IMPORTANT：Read the instructions
carefully before operating the appliance
and keep them for future reference.
Model No.: L7
User Manual
ROBOT VACUUM CLEANER
01
03
10
22
27
Table Of Contents
Safety Instructions
Product Components
How To Use
Cleaning And Maintenance
Troubleshooting
Scan the QR code for more
assistance and support
GeekSmart bids you welcome to a world of smart homedevices, the
robot vacuum ceaner. GeekSmart strives to explore and develop the smart
home industryfor the good of all by combining cutting-edge technologies to
develop products fit and ready for the market. Please visitourwebsite
www.geektechnology.com.
Before use, please scan the QR codes to watch oureasy step-by-step
installation video. If you have questions regarding the installation process,
phone 1-844-801-8880 / (862) 352-0406.
welcome
01
WARNING: TO REDUCE THE RISKOFINJURY ORDAMAGE, READ THEFOLOWING
SAFETY PRECAUTIONS WHENSETTINGUP, USINGAND MAINTAINING YOUR ROBOT.
This product is designed for indoor floor cleaning only, do not use it outdoors
(such as on an open-ended terrace), on any surface other than the ground
(such as a sofa ) , or in any commercial or industrial environment.
Do not use this product on elevated surfaces without barriers such as the
floor of a loft, an open-ended terrace.
Do not use the product when the ambient temperature is higher than 104°F
(40°C) , lower than 39°F (4°C), or if there are liquids or tacky substances on
the floor.
side to prevent them being pulled on by the cleaner.
To prevent blocking the product and to avoid damage to valuables, remove
light-weight items (such as plastic bags) and fragile objects (such as vases)
from the floor before cleaning.
Children should be supervised to ensure that they do not play with the
appliance.
This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the product by a person responsible for their safety .
This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the product in a safe way and understand the hazards
involved. Children shall not play with the product. Cleaning and user mainte-
nance shall not be made by children without supervision (EU).
Keep the main brush cleaning tools out of reach of children.
Do not place any object (including children and pets) on the product ,
whether it is in operation or not.
Keep hair, loose clothing , fingers,and all parts of the body away from open-
ings and moving parts.
Do not use the product on burning objects (such as cigarette butts).
Safety Instructions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
lmportant Safety lnstructions
Safety Instructions
Battery and Charging
02
be reduced on dark carpets).
Do not use the product to clean hard or sharp objects (such as decoration
wastes, glass and nails).
socket-outlet before cleaning or maintaining the product.
Do not use wet cloth or liquids for cleaning the product.
Do not use the mopping module on carpets.
Use the product according to the manual, Any loss or damage caused from
improper use will be borne by the user.
This product contains batteries that are only replaceable by skilled persons.
Do not charge non-rechargeable batteries.
For the purposes of recharging the battery, only use the detachable supply unit
robot provided with this product.
Do not dismantle, repair or modify the battery or charging dock.
Keep the charging dock away from heat (such as heating vents).
The battery must be removed from the appliance before it is scrapped.
The product must be disconnected from the power supply when removing the
battery.
The battery must be disposed of safely. Do not discard waste batteries, leave
them with a professional recycling organization.
Do not wipe or clean the charger prongs with wet cloth or wet hands.
If the power cord is damaged, stop using it immediately. It must be replaced by
the manufacturer, service agent, or similarly qualified persons to avoid a hazard.
Immediately dispose of packaging as it can pose choking
or other hazards to small children and pets. Please carefully
confirm the consistency between the picture and the real
components that correspond to the model you purchased.
13.
14.
15.
16.
17.
18.
19.
20.
1.
3.
2.
4.
5.
6.
7.
8.
9.
CAUTION
03
Robot vacuumcleaner
(main brush x1and side brush x2)
Charging dock
Adapter
Electricalwater tank
(Primary filter x1HEPA filter x1Spongex1)
Dust bin
(Primary filter x1HEPA filter x1Spongex1)
Remote control(“Optional”)
AAA Batteryfor remote control ×2
User manual
Cleaning tool
Product components
OPEN
Product Components
What’s in the Box
Product Components
04
Bottom View
Power/Auto cleaning/Pause
Recharge
Height sensor
Laser Distance sensor
Anti-collision bumper
Speaker
Power switch
Dust bin
Charging metal
Contact piece
Charging metal
Contact piece
Omnidirectional wheel
Side brush
Battery cover
Back wheel
Main brush
Dustbin
Side brush
Back wheel
Top View
Robot
Docking Station
Dust Bin
Power indicator
Charging contacts
Power Socket
Cable lines collect slot
Anti-slip mat
Primary filter
Sponge filter Hepa filter
Dust bin cover
Dust bin button
Dust bin block slice
Dust bin unit
Product Components
05
Auto cleaning
Direction forward
Left direction
Spot cleaning
Seek the robot
Suction power
Water tank cover
Sponge filter
Primary filter
Water tank latch
Water flow control
Edge cleaning
Right direction
On/Pause button
Recharge button
Product Components
06
Remote Contro(“Optional”)
Water Tank
OPEN
Water tank unit
Water tank button
07
Product Components
Remark: Storage temperature 0-45℃
Name Parameter
L320*W320*H95mm
14.8V
32w
2600mAh Li-battery
19V
1A
Size
voltage
Battery
Charging base output current
Charging base Output voltage
Rated power
The Robot Parameters
