Dimensions and Installation Information

J2B918WEK/CEK/BEK

GE Profile™ 30" Free-Standing Dual-Fuel Double Oven Range

Specification Created 12/04

221207

Note: Dimension from the wall to the front

of the closed door handle is 29”. Depth to

front edge of cooktop 25-1/4”. Factory set for

Natural Gas. A set of LP orifices is included

with each range for LP conversion.

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Dimension and installation information are shown in inches.

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000.

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

47-3/4

26-1/4*

46-3/8

36-1/4±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

CERTIFIED

7-1/2 2-1/4

Recommended acceptable

electrical outlet area. Orient

the electrical receptacle so the

length is parallel to the floor.

Product is shipped with a 4-prong

plug. Recommended outlet is a

NEMA 14-50R receptacle.

Wall Mounted

J2B900_elec_locate.eps

Recommended area for electric outlet

7-1/2

Recommended area for

through-the-wall connection

of pipe stub/shut-off valve.

Recommended area for

through-the-floor connection

of pipe stub/shut-off valve.

This area allows for

flush range installation

with the rear wall.

J2B900_gas_locate.eps

Recommended area for gas outlet

J2B918WEK/CEK/BEK

GE Profile™ 30" Free-Standing Dual-Fuel Double Oven Range

Specification Created 12/04

221207

Features and Benefits

• Electric convection oven - Features electric heating elements and a fan

that circulates air throughout the oven cavity, to deliver uniform and

savory cooking results

• Self clean oven - Conveniently cleans the oven cavity without need of scrubbing

• Center oval burner - Fifth burner in the center of the cooktop, ideal for griddle or

odd-size cookware

• Non-stick griddle - Placed over a fifth center burner the griddle provides a flat,

non-stick surface for cooking and warming all types of foods

• Super-large oven capacity – Provides an impressively large oven interior for

cooking more dishes and large meals at once

• Deep recessed cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• QuickSet VI glass touch oven controls - A smooth glass design that is

easy-to-operate and easy-to-clean

• Precise simmer burner - Offers the low setting of 600 BTUs, ensuring more

temperature control for simmering

• Sealed cooktop burners - Eliminates the space between the burners and the

cooktop to help contain spills and boil over liquids, ensuring easy cleanup

• Power Boil™ 17,000 BTU burner – Delivers 17,000 BTUs of forceful heat for

rapid boiling

• Model J2B918WEKWW - White on white

• Model J2B918CEKCC - Bisque on bisque

• Model J2B918BEKBB - Black on black

JGB918WEK/CEK/BEK

J2B918WEK/CEK/BEK

Double Oven

Lower Oven

LITE

FRONT

654

LO HI

LITE

REAR

654

LITE

RECISE SIMMER

REAR

654

LITE

POWER

BOIL

FRONT

POWER BOIL

SETTING INTENDED FOR

USE WITH LARGER POTS

LITE

CENTER

654

WARM

ZONE

200

250

300350400

450

LOWER OVEN

HEATING
