GE Healthcare
VividClub
Application News
-
Useful shortcuts
for the
Vivid e
GE Healthcare
VividClub
-2-
Table of Contents
USEFUL SHORTCUTS FOR VIVID E
Volume adjustment .............................................................................................................................................................3
Monitor brightness...............................................................................................................................................................3
Eject a media..........................................................................................................................................................................4
Status of network connection.........................................................................................................................................4
Store a log file ........................................................................................................................................................................5
Restarting the system ........................................................................................................................................................5
Using a beamer.....................................................................................................................................................................6
NOTE
This hand out is additional training material.
For more information please refer to the user manual and/or reference manual.
GE Healthcare
VividClub
-3-
An overview on useful shortcuts of the Vivid e
Volume adjustment
Keys
Ctrl + Arrow Left or Arrow Right
For
Adjusting the volume of the loud speakers
When
Can be used during normal application mode
What To-Do
Hold the Crtl key. Additionally use the arrow keys to adjust the volume. To turn the volume to the
maximum, use the right arrow.
Monitor brightness
Keys
Ctrl + Arrow Up or Arrow Down
For
Monitor brightness
Why
For adjusting the monitor to the brightness of the room.
When
Can be used during normal application mode
What To-Do
Normally, you can see Brightness 0-31 bar at the bottom-left corner of the screen. See Section 6-2
on monitor adjustments in the service manual or in the proprietary manual.
Things to mention
ۥ The proper setup displays a complete gray scale. The lowest level of black should just
disappear into the background and the highest white should be bright, but not saturated.
GE Healthcare
VividClub
-4-
€‚ After readjusting the LCD monitor's Brightness, readjust all preset and peripheral settings.
€ƒ The brightness of the LCD monitor’s Brightness should be set first, as it affects the Gain and
Dynamic Range settings of the image. Once set, this should not be changed unless the
brightness of your scanning environment changes.
Eject a media
Keys
Ctrl + E
For
Ejection media
Why
To remove a media properly from the system.
When
While in application mode the shortcut can be used.
To-Do
Select the medium from the popup list with the trackball and press select.
Status of network connection
Keys
Alt + N
For:
Display the status of the connectivity in the network.
Why:
To check if the network connection is available.
When:
Can be used in the normal application mode.
To-Do:
Window opens that show the status like this:
Status: Scanner is connected to GEMS Service.
Click the Ok button to close the window.
GE Healthcare
VividClub
-5-
Store a log file
Keys
Alt + D
For
Storing Log files
Why
When a problem occurs on the system, the user can store a log file. This log file can be sent for
further review to help solving the problem.
When
Can be used in the normal application mode.
To-Do
Press the Alt + D keys at the same time. A new window will open. Type in a description of the
problem and the last steps that where done on the system. Then press Save. Call your GE
representative on how to proceed further get the log files for review.
Restarting the system
Keys
Ctrl + Alt + R
For
Restarting the application SW
Why
If problems occur during working it is sometimes helpful to restart the program.
When
Can be used during normal application mode
To-Do
A message appears if you want to restart the application.
Press Yes and the application will restart immediately.
During the boot process you will have the possibility to start the problem reporting system by
clicking Ok.
This gives the opportunity to give some problem description and store a log file.
GE Healthcare
VividClub
-6-
Using a beamer
Keys
Ctrl + Alt + V
For
External monitor
Why
For adding a beamer
To-Do
Displays the Graphics Controller Properties window and permits the display to be switched to
Notebook, External Monitor, or Dual (both) for external monitor or projector, if currently connected
on the VGA port. If the Graphics Controller Properties window is displayed and the Dual option or
External Monitor option is not displayed, then the cable is either disconnected or is not connected
properly.
