JBP48ABAA–GE Profile™Spectra™30" Free-Standing QuickClean™Electric Range

Dimensions (in inches)

30

25

2-1/2

7-1/2

29-7/8

25-3/8*

47-5/8

44-7/16

2-1/2

Acceptable electrical

outlet area

Preferred electrical

outlet area

Roughed-in dimensions

*Dimension from wall to front of closed door handle is 27-3/8”.

R

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

For answers to your Monogram,®

GE Profile Performance Series,™

GE Profile™or GE appliance questions, call

GE Answer Center®service, 800.626.2000.

†Note: Check local codes for required breaker size.

A properly grounded branch circuit with a 3 prong grounding type receptacle is required for

GE ranges.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because terminals are not

accessible after range installation. See shaded area in drawing for location of electrical outlet box.

Recommended outlet locations allow range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent walls below

countertops. To reduce possibility of scorching of walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat, no-load heating element operation.

Installation Information: Before installing, consult installation instructions packed with product

for current dimensional data.

KW Rating

240V 11.7

208V 8.8

Breaker Size

40 Amps†

TM

Specification Revised 4/99

JBP48ABAA–GE Profile™Spectra™30" Free-Standing QuickClean™Electric Range

OVENCLEANING–

MOVEDOORLATCH TO RIGHT. TOUCH"SELFCLEAN" PAD. TOUCH"START" PAD.

OVEN LIGHT

START

OVEN TIMECONTROLS

CLEAR

OFF

KITCHEN

TIMER

ON OFF

CLOCK

SELF

CLEAN

BROIL

HI/LO

BAKE

COOKING

TIME START

TIME

LOCKED CLEAN

O

N

BROIL COOK TIMER

STOP

CLOCK CLEAN

START

DELAY

S

E

T

BAKE DOOR

S

E

T

OFF OFF OFF OFF

H

I

L

O

8

7

6

5

4

3

2

1

9

H

I

L

O

8

7

6

5

4

3

2

1

9

H

I

L

O

8

7

6

5

4

3

2

1

9

H

I

L

O

8

7

6

5

4

3

2

1

9

FRONT REAR REAR FRONT

SURFACE

UNITS

Features and Benefits

•Super Large 5.0 Cu. Ft. Oven Capacity

•Clean-Well™ Cooktop System

•Self-Cleaning Oven

•Lift-Up Upswept Porcelain-Enameled Cooktop with Dual Support Rods

•Two 8" and Two 6" Deluxe Plug-in Calrod™ Heating Elements with Warming Option

•TrueTemp™ System with QuickSet IV Oven Controls

•SmartLogic™ Oven Controls

•Removable One-Piece Drip Bowls

•Electonic Clock and Minute Timer

•Time Bake with Delay Option

•Six-Pass Power Bake Element

•2 Oven Shelves

•Auto Oven Shut-Off with Override

•Audible Preheat Signal with Light

•Heating Element "On" Indicator Light

•Dual Bake Element

•Porcelain-Enameled Broiler Pan with Chrome-Plated Grid

•Automatic Interior Oven Light

•Frameless Lift-Off Glass Oven Door with Big View Window

•Color-Matched Removable Full-Width Storage Drawer

•Sure Grip Designer-Style Handle

• Model JBP48WBWW - White on white

• Model JBP48BBBB - Black on black

• Model JBP48ABAA - Almond on almond
