†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JB700SN
GE®30" Free-Standing Electric Range
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 6/08 321524
KW Rating
240V 12.0
208V 9.0
Breaker Size
40 Amps†
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_ge.eps
Dimension from wall to front of
closed oven door handle is 27-3/4.
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_ge.eps
Dimension from wall to front of
closed oven door handle is 27-3/4.
JB700SN
GE®30" Free-Standing Electric Range
Specification Created 6/08 321524
Features and Benefits
• Self-CleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing
•Super-Large5.3Cu.Ft.OvenCapacity-Providesanimpressivelylargeoveninteriorto
cook more dishes and large meals at once
•TrueTemp™System - Delivers even heat distribution and maximum oven control
•DualSizeRibbonElement-Offersaconvenientchoiceofusinga9"or12"heating
element, depending on the size of the pan
•6"/9"PowerBoil™Element - Accomodates various-size pots or pans and 3,000 watts of
power speeds the boiling process
•HiddenBakeOvenInterior-Hidespreviouslyexposedbottomelementtodeliveraclean
interior appearance
•StainlessAppearanceKnobs-Deliverthesleekmetalliccolorofstainlesssteelfora
universally appealing look
•WarmingZone-Provideslowheatcapabilityforfoods,makingmealcoordinationsimple
•BigHearthWindow-Featuresanenhancedshapetoaddanelegantappearanceand
make viewing trouble-free
•QuickSetIVOvenControls-Featureaneasytousedesignwhichallowsyoutosetprecise
cooking temperatures
• ModelJB700SNSS–Stainlesssteel
JB700SN
BROIL
BAKE
SELF
CLEAN
OVEN
LIGHT
CLOCK
OVENCONTROLS True Temp
START
ON
CLEAR
OFF
TIMECONTROLS
BURNERON
HOTCOOKTOP
WARMING ZONE
CENTER
MED
