GE Profile PK956DR Manuale

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

KW Rating

240V 7. 2

208V 5.4

Breaker Size

240V 30 Amps

208V 30 Amps

Note:

Cabinets installed adjacent to wall ovens

must have an adhesion spec of

at least a 194°F

temperature rating. For 27” built-in single ovens,

if marks, blemishes or the cutout opening is visible

above the installed oven, it may be necessary to

add wood shims under the runners and front trim

until the marks or openings are covered.

Note: Door handle protrudes 3" from door face.

Cabinets and drawers on adjacent 45° and 90°

walls should be placed to avoid interference with

the handle.

Electric wall ovens are not approved for

installation with a plug and receptacle.

They must be hard wired in accordance with

installation instructions.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

Cabinet 27"

A – Cabinet width required 27" min.

B – Minimum cabinet depth 23-5/8"

C – Opening width 25" min. - 25-1/4" max

D – Opening height 50-1/8" max

E – Recommended minimum cutout location from ﬂoor 13-1/4"

Oven

F – Overall depth* 23-5/8"

G – Overall height with trim 51-7/8" - 52-3/4"

Overall height without trim 51"

H – Overall width 26-5/8"

*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.

Suitable

bracing

to support

runners 18"

Over centerline

of cabinet

(must support 300 lbs.)

2" x 4" or

equivalent

runners

Locate

unction box

for 27"models

either 5" MIN.

below cutout

floor or 44"

MIN. above

cutout floor

Access

from

adjacent

cabinet

required

Allow 3/4"

for overlap

over all edges

of cutout

Minimum

cutout location

from floor

2" X 4" or

equiv. runners

(cutout floor) 21" MIN.

door opening

allowance

Locate

junction box

for 24"models

56" MIN. above

cutout floor

Conduit

(48-1/2" Long)

PK956DR

GE Profile™27" Built-In Convection/Thermal Wall Oven

Cabinet 27"

A – Cabinet width required 27" min.

B – Minimum cabinet depth 23-5/8"

C – Opening width 25" min. - 25-1/4" max

D – Opening height 50-1/8" max

E – Recommended minimum cutout location from ﬂoor 13-1/4"

Oven

F – Overall depth* 23-5/8"

G – Overall height with trim 51-7/8" - 52-3/4"

Overall height without trim 51"

H – Overall width 26-5/8"

*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.

Suitable

bracing

to support

runners 18"

Over centerline

of cabinet

(must support 300 lbs.)

2" x 4" or

equivalent

runners

Locate

unction box

for 27"models

either 5" MIN.

below cutout

floor or 44"

MIN. above

cutout floor

Access

from

adjacent

cabinet

required

Allow 3/4"

for overlap

over all edges

of cutout

Minimum

cutout location

from floor

2" X 4" or

equiv. runners

(cutout floor) 21" MIN.

door opening

allowance

Locate

junction box

for 24"models

56" MIN. above

cutout floor

Conduit

(48-1/2" Long)

Dimensions and Installation Information (in inches)

Specification Created 5/10 220367

Features and Benefits

• GlassTouchControls-Smoothcontrolsareeasytouseandadda

sophisticated style to the kitchen

• Blackglossoveninterior-Blackoveninterioraddsastylishtouchtoany

kitchen

• PreciseAir™ConvectionSystem-Areversingfancirculatesheatandairfor

evenly browned and baked foods

• Heavy-dutyrollerrack-Racksprovideeasyaccesstoitemsinsidetheoven

by simplifying loading and unloading

• Flatbackconvection-Convectionfansystemisonly1"deeptoprovide

additional room for cookware

• ConvectionBake-Thissettingisoptimalforbakingcasserolesorlasagnas,

yeast breads, pies and pizzas with no need to turn the pan

• Convectionroast-Optimalforlargercutsofmeat,thissettingrotatesthe

heat around all sides, sealing in the juices, producting rotisserie results at up

to 25% faster than a convectional oven

• Hiddenbakeoveninterior-Concealsthelowerovenbakeelementto

eliminate hard-to-reach areas that collect food and spills for easy cleaning

• SelfCleanOven-Self-cleanallowsyoutospareyourselffromthetrouble

and effort it takes to scrub the oven interior

• Upfronthalogenlights-Halogenlightsmakescheckingontheprogressof

your cooking effortless

• ModelPK956DRBB–Blackonblack

•ModelPK956DRCC–Bisqueonbisque

• ModelPK956DRWW–Whiteonwhite

PK956DR

GE Profile™27" Built-In Convection/Thermal Wall Oven

Specification Created 5/10 220367
