2005 Owner’s Manual
GEM Owner’s Manual - Page 1
Introduction
CONTENTS
About this Manual ........................................................................2
Cautions, Warnings and Notes ....................................................3
GEM Owner’s Manual - Page 2
ABOUT THIS MANUAL
Thank you for purchasing your GEM. Your vehicle is designed to
operate exclusively on battery power. It is an emission free vehicle.
The ideal application for a battery-powered vehicle occurs when the
daily driving pattern is predictable and the distance is short.
Customer safety and satisfaction is of genuine concern to GEM.
For this reason, we have supplied you with this Owner’s Manual
designed to acquaint you with the proper and safe use of your GEM
vehicle. Please take the time to read and understand the manual
before operating your vehicle. The Owner’s Manual has been
designed for your enjoyment and safety. Maintenance schedules and
general care instructions are included.
This manual is applicable to all four of the GEM models: The GEM
e2 (Two Passenger NEV), GEM e4 (Four Passenger NEV), GEM
eS (Two Passenger Short-back NEV), and the GEM eL (Two
Passenger Long-back NEV).
Introduction
GEM Owner’s Manual - Page 3
If questions arise after reading the manual, contact GEM Customer
Service at 1-866-764-0616. Please have your Vehicle Identification
Number (VIN) and date of purchase information available.
NOTE: All information and specifications in this Owner’s Manual
are current at the time of printing. However, due to GEM’s policy
of continuous product developm2ent, we reserve the right to make
changes, at any time, without written notice or obligation.
CAUTIONS, WARNINGS, AND NOTES
Throughout this book you will find the words “WARNING!” and
“CAUTION!” These serve as reminders to be especially careful.
“WARNING!” indicates an immediate hazard, which could result in an
accident causing bodily injury. “CAUTION!” identifies something that
could result in damage to your vehicle. You will also find information
preceded by the word “NOTE.” Notes are for your information and
make procedures more easily understood.
Introduction
GEM Owner’s Manual - Page 4
Vehicle Identification and Specifications
CONTENTS
Vehicle Information ......................................................................5
General Specifications .................................................................6
GEM Owner’s Manual - Page 5
VEHICLE INFORMATION
Figure 1 - VIN/Certification Label Location
For both the two and four-passenger model vehicles, the vehicle
identification number (VIN) can be found on the VIN/Certification
Label, located on the left rear, inside portion of the vehicle roof
panel. The VIN indicates the model year, the model type and the
serial number of the vehicle.
NOTE: Be sure to record the Vehicle Identification Number in the
space provided.
0001
1
0023
Vehicle Identification and Specifications
Vehicle Identification Number (VIN):
__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|
Key # ___________
Optional Pak # _______________
Date purchased: _____ /_____ /_____
GEM Owner’s Manual - Page 6
GENERAL SPECIFICATIONS
GEM e2 Specifications
Motor: 72-volt shunt GE motor
Transmission: Front wheel drive direct -
couple Dana Spicer differential
Speed Control: GE solid state controller with:
* Motor thermal protection
* Battery under-voltage protection
* Regenerative brakes
* Top speed regulation
Tire: 10” Two-ply street and turf rated tires
Battery Pack: Six 12-volt flooded or gel batteries
Secondary Power Supply: Dual output 30A DC/DC converter
On Board
Charger: Proprietary 72-volt DC charger
110-volt AC house current
Width: 55 inches
Length: 99 inches
Height: 68 inches
Turning Radius: 12’ 3”
Wheelbase: 72 inches
Curb Weight: 1078 lb.(EMPTY)
GVW: 1600 lb.(LOADED)
Vehicle Identification and Specifications
GEM Owner’s Manual - Page 7
GENERAL SPECIFICATIONS
GEM e4 Specifications
Motor: 72-volt shunt GE motor
Transmission: Front wheel drive direct -
couple Dana Spicer differential
Speed Control: GE solid state controller with:
* Motor thermal protection
* Battery under-voltage protection
* Regenerative brakes
* Top speed regulation
Tire: 12” Two-ply street rated tires
Battery Pack: Six 12-volt flooded or gel batteries
Secondary Power Supply: Dual output 30A DC/DC converter
On Board
Charger: Proprietary 72-volt DC charger
110-volt AC house current
Width: 55 inches
Length: 128 inches
Height: 70 inches
Turning Radius: 16’ 6”
Wheelbase: 102 inches
Curb Weight: 1271 lb.(EMPTY)
GVW: 2100 lb.(LOADED)
Vehicle Identification and Specifications
GEM Owner’s Manual - Page 8
GENERAL SPECIFICATIONS
GEM eS Specifications
Motor: 72-volt shunt GE motor
Transmission: Front wheel drive direct -
couple Dana Spicer differential
Speed Control: GE solid state controller with:
* Motor thermal protection
* Battery under-voltage protection
* Regenerative brakes
* Top speed regulation
Tire: 12” Two-ply street rated tires
Battery Pack: Six 12-volt flooded or gel batteries
Secondary Power Supply: Dual output 30A DC/DC converter
On Board
Charger: Proprietary 72-volt DC charger
110-volt AC house current
Width: 55 inches
Length: 108 inches
Height: 70 inches
Turning Radius: 12’ 3”
Wheelbase: 72 inches
Curb Weight: 1140 lb.(EMPTY)
GVW: 1850 lb.(LOADED)
Vehicle Identification and Specifications
GEM Owner’s Manual - Page 9
GENERAL SPECIFICATIONS
GEM eL Specifications
Motor: 72-volt shunt GE motor
Transmission: Front wheel drive direct -
couple Dana Spicer differential
Speed Control: GE solid state controller with:
* Motor thermal protection
* Battery under-voltage protection
* Regenerative brakes
* Top speed regulation
Tire: 12” Two-ply street rated tires
Battery Pack: Six 12-volt flooded or gel batteries
Secondary Power Supply: Dual output 30A DC/DC converter
On Board
Charger: Proprietary 72-volt DC charger
110-volt AC house current
Width: 55 inches
Length: 144 inches
Height: 70 inches
Turning Radius: 16’ 6”
Wheelbase: 102 inches
Curb Weight: 1192 lb.(EMPTY)
GVW: 2300 lb.(LOADED)
Vehicle Identification and Specifications
