†Check local codes for required breaker size.
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least 194°
temperature rating.
Installation information: Before installing, consult
installation instructions packed with product for
current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
JRP28BJ
GE® 24" Built-In Double Wall Oven
KW Rating
240V 7.1
208V 5.3
Breaker Size
30 Amps†
Listed by
Underwriters
Laboratories
R
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Revised 7/05 320308
10
Locate
junction box
5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Allow 3/4"
for overlap
over all edges
of cutout
24
Minimum
cutout location
from floor
48-1/8
Min.
14
2" X 4" or
equiv. runners
(cutout floor) 21" MIN.
door opening
allowance
23-1/2
22-1/2
23-3/4
23-1/8
48-1/8 w/out trim
49-1/4 with trim
Locate
junction box
56" MIN. above
cutout floor
Conduit
(48-1/2" Long)
21
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
11"
over centerline
of cabinet
JRP28BJ
GE® 24" Built-In Double Wall Oven
Specification Revised 7/05 320308
Features and Benefits
• Self-clean oven –Conveniently cleans oven cavity without the need for scrubbing
• Electronic oven controls – One-touch electronic pads are easy-to-use and allow for
simple oven operation
• ClearView™ window – Provides a convenient viewing area to check the progress
of food
• Interior oven light – Supplies light to make viewing the progress of cooking easy
and convenient
• Two oven racks – Feature a durable construction to help accommodate any size or
type of cookware
• Multiple oven rack positions –Deliver flexibility and allow consumers to make the most
of available oven capacity
• Frameless glass oven door – Offers an easy-to-clean and stylish design that blends
seamlessly into existing cabinetry
• Certified Sabbath mode – Prepared foods stay warm in accordance with kosher law
• Model JRP28BJBB - Black on black
JRP28BJ
START
CLEAR
OFF
BAKE
SELF
CLEAN
COOKING
TIME
DELAY
START
OVEN
LIGHT
HOLD 3 SEC. TO
SET CLOCK
TIMER
CLOCK
TIME CONTROLS
OVEN CONTROLS
5
0
0
•
4
5
0
•
4
0
0
•
3
5
0
•
3
0
0
•
2
5
0
•
2
0
0
B
R
O
I
L
W
M
OFF
LOWER OVEN
