than normal. Choosing a cycle other than

NORMAL WASH will save energy and water.

LIGHT WASH For dishes with light soils.

RINSE ONLY For rinsing partial loads that will be washed later.

Do not use detergent or HEATED DRY ON.

PLATE WARMER For warming clean dishes and serving plates. This

cycle will take approximately 30 minutes.

Start

Slowly turn the Dial to the desired position on the Dial

after selecting the drying option. Don’t turn it past that

position, or you could accidentally miss a rinse. There is

a time delay between start-up and water fill so you will not

hear any wash action right away.

HEATED

DRY ON

HEATED

DRY OFF PLATE WARMER

(HEATED DRY ON)

RINSE ONLY

POTS & PANS

NORMAL WASH

LIGHT WASH

(HEATED DRY OFF)

OFF

HEAVY WASH

GEAppliances.com

Consumer Support

Troubleshooting TipsOperating InstructionsSafety Instructions

Cycle Sequence

Water Time

Cycles (approx.) (approx.) Cycle Sequence

POTS & PANS 9.3 gal. 55 min. Wash Rinse Rinse Rinse Wash Rinse Rinse

HEAVY WASH 8.0 gal. 48 min. Wash Rinse Rinse Wash Rinse Rinse

NORMAL WASH 6.7 gal. 43 min. Wash Rinse Wash Rinse Rinse

LIGHT WASH 5.3 gal. 37 min. Rinse Wash Rinse Rinse

RINSE ONLY 1.3 gal. 9 min. Rinse

Drying Options

HEATED DRY ON adds approximately 36 minutes to the

cycle. (Not available on the RINSE ONLY cycle.)

Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support

Using the dishwasher.

Check the Water Temperature

The entering water must be at least 120°F and not more than 150°F,

for effective cleaning and to prevent dish damage. Check the water

temperature with a candy or meat thermometer. Turn on the hot

water faucet nearest the dishwasher, place the thermometer in a

glass and let the water run continuously into the glass until the

temperature stops rising.

Use Jet-Dry ®Rinse Agent

Jet-Dry®rinse agent removes spots and prevents new film buildup on

your dishes, glasses, flatware, cookware and plastic.

A dispenser, located next to the detergent

cup, automatically releases a measured

amount of rinse aid during the last rinse.

If spotting and poor drying are problems,

increase the amount of rinse aid dispensed

y rotating the dial to a higher number.

The dial is located under the dispenser

cap. The indicator will be dark when full

and will show clear when it is time to refill.

To add liquid rinse aid, turn dispenser cap

1/4 turn counterclockwise

and lift out. Pour

in rinse aid until liquid touches the indicated

fill level. Replace the cap.

A full dispenser should last about one month.

If rinse agent spills, wipe up the excess.

Dispenser opening Indicator

Dispenser cap

Adjustable setting

Use only detergent specifically made for use in dishwashers.

Cascade,

Cascade

Complete and Electrasol

Automatic Dishwashing

Detergents have been approved for

use in all GE dishwashers.

Keep

your detergent fresh and dry. Don’t put powder detergent into the

dispenser until you’re ready to wash dishes.

The amount of detergent to use depends on whether your water is

hard or soft. With hard water, you need extra detergent. With soft

water, you need less detergent.

Protect your dishes and dishwasher by contacting your water

department and asking how hard your water is. Twelve or more

grains is extremely hard water. A water softener is recommended.

Without it, lime can build up in the water valve, which could stick

while open and cause flooding. Too much detergent with soft water

can cause a permanent cloudiness of glassware, called etching.

You’ll find two detergent cups on the inside door of your dishwasher.

For POTS & PANS,HEAVY WASH and NORMAL WASH, fill both cups.

For LIGHT WASH, fill only the Main Wash cup. Close the Main Wash

cup before closing the dishwasher door.

When using automatic

dishwashing detergent tabs, simply place one tab in the main wash

and close.

GEAppliances.com

Consumer Support

Troubleshooting TipsOperating InstructionsSafety Instructions

Proper Use of Detergent

Fill to

▲

REGULAR

▲

line when using

standard dishwashing detergent.

Fill to

▲

REGULAR

▲

line when using

standard dishwashing detergent.

Pre Wash open cup

Fill to

▲

ULTRA

▲

line when using

ultra or concentrated dishwashing

detergent.

Main Wash covered cup

Fill to

▲

ULTRA

▲

line when using

ultra or concentrated dishwashing

detergent.

To open the main wash cover,

press the retainer button.

The cover will flip back.

Forget to Add a Dish?

A forgotten dish can be added any time before the main wash.

CAUTION: Do not open the door until the water spray action stops.

Water may splash out of the dishwasher.

Unlatch the door to interrupt

the cycle.

Do not open the door until

water spray action stops. Steam

may rise out of the dishwasher.

Add forgotten dishes.

Close the door and push it in

to relatch.

Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support

Loading the dishwasher racks.

For best dishwashing results, follow these loading guidelines. Features and

appearance of racks and silverware baskets may vary from your model.

Upper Rack

The upper rack is for glasses, cups and saucers.

Cups and glasses fit best along the sides. This is

also a secure place for dishwasher-safe plastics.

A cup shelf (on some models) may be placed in

the up or down position to add flexibility. The

upper rack is good for all kinds of odd-shaped

utensils. Saucepans, mixing bowls and other

items should be placed face down.

Secure larger dishwasher-safe plastics over two fingers

when possible.

Make sure small plastic items are secure so they can’t fall

onto the heating element.

The Wash Tower

Keep the center area clear in the lower rack.

The wash tower rises through the center of the

lower rack during the wash and rinse portions of

the cycle.

Don’t block it or load tall things next to it.

Also, be careful not to let a

portion of an item such as a pot

or dish handle extend through

the bottom rack. This could block

the wash arm and cause poor

washing results.

Do not block center area

Altri manuali per GSS1800

Indice

Altri manuali GE Lavastoviglie

GE GDF510PSJSS Manuale utente

GE Nautilus GSD4500 Series Manuale utente

GE GHDA480N Manuale utente

GE Monogram ZBD6800 Manuale utente

GE GDF510PSDSS Manuale

GE CDWT980RSS - Cafe 24" Tall Tub Dishwasher Manuale utente

GE GSD580 Manuale utente

GE Adora Series Manuale utente

GE HDA2030 Istruzioni per l'installazione

GE Profile PDWT200V Manuale

GE GSD3360DSS Manuale

GE Monogram ZBD6400 Series Manuale utente

GE Mabe GLD9312 Come usare

GE Monogram ZBD1850 Manuale utente

GE CDWT980RSS - Cafe 24" Tall Tub Dishwasher Manuale

GE ZBD1870NSS Manuale utente

GE GSD1300N Manuale utente

GE Monogram ZBD3500ZZWW Istruzioni utente

GE Stainless Steel Tub Dishwasher Manuale utente

GE ADW1000 Series Manuale utente

GE Profile PDW8700 Series Manuale utente

GE GSD2800 Series Manuale utente

GE GSD3400 series Manuale utente

GE GSD2300V Manuale

Manuali Lavastoviglie popolari di altre marche

Electrolux

Electrolux ESI5211LOX Manuale utente

KitchenAid

KitchenAid KUDB230B Manuale utente

Brandt

Brandt BDJ424DB Manuale utente

Asko

Asko DSD767UXXL.AU Manuale utente

Beko

Beko DFN26210W Manuale utente

NEFF

NEFF S153ITX00E Scheda tecnica

Midea

Midea SV 4.45 wi Manuale utente

LG LDF7932 Manuale utente

Gorenje

Gorenje GV63214 Manuale utente

Hotpoint

Hotpoint HDA1100ZWH Manuale di servizio

Blomberg

Blomberg LDFN2240W Manuale utente

AEG

AEG FFB83836PM Manuale utente

Cylinda

Cylinda DM3220RFD Manuale utente

Atag

Atag DW8214MB Manuale utente

Siemens

Siemens SN23HI02KE Scheda tecnica

Omega

Omega ODW717X Manuale utente

BORETTI

BORETTI BVW-683 Manuale utente

Siemens

Siemens SN 56N591 Manuale utente
