GE JVE40STSS Manuale
Specification Revised 8/11 321455
JVE40ST
GE® 30" ENERGY STAR®Qualified Ventilation Hood
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
5-15/16
29-15/16
19-1/2
12
WB02X9381 replacement grease filter and WB02X10700
replacement charcoal filter are available for additional
cost. Call toll-free 800.626.2002.
JXHC1 Cord Kit: Allows a receptacle in the cabinet over
the range to accommodate either an over-the-range
microwave oven or a standard hood.
Installation Information: Before installing, consult
installation instructions,packed with product, for current
dimensional data.Light bulb(s) not included.
Refer to this drawing for
rectangular exhaust option.
Exhaust outlet connects to 3-1/4"
x 10" rectangular duct. Vent top or
rear. Includes rectangular damper.
Refer to this drawing for round
exhaust option.
Exhaust outlet connects to 7"
diameter duct. Vent top only.
Round damper accessory. JXDA22,
available at additional cost.
Listed by
Underwriters
Laboratories
Model JV347
1/2
10
3-1/4
5-3/4
Center
line of hood
1-1/4
1-1/4 Optional power
supply connection
1-1/8" Ty p.
7-3/4
1-3/8" Ty p.
8-1/4" Ty p.
Center
line of hood
1-1/4
1-1/4 Optional power
supply connection
1-1/8" Ty p.
7-3/4
1-3/8" Ty p.
8-1/4" Ty p.
Model JVE40
1/2
10
3-1/4
Center
line of hood
1-1/4
1-1/4Optional power
supply connection
1-1/4"
7-3/4
7/8"
8-1/4" Ty p.
Amp Rating
120V 1.0
Dimensions and Installation Information (in inches)
Specification Revised 8/11 321455
JVE40ST
GE® 30" ENERGY STAR®Qualified Ventilation Hood
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
JVE40
Features and Benefits
• ENERGYSTAR qualified - Meets or exceeds federal guidelines for
energy efficiency for year-round energy and money savings
• Convertible venting - Hood designed to accommodate a vented
configuration, which channels exhaust outside of the home, or a non-
vented configuration, which filters and returns the air into the kitchen
• Vertical and rear exhaust - Hood design gives installers total flexibility
to connect the exhaust vent to your home’s duct work from either the
top or rear of the unit
• 2 Fan Speed Selections
• Cooktop light - Enjoy the convenience of light under the hood to help
you better see your cooking surface
• Removable grease filter - Durable grease filter collects the grease that
builds up from cooking and removes quickly and easily for cleaning
• Round and rectangular ducting - Designed to fit standard round and
rectangular duct work for quick and simple installation
• Rectangular damper included - Included damper keeps the vent
sealed when it is not in use, so your home’s heat doesn’t escape
• Model JVE40STSS – Stainless steel
CFM/Sones Ratings
Rear Exhaust High Speed (HS) 240/5.5
Rear Exhaust Working Speed (WS) 120/1.2
Top Exhaust (HS) 210/6.0
Top Exhaust (WS) 110/1.3
