GE Appliances

JGBP30BEH – GE®30" Free-Standing Self-Clean Gas Range

Installation Information Dimensions (in inches)

Optional Gas Range Accessory

Drip Pans for Sealed and

Standard Burner Models

(Available at additional cost)

To order these accessory drip pans,

call toll-free 800-626-2002.

Gas Self-Clean Range Anti-Tip

Bracket (Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before

installing, consult installation

instructions packed with product

for current dimensional data.

Specification Created 5/03

CERTIFIED

For answers to your Monogram,

® GE Profile™or

GE®appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

All GE ranges are equipped

with an Anti-Tip device.

The installation of this

device is an important,

required step in the

installation of the range.

*Dimension from wall to front of closed door handle is 28-1/4".

Depth to front edge of cooktop – 25-1/4".

30

46-7/8

26-1/4*

46-3/8

36±1/4

24

30

8

4

92

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

GE Appliances

JGBP30BEH – GE®30" Free-Standing Self-Clean Gas Range

Features and Benefits

• Self Clean Oven – Conveniently cleans the oven cavity without need of scrubbing.

• Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more items

at once.

• TrueTemp™System – Delivers even heat distribution and maximum oven control.

• QuickSet IV Oven Controls – Feature an easy to use design that lets you set precise

cooking temperatures.

• High Output Burner – Provides a powerful burner output for efficient heat-up and sautéing.

•Precise Simmer Burner – Offers a low setting of 600 BTUs, ensuring more temperature control

for simmering.

• All Purpose Burners – Deliver a wide range of heat output ideal for most cooking requirements.

• Model JGBP30WEHWW – White on white (white door and white patterned cooktop)

• Model JGBP30CEHCC – Bisque on bisque (bisque door and bisque patterned cooktop)

• Model JGBP30BEHWH – White (black door and white patterned cooktop)

• Model JGBP30BEHCT – Bisque (black door and bisque patterned cooktop)

Specification Created 5/03

PRECISESIMMER

BROIL SELF

CLEAN

OVEN

LIGHT

CLOCK

OVENCONTROLSTrueTemp

ON

TEMP

NORMAL

HI LOOFF

KITCHEN

TIMER

ON OFF

BAKE START

ON

CLEAR

OFF

TIMECONTROLS

COOKING

TIME

ON OFF

AUTOMATICOVEN

START

TIME

ON OFF

HIGHOUTPUT
