Geberit AquaClean 8000plus

Operating

instructions

Operating instructions Geberit AquaClean 8000plus

For true well-being .................................................................................................. 4

Added value for health and well-being.............................................................................. 4

Easy to operate................................................................................................................ 4

Any questions about Geberit AquaClean? ........................................................................ 4

Warranty card registration ................................................................................................ 4

Environment..................................................................................................................... 4

Important notes ...................................................................................................... 5

Intended use.................................................................................................................... 5

Declaration of conformity ................................................................................................. 5

For your safety ................................................................................................................. 5

Operation......................................................................................................................... 5

Explanation of symbols .................................................................................................... 5

Geberit AquaClean 8000plus operation .................................................................. 6

Overview of controls ........................................................................................................ 6

Control panel ................................................................................................................... 6

Geberit AquaClean 8000plus remote control.................................................................... 7

Additional functions of the Geberit AquaClean 8000plus remote control........................... 8

Integrated control panel ................................................................................................. 10

Using Geberit AquaClean 8000plus ................................................................................ 11

Using the lady shower..................................................................................................... 12

What you should know ......................................................................................... 13

Spray shield ................................................................................................................... 13

Storing the remote control ............................................................................................. 13

WC seat and lid with lowering function........................................................................... 13

User-defined settings ............................................................................................ 14

Saving user profiles......................................................................................................... 14

Basic settings ................................................................................................................. 15

Restoring the factory setting ........................................................................................... 15

Care and cleaning ................................................................................................ 16

Care instructions ............................................................................................................ 16

Components.................................................................................................................. 16

Permissible cleaning agents and cleaning equipment ..................................................... 17

Non-permissible cleaning agents and cleaning equipment ............................................. 18

Tips................................................................................................................................ 19

Cleaning the WC seat, WC lid and casing ....................................................................... 20

Cleaning the hinges, the cover, the dryer arm and the spray arm .................................... 20

Cleaning the WC ceramic appliance................................................................................ 21

Troubleshooting ................................................................................................... 22

Malfunctions during operation ........................................................................................ 22

Replacing the remote control batteries ............................................................................ 24

Replacing the active carbon filter..................................................................................... 25

Refilling nozzle cleaner .................................................................................................... 26

Replacing the spray nozzle and cleaning the opening of the spray arm ........................... 27

Replacing the dryer arm and cleaning the opening of the dryer arm ................................ 28

Removing and fitting the WC seat and WC lid ................................................................. 29

Technical data ...................................................................................................... 30

End user warranty ................................................................................................ 31

Operating instructions Geberit AquaClean 8000plus

For true well-being

The Geberit AquaClean 8000plus is a toilet which reclaims the source of freshness

and cleanliness: water. A single water jet cleans your bottom with a pleasant and

gentle feel. Application is simple yet effective. Toilet paper, a towel or the integrated

dryer can be used for drying.

Added value for health and well-being

Additional functions like the oscillating spray, the lady shower for natural cleansing of

the sensitive female genital area, a pulsating massage spray, warm air dryer, remote

control or memory function round off this shower concept.

Easy to operate

Operation is effortless, requiring you simply to either press the clearly labelled buttons

on the side of the unit or use the remote control, via which you can also call up your

personal settings.

Any questions about Geberit AquaClean?

Our after-sales team will be happy to respond to your enquiries.

Please contact your responsible Geberit sales company.

Warranty card registration

So that we can provide you with optimum support, please take the opportunity to

to no time to complete.

• www.i-love-water.com

Environment

This product meets the requirements of the EU directive "Restriction of Hazardous

Substances" (2002/95/EC). It is largely free from hazardous substances such as lead,

mercury, cadmium and chrome VI, which are environmental pollutants.

All old Geberit AquaClean 8000plus can be returned to Geberit free of charge for

proper disposal. This arrangement applies to all EU member states as well as to

Switzerland and Norway. Equipment can be returned to the responsible Geberit sales

company (see the website of your respective country for the address).

Operating instructions Geberit AquaClean 8000plus

Important notes

Intended use

The Geberit AquaClean 8000plus is a toilet which is also designed for cleansing the

anal area and, with the lady shower, for cleansing the vaginal area. Its use for any other

purpose is deemed improper. Geberit accepts no liability for the consequences of

improper use.

Declaration of conformity

You can obtain a copy of the declaration of conformity from your responsible Geberit

sales company.

For your safety

• In the event of evidence of damage to the Geberit AquaClean, disconnect the unit

from the mains immediately and contact Geberit Customer Service.

• If the mains connection cable is damaged, it must be replaced by a skilled person.

• Never open and repair the Geberit AquaClean yourself. Do not modify the unit or

add any additional modules. The Geberit AquaClean contains live parts. Opening

the unit exposes those present to fatal danger.

• Repairs may only be carried out by trained and authorised skilled persons using

original spare parts and accessories.

• The Geberit AquaClean must only be connected to a mains voltage conforming to

the specification plate. The specification plate is located behind the maintenance

flap. You will find more technical data in the chapter titled "Technical data".

Operation

• People who are not familiar with the Geberit AquaClean 8000plus, especially

children, must be shown how to use it.

• Everyone's temperature sensitivity is different. Please always check the dryer and

water temperature settings before using the Geberit AquaClean 8000plus.

• Operation and maintenance work may only be performed by the operator or user

as described in these operating instructions.

• The Geberit AquaClean 8000plus may only be operated with drinking water.

Explanation of symbols

DANGER

Refers to a potentially dangerous situation that may cause serious injury or

death.

Refers to important information.

Operating instructions Geberit AquaClean 8000plus

Geberit AquaClean 8000plus operation

Overview of controls

Control panel

1 Control panel

2 Power switch

3 Active carbon filter compartment

4 Maintenance flap

5 Serial number

6 Filling tray for nozzle cleaner

7 Cleaning instructions for end users

8 Spray arm

9Dryerarm

10 User detection

8899

1010

1Sprayintensity

2 LED displays

3 Odour extraction unit

4Drying

5 Start and stop shower

6 Remote control compartment

Operating instructions Geberit AquaClean 8000plus

Geberit AquaClean 8000plus remote control

Additional functions of the Geberit AquaClean 8000plus remote control

You can use the remote control to call up all of the additional functions or to make and

save personal settings. To activate the remote control, touch any button once. The

display appears. The display switches off automatically 10 min after use.

Display

D1 Shower water / dryer air temperature display

D2 Dryer temperature

D3 Service icon

D4 Water heater function status indicator

D5 Nozzle cleaner refill icon

D6 Filter replacement symbol

D7 Odour extraction unit

D8 Drying

D9 Spray arm position

D10 Oscillating spray

D11 Massage spray

D12 Spray intensity

D13 Error icon

D14 Activated user profile I/II/III/IIII

Buttons

1 <Shower>, start and stop

2 <Spray intensity ->, reduce

3 <Spray intensity +>, increase

4 <Odour extraction unit>

5<Drying>

6 <Oscillating spray>, start and stop

7 <Spray arm position> forwards and

backwards

8 <Service>

9 <Shower water / dryer air temperature>

10 <Water heater function>

ON/economy mode/OFF

11 <Massage spray>, start and stop

12 <User profiles I/II/III/IIII>, on and off

13 <Lady shower>

D12

D14

D11

D13

D10 D9 D8

D1 D2

The Geberit AquaClean 8000plus with visible cistern supports three user profiles.

This version also supports a <toilet flush> button for activating the toilet flush.

Operating instructions Geberit AquaClean 8000plus

The low spray intensity has a pleasant and gentle feel whilst cleaning.

Press the button: The spray arm moves into position and the shower

procedure starts. The shower stops after 20 s. You can stop the

shower before this by pressing the <shower> button.

Press the button: Triggers a full flush

(Geberit AquaClean 8000plus with visible cistern).

Press the button: The user profile is activated with its saved settings.

The pulsating massage spray is pleasant and relaxing.

Press the button: The massage spray is activated. The function can be

activated before or during the shower procedure.

Press the button again: The massage spray is deactivated.

To suit your sitting position, the spray arm can be moved forwards or

backwards through 7 positions in accordance with the directions

shown on the arrow button.

Press the button: Sets the position of the spray arm.

The oscillating spray intensifies cleaning efficiency.

Press the button: The oscillating spray is activated. The function can be

activated before or during the shower procedure.

The spray arm moves back and forth.

Press the button again: The oscillating spray stops.

Press the button:

• : Heating element is switched on. The water temperature is preset

to 37 °C

• : Economy mode (factory setting). In economy mode, the heating

element only switches on if user detection is activated. The warm-up

time is 3 to 4 minutes.

• : Heating element is switched off.

Sets the required shower water temperature.

Press the button: Increase or reduce temperature.

Sets the required dryer air temperature.

Prerequisite: Select the drying function.

Press the button: Increase or reduce temperature.

Operating instructions Geberit AquaClean 8000plus

To deactivate the spray functionality for manual cleaning or for

changing the spray nozzle or dryer nozzle.

Press the button: The spray arm / dryer arm extends but is not in

operation.

See chapter "Troubleshooting" for more information.

Geberit AquaClean 8000plus for concealed cisterns:

• Press the actuator button on the actuator plate on the wall (large actuator button

for full flush, small actuator button for partial flush)

Geberit AquaClean 8000plus with visible cistern:

• Press the actuator button on the cistern (large actuator button for full flush, both

actuator buttons for partial flush) or

• Press the <toilet flush> button on the remote control (full flush)

Operating instructions Geberit AquaClean 8000plus

Integrated control panel

<Shower>, starting and stopping

Press the button: The spray arm moves into position and the

shower procedure starts. The shower automatically stops

after 20 s.

You can stop the shower before this by pressing the

<shower> button.

Press the button again: The shower stops.

Adjust the sliding button during the shower procedure to

change the spray intensity of the anal shower or the lady

shower.

There are 7 spray intensity levels to choose from.

Prerequisite: Odour extraction unit is switched on.

The odour extraction unit starts as soon as someone sits

down on the toilet.

Press the button: The odour extraction unit stops.

Press the button again: The odour extraction unit starts.

Prerequisite: Drying is activated.

Drying starts after the shower procedure and stops as soon

as you stand up. You can interrupt drying before this by

pressing the <drying> button.

Press the button: Drying stops.

Press the button again: Drying starts.

Blue LED Meaning

Lights up Heating element is switched on. In economy mode (factory

setting), the heating element only switches on if user

detection is activated. The warm-up time is 3 to 4 minutes.

Does not light up Heating element is switched off

Red LED Meaning

Lights up Replace active carbon filter or refill nozzle cleaner

Flashing Error message (see "Troubleshooting")

Altri manuali per AquaClean 8000plus

Indice

Altri manuali Geberit Aspirapolvere

Geberit

Geberit Pluvia Manuale utente

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
