Gembird IS-BR Manuale utente
Broadband router
Broadband 1xWAN and 4(8)xLAN
10/100Mbps ports router
Broadband router
Disclaimer
We spared no efforts to make sure that the information in this manual is correct and
complete. However no liability is accepted for any errors or omissions. Gembird
Electronics reserves the right to change the specifications of the hardware and
software described in this manual without prior notice.
No part of this manual may be reproduced, transmitted or translated in any language
in any form, by any means, without the prior written permission of Gembird
Electronics Ltd.
Gembird Electronics makes no warranties for damages resulting from corrupted or
lost data due to a mistaken operation or malfunction of the product, the software,
personal computers or peripheral devices.
Gembird® is a registered trademark of GMB Tech (Holland) bv.
Other names or products not mentioned above may be registered trademarks or
trademarks of their respective owners.
Copyright © 2007 Gembird Electronics Ltd. All rights reserved.
Broadband router
Introduction
Thank you for buying the Gembird® Broadband router! This manual will help you
install and use it properly.
This product is specifically designed for Middling and Small Corporation needs. It
provides a complete solution for Internet surfing and corporation resources sharing, and it
is easy to configure and operate for even non-technical users. Instructions for installing
and configuring this product can be found in this manual. Before you install and use this
product, please read this manual carefully for full exploiting the functions of this product.
Just connect your DSL or Cable Modem to the Router, and all the computers in your
home or office can share the Internet -- all at the same time. The built-in 4-port switch lets
you attach seven local PCs directly, or daisy-chain out to more hubs and switches as your
network grows.
Once your computers are connected to the Internet through the Router, they can
communicate with each other too, sharing resources and files. All your computers can print
on a shared printer connected anywhere in the building. And you can share all kinds of files
between computers -- music, digital pictures, and other documents.
IS
-
BR
Use
r
manual
Broadband router
Features
Share your broadband Internet connection among 4 computers
Built-in DHCP server for automatic configuration of LAN IP addresses
Built-in powerful firewall preventing your LAN from attacks via Internet
Built-in WEB-server providing interface for easy installation and management
Supports PPPoE Auto-connect and Auto-disconnect
Supports NAT & IP routing
Broadband router
Specifications
Supports 1xWAN and 4(8)xLAN 10/100Mbps ports
Supports DHCP/Static IP/PPPoE/PPTP/L2TP client
Supports IP Filter, URL Filter, Port Filter and MAC Address Filter
Supports TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP, ARP Protocols
Supports Time Schedule, MAC Address CLONE, Static Route, Dynamic DNS
Supports UPnP, Virtual Server and Port Mapping
Supports DMZ host, VPN Passthrough for IPSec, PPTP and L2TP Protocols
Built-in network diagnostics tools
Supports Remote and Web Management
Supports security logs
Dimensions: 145x92x35mm
Product weight: 165g
Power supply adapter: 9VDC, 1A
Consumption: up to 12W
Storage conditions: temp. -40...70 Celsius degrees, humidity: 5-90% RH
non-condensing
Operating conditions: temp. 0...40 Celsius degrees, humidity: 10-90% RH
non-condensing
Broadband router
System requirements
DSL/Cable modem
10M, 100M or 10/100M Ethernet card on each PC
TCP/IP network protocol for each PC installed
RJ45 twisted-pair cables, patch cords
Internet browser Microsoft IE4.0 (or Netscape Navigator 4.0) or later
Package Contents
Broadband router
Power adapter
Software CD
User manual
Broadband router
Hardware Installation
Typical Installation
Multifunction Broadband Router connection
1. Make sure all devices, including your PCs, modem, and Router, are powered
down
2. Using an Ethernet network cable, connect the LAN or Ethernet network port of
the cable or DSL modem to the Router’s WAN port
Broadband router
3. Connect an Ethernet network cable to your PC’s Ethernet network adapter
4. Connect the other end to one of the Router’s Ethernet LAN ports (1, 2, 3, 4)
5. Repeat Steps 3 and 4 for every PC you wish to connect to the Router. If you are
connecting more than seven PCs to the Router, then you will need to connect a
hub or switch to any of the Router’s Ethernet LAN ports
6. Power on the cable or DSL modem, and power on the PC you wish to use to
configure the Router
7. Connect the included power adapter to the Router. And connect the other end of
the adapter to an electrical outlet
Broadband router
LED indicators
POWER (green)
The LED illuminates when the router is powered on.
RUN (green)
The LED is flickering when the router is working.
WAN (green)
The Link/Act LED serves two purposes. If the LED is continuously illuminated,
the Router is successfully connected to a device through the corresponding port.
If the LED is flickering, the Router is actively sending or receiving data over that
port.
Broadband router
LAN 1, 2, 3, 4 (green)
The Link/Act LED serves two purposes. If the LED is continuously illuminated,
the Router is successfully connected to a device through the corresponding port.
If the LED is flickering, the Router is actively sending or receiving data over that
port.
