Specification Revised 6/07 330513

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

*Dimension from the wall to the front of the closed door

handle is 29". Depth to the front edge of cooktop 25-1/4".

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

JGBP86DEM

GE® 30" Free-Standing Self-Clean Gas Range

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop, ideal

for griddle or odd-size cookware

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval burner,

for cooking multiple foods at once

• PowerBoil™17,000 BTU Burner - Delivers 17,000 BTUs of forceful heat

for rapid boiling

• QuickSet IV Oven Controls - Feature an easy to use design which allows you

to set precise cooking temperatures

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement

of pans between burners

• Dishwasher-Safe Grates - Feature durable construction for worry-free and effortless

cleaning and maintenance

• Sealed Cooktop Burners - Eliminate the space between the burners and the cooktop

to help contain spills and boil over liquids, ensuring easy cleanup

• TrueTemp™System - Delivers even heat distribution and maximum oven control

• Model JGBP86DEMWW - White on white

• Model JGBP86DEMBB - Black on black

JGBP86DEM

PRECISESIMMER

ime

ontrols

ven

ontrols

TempRecall

AutomaticOven

Start

ooking

ime

Start

Time

ven

ight

elf

lean

lock

itchen

imer

ake

roil

rueT

emp

Clean

Specification Revised 6/07 330513

JGBP86DEM

GE® 30" Free-Standing Self-Clean Gas Range
