Gemini CLI

Telephone

MODEL 9335

OPERATING INSTRUCTIONS

General Note:

When power is switched on or batteries are inserted, the display will be blank

until the Handset is lifted or the Handsfree button is pressed.

CONTENTS

THE FEATURES OF YOUR TELEPHONE...........................................................................6

1. IMPORTANT NOTES........................................................................................................7

INTENDED USE..........................................................................................................7

TELEPHONE FACILITIES..............................................................................................7

HANDSFREE SPEAKING..............................................................................................8

EMERGENCY CALLS...................................................................................................9

2. INSTALLATION...............................................................................................................10

POWER SUPPLY OR BATTERIES ...............................................................................10

COMPATIBLE PABX’S..............................................................................................11

PABX RECALL ........................................................................................................11

PABX ACCESS........................................................................................................13

VOICE MESSAGING .................................................................................................13

AUTOMATIC CENTREX EXTERNAL CODE INSERTION...................................................15

CONNECTION..........................................................................................................16

WALL MOUNTING.....................................................................................................16

3. TELEPHONE FEATURES ..............................................................................................18

LIQUID CRYSTAL DISPLAY (LCD)...............................................................................19

MUTE BUTTON ........................................................................................................21

PAUSE BUTTON.......................................................................................................21

RECALL ..................................................................................................................21

TIMER.....................................................................................................................21

RINGER INDICATOR .................................................................................................22

RINGER VOLUME SWITCH.........................................................................................22

RINGER PITCH CONTROL .........................................................................................23

DATA JACK ..............................................................................................................23

ELECTRONIC VOLUME CONTROL ..............................................................................23

RESET BUTTON.......................................................................................................23

MEMORY STORES....................................................................................................23

DIRECTORY ............................................................................................................24

DIRECT ACCESS MEMORY BUTTONS.........................................................................24

CALLS MEMORY ......................................................................................................24

REDIAL MEMORY.....................................................................................................25

IMPORTANT NOTE REGARDING MEMORY STORAGE....................................25

4. OPERATING INSTRUCTIONS .......................................................................................26

SETTING THE DATE / CLOCK.................................................................................26

CONTRAST SELECTION............................................................................................27

MANUAL DIALLING ...................................................................................................27

HANDSET / HEADSET / HANDSFREE OPERATION.......................................................27

ANSWERING A CALL.................................................................................................27

HANDSFREE AND HEADSET DIALING.........................................................................28

MEMORY DIALLING ..................................................................................................28

DIRECTORY MEMORIES............................................................................................30

To store a Directory memory.................................................................................30

To access the Directory.........................................................................................30

To edit a Directory memory...................................................................................30

To delete a Directory memory...............................................................................31

To call a Directory memory....................................................................................31

DIRECT ACCESS MEMORIES.....................................................................................32

To store a Direct Access memory..........................................................................32

To clear the Direct Access memory.......................................................................33

CALLS MEMORY ......................................................................................................34

Calls memory - how it works.................................................................................34

Calls Information...................................................................................................34

To store a Call memory to Directory Memory........................................................35

To store a Call Memory to Direct Access memory ................................................35

Viewing the Calls Directory ...................................................................................36

Deleting the Calls memory....................................................................................36

To remove the Message Waiting Prompt and Envelope Icon manually. ...............37

REDIAL MEMORY.....................................................................................................37

Viewing the Redial Information .............................................................................37

Deleting the Redial memory..................................................................................38

5. MAINTENANCE AND PROBLEM SOLVING.................................................................39

POOR HANDSFREE PERFORMANCE..........................................................................39

6. WARRANTY AND SERVICE ..........................................................................................41

The features of your telephone

This telephone is a sophisticated instrument but, with just a little practice and

some patience, you will soon be able to use it to its full capabilities.

Most importantly, the telephone is able to show caller display information,

provided that it is available on your telephone line and that your network operator

has provided the service to you. You may have to pay a small charge for the

service.

If caller display is connected then, when a call is received at the telephone, it will

display the number of the person calling you (there are some exceptions to this

but please refer to the appropriate section in this manual). This information is

stored together with information about the time/date of the call and whether you

answered the call or not. Information on the last 80 calls is retained in the

telephone memory and it is possible to scan through these calls and dial

someone back by simply pressing one button.

There is an independent directory for you to store the telephone numbers and

names of the 100 people whom you call most often or who call you. By accessing

an entry in the directory and pressing one button, that number will be called.

If one of your directory “Names” calls you, then the display will show not only the

number calling you but the name, as stored in your directory.

As well as a directory of numbers, it is possible to store up to 20 names and

numbers in ten one- and two-touch buttons. NOTE: one variant of this telephone

is designed to use Network Services and it utilizes these buttons. In this case, it

is not possible to store user programmable memories in these locations.

It is also possible to use this telephone in combination with a headset. There is a

universal interface in the telephone which will allow connection of most headsets,

providing that they have an RJ11 plug for connection to the headset socket

situated at the back of the telephone.

1. Important Notes

Intended Use

This apparatus is intended for use on 2 wire analogue PSTN and PABX circuits

within Europe and the Middle East.

Telephone facilities

This telephone has been designed for the use of the following facilities:

 Caller display facilities

 Liquid crystal display

 Handsfree speakerphone operation

Declaration of Conformity

Interquartz (UK) Limited declares under its sole responsibility that this product

Model : 9335 Gemini CLI Phone

Is in conformity with the following relevant harmonized standards

Health & Safety EN60950

Electromagnetic Compatibility EN55022 : 1998 & EN55024 : 1998

Telecom EN301437 : 1999 & TBR38 : 1998

Following the provisions of Council Directive on radio equipment and

telecommunications terminal equipment.

MAY 2004

 Optional message waiting indication

 Operation on PABX which return secondary indication

 Memories accessed by a button

 Last number redial

 PBX recall (earth or timed break selectable)

 MF signaling only

 Optional use of headset

 Access pause insertion (maximum of 3)

 Mute function

 Data port

 Headset electronic volume control

 Speaker electronic volume control

 Ringer volume control

 Ringer pitch control

 Ringing indicator

Handsfree speaking

This telephone is designed to work on most telephone lines by drawing power

from the line. However, when using the loudspeaking facility, there are some

instances where the power available may not be sufficient to provide an

adequate performance.

This telephone requires the use of a power supply, or batteries, for Handsfree

operation and for the caller display to function. If the telephone is used in

Handsfree mode without any additional power, difficulties may be experienced

but your telephone will still work simply by lifting the Handset and proceeding to

dial.

Emergency calls

Calls can be made on this telephone to contact the emergency services. The

European code for emergency services is 112, however, you can still use 999 in

the UK. An access code may also be required, if the phone is connected to a

PABX.
