PT956BM/CM/WM

GE Profile™30" Built-In Double Convection/Thermal Wall Oven

KW Rating

240V 9.0

208V 6.8

Breaker Size

240V 40 Amps

208V 40 Amps

Note: Cabinets installed adjacent to wall ovens

must have an adhesion spec of at least a 194°F

temperature rating. Electric wall ovens are

not approved for installation with a plug and

receptacle. They must be hard wired in accordance

with installation instructions.

Door handle protrudes 3" from door face. Cabinets

and drawers on adjacent 45° and 90° walls should be

placed to avoid interference with the handle.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

21" minimum

Door Opening

Allowance

Cutout height

51-13/16" MIN.

51-15/16" MAX.

Minimum cutout location

12" from the floor.

Cutout depth

23-1/2" MIN

47" to

bottom of

junction box

Cutout width

28-1/2'' MIN.

28-5/8'' MAX.

Cabinet

width 30"

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

Conduit

48-1/2"

Junction box

location

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 325 lbs.)

Cabinet 30"

A – Overlap of oven over side of edges of cutout 11/16"-3/4"

B – Overlap of oven at top and bottom of cutout 1"

Oven

C – Overall depth* 23-1/2"

D – Overall height with trim 53-3/8"

Overall height without trim 52-7/8"

E –Overall width 29-3/4"

*Depth including door handle is approximately 26-6/10" min. to

26-9/10" max.

21" minimum

Door Opening

Allowance

Cutout height

51-13/16" MIN.

51-15/16" MAX.

Minimum cutout location

12" from the floor.

Cutout depth

23-1/2" MIN

47" to

bottom of

junction box

Cutout width

28-1/2'' MIN.

28-5/8'' MAX.

Cabinet

width 30"

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

Conduit

(72"

long)

Junction box

location

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 325 lbs.)

Cabinet 30"

A – Overlap of oven over side of edges of cutout 11/16"-3/4"

B – Overlap of oven at top and bottom of cutout 1"

Oven

C – Overall depth* 23-1/2"

D – Overall height with trim 53-3/8"

Overall height without trim 52-7/8"

E – Overall width 29-3/4"

*Depth including door handle is approximately 26-6/10" min. to

26-9/10" max.

Dimensions and Installation Information (in inches)

Specification Revised 6/09

220139

Features and Benefits

• GlassTouchControls-Featuresasmoothglassdesignthatiseasy-to-operateand

easy-to-clean

• PreciseAir™Convection System (Upper Oven Only) - Provides even air and heat

circulation for superior baking and roasting results

• FlatBackConvection(UpperOvenOnly)-Featuresamorestreamlineconvectionfan

that better accommodates baking or roasting pans

• ConvectionBake(UpperOvenOnly)-Deliversidealairflowthroughouttheovencavity,

ensuring better baking results

• ConvectionRoast(UpperOvenOnly)-Deliversevencookingandconsistentresults,

roasting meats up to 25% faster than a conventional oven

• HiddenBakeOvenInterior-Hidespreviouslyexposedbottomelementtodelivera

clean interior appearance

• SelfCleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing

• ImprovedLighting-Positionslampsdiagonallyacrossthetopoftheoventopromote

better viewing

• Self-CleanHeavy-DutyOvenRacks-Doublecoatedporcelain-enameledracksno

longer require hand cleaning

• Extra-LargeOvenCapacity-Providesalargeoveninterioridealforcookingmore

items at once

• ModelPT956BMBB–Blackonblack

• ModelPT956CMCC–Bisqueonbisque

• ModelPT956WMWW–Whiteonwhite

PT956BM/CM/WM

GE Profile™30" Built-In Double Convection/Thermal Wall Oven

PT956WM/CM/BM
