Specification Created 5/03
GE Appliances
JGBS09PEH – GE®30" Free-Standing Standard Clean Gas Range
Dimensions (in inches) and Installation Information
30
45
25-5/16*
46-1/4
36±1/4
Factory set for Natural gas. A set of
LP orifices is included with each
range for LP conversion.
Gas Self-Clean Range
Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
*Dimension from wall to front of closed door handle is 29".
Depth to front edge of cooktop – 25-1/4".
CERTIFIED
For answers to your Monogram,
® GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
All GE ranges are equipped
with an Anti-Tip device.
The installation of this
device is an important,
required step in the
installation of the range.
Specification Created 5/03
GE Appliances
JGBS09PEH – GE®30" Free-Standing Standard Clean Gas Range
Features and Benefits
• Center Oval Burner – Fifth burner in the center of the cooktop, ideal for griddle or
odd-size cookware.
• Non-Stick Griddle – Placed over a fifth center burner the griddle provides a flat,
non-stick surface for cooking and warming all types of foods.
• Sealed Cooktop Burners – Eliminate the space between the burners and the
cooktop to help contain spills and boil over liquids, ensuring easy cleanup.
• All Purpose Burners – Deliver a wide range of heat output ideal for most
cooking requirements.
• Porcelain Upswept Cooktop – Features raised edges to help contain spills and
make clean-up easy.
• Easy Clean Subtop – Porcelain enameled subtop collects spills and messes for
easy cleaning.
• Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more
items at once.
• Model JGBS09PEHWW – White on white (white door and white patterned cooktop)
