†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Revised 1/08 321583

Dimension from wall to front of closed door handle is 27-3/4".

KW Rating

240V 11.5

208V 8.6

Breaker Size

40 Amps†

30

25

29-7/8

46-7/8

2-1/2

7-1/2

25-3/8

47-5/8

2-1/2

Acceptable electrical

outlet area

30_install_fse_ge.eps

Dimension from wall to front of

closed oven door handle is 27-3/4.

JBP65MM

GE®30" Free-Standing CleanDesign™Electric Range

Specification Revised 1/08 321583

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without the need

for scrubbing

• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large oven

interior to cook more dishes and large meals at once

• QuickSet III Oven Controls - Feature an easy to use design that lets you set

precise cooking temperatures

• 6"/9" PowerBoil™Element - Accommodates various-size pots or pans and

3,000 watts of power speeds the boiling process

• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick

and easy

• Dual Element Bake - Alternates the upper broiling element and the lower baking

element for even heating and optimal baking results

• Ribbon Heating Elements - Provide powerful heat beneath a smooth glass

surface to ensure even heat and fast warm-up times

• Big Hearth Window - Features an enhanced shape to add an elegant

appearance and make viewing trouble-free

• Model JBP65MMBS – Clean Steel

JBP65MM

BROIL SELF

CLEAN

OVEN

LIGHT

CLOCK

TIME CONTROLS

OVEN CONTROLS

ONOFF

KITCHEN

LIGHT

ONOFF

BAKESTART

ON

CLEAR

OFF

JBP65MM

GE®30" Free-Standing CleanDesign™Electric Range
