GE DeluxeDoorAlarm Manuale utente

Do not use in wet locations

Personal Security

Deluxe Door Alarm

User Manual

Deluxe Door Alarm

Keypad Controlled

Low Battery Indicator

The alarm unit has a low battery circuit.

When the batteries reach a low level, the

indicator light will ﬂash slowly. Average

battery life for typical usage is up to one

year.

Battery Compartment

Learn

button

Keypad

Home/

Away

Switch

Alarm/

Chime

Switch

Indicator

Light

Magnet

Mounting Plate

Double-

sided tape

Screws LEARN

INSTALLING BATTERIES

The keypad controlled door alarm requires

three (3) AAA Alkaline batteries (not

included).

To install the batteries:

1. Remove screw from battery

compartment door located on back

of the unit. Slide off the door in the

direction of the arrow.

2. Insert three (3) AAA

batteries noting the

polarity diagram

inside the battery

compartment.

3. Replace door and

secure screw.

CREATING YOUR PERSONAL ALARM CODE

The keypad allows you to set a personal

4-digit code for arming and disarming the

alarm.

1. Remove screw from battery

compartment door located on back

of the unit. Slide off the door in the

direction of the arrow.

2. Press the LEARN button.

3. The red light on the front of the alarm

will blink for 15 seconds. During this

time, input your 4-digit code. A beep

will conﬁrm each input.

The unit will ﬂash a

green light 3 times to

conﬁrm the new 4-digit

code has been saved.

4. Replace cover and

secure screw.

Learn

button

LEARN

INSTALLATION

1. Select desired location for alarm.

The alarm is designed to mount to

the door frame or to the door itself.

Use either the provided screws (for

permanent mounting) or double-sided

tape (for temporary mounting). The

recommended location is the back of

the door, with the magnet mounted to

the door frame. Mounting the alarm

to the door ensures that the alarm

will not be damaged by opening and

closing the door.

Recommended Mounting Method Alternate Mounting Method

Note that the magnet may be

mounted to either side of the alarm as

long as the arrows line up.

Distance must be less than 1/2”

IMPORTANT: Whether mounting

to the door or door frame, the gap

distance between the alarm and

magnet must be 1/2” or less.

2. Attach the mounting plate to the

back of the alarm. Peel the protective

covering from one side of the

double-sided tape and then apply to

mounting plate. Remove protective

covering from the back side of the

double-sided tape and lightly mount

the alarm in the desired position.

Make sure the surface you are

mounting to is clean and dry. For best

results, clean the mounting surface

with a mixture of 50% isopropyl

alcohol and 50% water.

Alarm

Mounting Plate

Double-sided tape

Do not apply ﬁrm pressure until

location is ﬁnal.

NOTE: When mounting to a door

frame, the mounting plate mounts

off-center to the left or right in order

to position alarm closest to the edge

of the door.

3. Using double-sided tape, lightly

attach the magnet to the opposite

edge next to the alarm. Line up the

arrows of the alarm and the magnet.

Ensure the distance between the two

pieces is 1/2” or less. To test the gap

distance, slide the ALARM/CHIME

switch to CHIME and open the door. If

chime sounds, then the gap distance

is correct. If it does not sound, move

either the alarm or magnet closer so

that gap distance is 1/2” or less.

4. Once you have conﬁrmed the correct

positioning of the magnet and alarm,

lift the alarm off the mounting plate

and apply ﬁrm pressure directly to the

plate itself. Once secured, reattach the

alarm to the mounting plate.

5. Apply ﬁrm pressure to the magnet to

secure its position as well.

OPERATING IN THE ALARM MODE

1. Locate ALARM/CHIME switch on right

side of the alarm unit.

2. Slide switch to ALARM position.

3. Choose HOME or AWAY on the left side

of the alarm unit.

HOME MODE

In HOME mode, the alarm will sound

when the gap between the alarm and the

magnet is greater than 1/2” (i.e. the door

is opened).
