GE JBS27DM Manuale

†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Created 5/07

KW Rating

240V 12.6

208V 9.9

Breaker Size

40 Amps†

CENTER LINE

2-1/4

7-1/2

2-1/4

3-1/2

REAR

WALL

26-1/4*

46-1/4

*Dimension from wall to front

of closed door handle is 28-3/4".

29-7/8

*Dimension from wall to front of closed door handle is 27-3/4".

CENTER LINE

2-1/4

7-1/2

2-1/4

3-1/2

REAR

WALL

26-1/4*

46-1/4

*Dimension from wall to front

of closed door handle is 28-3/4".

29-7/8

322038

JBS27DM

GE®30" Free-Standing Electric Range

Features and Benefits

• Standard Clean Oven - Offers a traditional oven design that requires hand cleaning

• Super-Large Oven Capacity - Provides an impressively large oven interior

for cooking more dishes and large meals at one time

• Coil Heating Elements - Provides consistent and even heat on the cooktop with

a plug-in element that is removable for easy cleaning

• ClearView™ Window - Features a convenient viewing area to check the progress

of food

• Dual Element Bake - Alternates the upper broiling element and the lower baking

element for even heating and optimal baking results

• Electronic Clock And Timer - Features a convenient digital clock and easy-to-use

timer with an audible signal to help coordinate cooking times in the kitchen

• Frameless Glass Oven Door - Offers an easy-to-clean and stylish design that blends

seamlessly into existing cabinetry

• Chrome Drip Bowls - Contain minor spills and are removable for easy cleaning

• CleanWell™ Cooktop System - Ensures spills are properly contained, while providing

convenient cleaning access

• Six Rack Positions - Provides flexibility and allows consumers to make the most

of available oven capacity

• Model JBS27DMWW – White on white (white door and white cooktop)

• Model JBS27DMMCC – Bisque on bisque (bisque door and bisque cooktop)

• Model JBS27DMMBB – Black on black (black door and black cooktop)

JBS27DM

BROILSELF

CLEAN

OVEN

LIGHT

CLOCK

TIMECONTROLS

OVENCONTROLS

ONOFF

KITCHEN

LIGHT

ONOFF

BAKESTART

CLEAR

OFF

COOKING

TIME

ONOFF

AUTOMATICOVEN

START

TIME

ONOFF

Specification Created 5/07 322038

JBS27DM

GE®30" Free-Standing Electric Range
