For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Revised 7/09 360422

Listed by

Underwriters

Laboratories

Dimensions and Installation Information (in inches)

Installation Information: For complete information, see

installation instructions packed with your washer.

23 1/2” 26 5/8”

33 5/16”

POWER

START

PAUSE

SOIL

POWER

START

PAUSE

E L

SPIN

N S

E HE H

TEMP

T C

SPEEDWASH

RINSE& SPIN

DRAIN& SPIN

DELICATES

HANDWASH

WHITES/ HEAVY DUTY

WRINKLEFREE

ACTIVEWEAR

COLORS/ NORMAL

BASKETCLEAN

E R

D S

M C

Electric Dryer Rating

120V 12.0A, 60Hz

WCVH4800K/4815K

GE®2.6 IEC Cu. Ft. Capacity Frontload Washer with Stainless Steel Basket

Listed by

Underwriters

Laboratories

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Alcove or Closet Installation:

•Ifyourdryerisapprovedforinstallationinanalcoveorcloset,itwillbe

stated on a label on the dryer back.

•ThedryerMUSTbeexhaustedtotheoutside.

•Minimumclearancesbetweendryercabinetandadjacentwallsorother

surfaces are: 0" either side, 3" front and rear

•Minimumverticalspacefromfloortooverheadcabinets,ceilings,etc.is52".

•Closetdoorsmustbelouveredorotherwiseventilatedandmustcontaina

minimum of 60 sq. in. of open area equally distributed. If this closet contains

both a washer and a dryer, doors must contain a minimum of 120 sq. in. of

open area equally distributed.

•Nootherfuel-burningapplianceshallbeinstalledinthesameclosetwith

a gas dryer.

Bathroom or Bedroom Installation:

•ThedryerMUSTbeexhaustedtotheoutdoors.

•Theinstallationmustconformwiththelocalcodes,orintheabsenceof

localcodes,withtheNationalElectricCodeandNationalFuelGasCode,

ANSIZ223forgasdryers.

Minimum Clearance other than Alcove or Closet Installations:

•Minimumclearancestocombustiblesurfaces0"bothsides,3"rear.

For more information on venting kits and accessories,

please call 1-800-GE-CARES.

Stacked Dimensions (in inches)

67 5/8”

23 1/2”

23 3/4”

4”

33 1/2”

26 1/2”

26 5/8”

Specification Revised 6/09 360422

WCVH4800K/4815K

GE®2.6 IEC Cu. Ft. Capacity Frontload Washer with Stainless Steel Basket

ADJUST

TIME DRY HOLD3 SECS TO

LOCK& UNLOCK

CONTROLPANEL

POWER

STA RT

PAUSE

STIMATED

IME

EMAINING

SOIL

POWER

STA RT

PAUSE

HEAVY

NORMAL

LIGHT

EXTRALIGHT

SPIN

HIGH

MEDIUM

LOW

NOSPIN

EXTRAHIGH

EXTRAHEAVY

TEMP

HOT

SANITIZE

WARM

COLD

TAPCOLD

SPEED WASH

RINSE &SPIN

DRAIN &SPIN

DELICATES

HAND WASH

WHITES / HEAVYDUTY

WRINKLE FREE

ACTIVE WEAR

COLORS / NORMAL

BASKETCLEAN

BLEACHONLY

EXTRARINSE

DELAY STA RT

SIGNAL

HOLD3 SECS TO

LOCK& UNLOCK

CONTROLPANEL

MY CYCLE

HOLD3

SECONDS

TOSTORE

WASH RINSEPRE SPINEXTRA

DOOR LOCKED

DELAY

Features and Benefits

•ENERGYSTAR®Qualified-Meetsorexceedsfederalguidelinesforenergyefficiencyfor

year-roundenergyandmoneysavings

•HydroMotion™WashAction-Reversingwashactionoffersgreatcleaningperformance

with gentle wash motion

•HydroHeater™-Increaseswashtemperaturetoreducebacteriaandprovidebetter

cleaning for the really tough stains

•5Wash/SpinSpeedCombinations-Washeralternatesspeedsforgreatclothescare

•MultipleWashCycles-Choosefromvariouswashactionsforoptimalcleaningand

clothes care

•5Wash/RinseTemperatureswithSanitize-MultiplesettingsandaSanitizewashoffer

a greater degree of control over fabric cleaning and care

•AutomaticWaterLevels-Reducewaterwastepercyclebyfillingonlyenoughwaterto

match the load size

•DelayStartUpTo18Hours-Setthewasherordryertobegincyclesanytimeinthe

next18hours

• ModelWCVH4800KWW–Whiteonwhite

• ModelWCVH4815KMS–MetallicSilver

Specification Revised 7/09 360422

WCVH4800K/4815K

GE®2.6 IEC Cu. Ft. Capacity Frontload Washer with Stainless Steel Basket

Modified Energy Factor (MEF) 2.30

Water Factor (WF) 4.33
