GECKO® DESTINY EQ 260

OWNER'S MANUAL

www.geckomusicgroup.com

SAFETY INSTRUCTIONS & SYMBOLS GUIDE

For your own safety and to avoid invalidation of the warranty, all text marked with these symbols should be

read carefully.

SYMBOLS:

SAFETY INSTRUCTIONS:

•To reduce the risk of electrical shock, do not remove covers. No user-serviceable parts inside. Please

refer servicing to qualified personnel.

•To reduce the risk of electrical shock or fire, do not expose the equipment to rain or moisture.

•Do not impose unnecessary stress on your equipment (i.e. placing heavy objects on it, over screwing its

mounting, etc).

•Read and keep the instruction manuals in a safe place for future references.

•Do not attempt to clean the equipment with chemical solvents as this may damage the finish. Clean only

with a dry cloth.

•Do not block any ventilation openings.

•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that

produce heat.

•Do not defeat the purpose of the polarized or grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the grounding prong is provided for your safety. If the provided plug does not fit into your outlet,

consult an electrician for the replacement of the obsolete outlet.

•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

• Unplug the apparatus during lightning storms or when it is not in use for a long period of time.

NOTES

Contain important information and useful tips on the operation of your equipment.

WARNING

The lightning flash with arrowhead symbol within an equilateral triangle, is intended to

alert the user to the presence of uninsulated dangerous voltage within the product’s

enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

CAUTIONS

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in thee

literature accompanying the appliance. Please read the manual carefully.

HEADPHONES

EADPHONES

SAFETY

WARNIN

WARNING

Contain important information and use

useful tips for headphones outputs and monitoring

levels.

•Use only attachments/accessories specified by the manufacturer.

•Always shut down power supply when not in use to save energy and for a prolonged lifespan.

•Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary

considerably in susceptibility to noise-induced hearing loss, but nearly everyone will lose some hearing if

exposed to sufficiently intense noise for a period of time. The U.S. Government’s Occupational Safety

and Health Administration (OSHA) and the Singapore Workplace Safety and Health Council (WSHC)

has specified the permissible noise level exposures shown in the following chart. According to OSHA

and WSHC, any exposure in excess of these permissible limits could result in some hearing loss. To

ensure against potentially dangerous exposure to high sound pressure levels, it is recommended that all

persons exposed to equipment capable of producing high sound pressure levels use hearing protectors

while the equipment is in operation. Earplugs or protectors in the ear canals or over the ears must be

worn when operating the equipment in order to prevent permanent hearing loss if exposure is in excess

of the limits set forth here:

Duration/Day (Hours) dB, Sound Pressure Level (SPL) Descriptions

Below 90dB Safe zone

8.00 90 Hearing damage

6.00 92

4.00 95

3.00 97

2.00 100 Serious hearing damage

1.50 102

1.00 105

0.50 110

0.25 or less 115 Human pain threshold

GECKO MUSIC GROUP

Singapore | Malaysia | Taiwan | Philippines | Canada

Email: [email protected] • Website: www.geckomusicgroup.com

FOREWORD

Dear Friends,

Thank you very much for purchasing quality products by GECKO MUSIC GROUP. I am very grateful that we

have journeyed this far, since 2002! We have set new audio standards in the industry and we have touched

and changed lives along the way! I believe our journey will not stop but continue to pursue more

breakthrough findings and improvements that will change our lives for the better.

At GECKO MUSIC GROUP we focus on developing nothing but the best professional audio equipment and

premium grade audiophile products you ever need! Our engineering team is constantly doing R&D to meet

this goal. I thank God that by His grace, we have succeeded in developing the revolutionary C.R.I.S.T.A.L.®

technology that has changed and is changing the way how audio is captured, encoded, reproduced and

managed!

On behalf of GECKO MUSIC GROUP, I would like to pledge our continuing commitment to uphold our

traditions in serving the music and audio communities around the world with more value-added premium

quality GECKO® professional audio equipment and premium grade audiophile products!

Once again, thank you very much for your support. We trust you will love what you hear!

Yours truly,

Dr. Daniel Foo

Founder/Director (R&D)

GECKO MUSIC GROUP

TABLE OF CONTENTS

INTRODUCTION 3

CHAPTER 1. GETTING STARTED 4

CHAPTER 2. EDITING FUNCTIONS 7

CHAPTER 3. SYSTEM SECURITY 14

CHAPTER 4. DETAILED PARAMETERS 21

SPECIFICATION 41

WARRANTY 42

NOTES: Congratulations on purchasing the GECKO® DESTINY EQ

260 speaker management system! We recommend that you take a

moment and read through the manual as it provides information that

will aid you in using your unit to its fullest potential.

______________________________________________________________________________________

INTRODUCTION

The GECKO® DESTINY EQ 260 is a complete equalization and speaker management system which offers a

redefined high standard audio signal processing; delivering the best out of your quality sound system.

Equipped with forty carefully pre-designed programs, the DESTINY EQ 260 is purpose-built to accommodate

virtually any sound reinforcement and installation application through quality, state-of-the-art, 24-bit, 48kHz

processor, while all editing functions and configuration possibilities of the EQ 260 can be performed by

utilizing the onboard user-friendly and intuitive function buttons. Coupled with the user interface LCD display,

complete and flexible editing performance is achieved in a simple and convenient way.

Apart from the 24-bit, 48kHz codec, the GECKO® DESTINY EQ 260 also offers two independent channels

of highly-precise 28-bit DSP processing power with a linkable 28-band graphic equalizer, incorporating

GECKO® Stereo Compressor Module (GSCM)™, notch filters, feedback eliminator, parametric equalizers,

limiters, bandpass filters, noise gates, automatic gain control, and alignment delay functions.

In order to protect all your detailed parameter editing and configuration modification settings of your

GECKO® DESTINY EQ 260, the unit is equipped with a robust Security System Setup (SSS), incorporating

security features such as program locking, account changing, system locking and password changing.
