Dimensions and Installation Information (in inches)

Factory set for Natural gas. A set of LP orifices is included

with each range for LP conversion.

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before installing, consult

installation instructions packed with product for current

dimensional data.

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

330570

Specification Revised 10/08

JGBS80SEM

GE® 30" Free-Standing Standard Clean Gas Range

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

All 30" GE gas and electric range backguards

are 30-7/8" wide.*

Note: 30" ranges conform to U.L. requirements

for 0" spacing from adjacent walls below

countertops. To reduce possible scorching of

walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended,

high heat, no-load heating element operation.

*Except these models: JGBS07, JGBS04, JGBP90,

all GE Profile free-standing electric and gas

ranges

Fits most countertop backsplash applications.

Consult Use & Care Manual for detailed

installation instructions.

30-7/8"

JGBS80SEM

BROIL OVEN

LIGHT

CLOCK

TIMECONTROLS

OVENCONTROLSTrue Temp

TEMP

NORMAL

HILO OFF

KITCHEN

TIMER

ONOFF

BAKESTART

CLEAR

OFF

Features and Benefits

• Standard Clean Oven - Offers a traditional oven design that requires

hand cleaning

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking

more items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain

spills and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop, ideal for

griddle or odd-size cookware

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval

burner, for cooking multiple foods at once

• PowerBoil™Burner - Delivers 15,000 BTUs of forceful heat for rapid boiling

• Broiler Drawer - Supplies a concentrated heat for crisping and browning

• Electronic Clock - Features an easy-to-use design that allows the time to be

easily viewed

• Precise Simmer Burner - Offers a low setting of 600 BTUs, ensuring more

temperature control for simmering

• Sealed Cooktop Burners - Eliminate the space between the burners and the

cooktop to help contain spills and boil over liquids, ensuring easy cleanup

• Model JGBS80SEMSS - Stainless steel

330570

Specification Revised 10/08

JGBS80SEM

GE® 30" Free-Standing Standard Clean Gas Range
