Genexis FiberTwist Series Manuale utente

PX

FiberTwist–Series

Installation Guide

Buton oveview Pot oveview

Power pot

ONOFF

buton

LAN pots

ONOFF buton

Power ON or OFF – press and

release to switch device ON or OFF

Unlock buton

Remove FiberTwist or Blind Cover – press and

hold while wisting counterclockwise

Reset buton (recessed)

Reset – press and release

LED dim buton

Dim LEDs – press and release to dim LEDs in

steps

System

Green – system ok

Green (blinking) – booting

Red – system error

Red (blinking) – insuicient optical signal

O – power o

Uplink

Green – link ok

Green (blinking) – link ok, no remote management

O – no link

LED oveview

Box contents

• Genexis FiberTwist (active device)

• Power adapter

• x Spare device label (self-adhesive)

• Installation Guide (this document)

Label position

The product label is positioned on the

back of the active device.

Preparation

Ensure there is a power socket

within reach of where the device

is being installed.

Impotant: Instructions need

to be followed precisely and

uninterrupted. This minimizes

the risk of damage to the iber

optic connectors, causing a severe

degradation of signal qualiy.

Dierent language versions of this document and additional product information

are availableon htps:genexis.euproductibewistdownloads

Installation guide

Remove Blind Cover (if present)

. Press and hold the unlock buton (see buton oveview).

. Rotate the Blind Cover counterclockwise till it blocks.

. Remove the Blind Cover from the baseplate (FTU) by pulling

it towards yourself.

. Store the Blind Cover in a safe place.

Remove dust cap

. Take the FiberTwist out of the box.

. The dust cap is connected to the red string

located on the rear of the FiberTwist.

. Remove the dust cap by pulling the red string.

. Store the dust cap in a safe place.

Twist!

. Place the FiberTwist on the FTU as shown in the picture below,

in a –degree angle.

. Rotate clockwise until it clicks into place.

. Make sure the FiberTwist is aligned squarely on the FTU,

each edge must line up directly with the FTU below.

Your FiberTwist is now installed!

Company Name

Genexis Netherlands B.V.

Company Address

Lodewijkstraat a

 AC Eindhoven

The Netherlands

Name and title of authorized person

Maaten Egmond, CTO

Signature of authorized person

Place of issue Date of issue

Eindhoven --

The Netherlands

Hereby, Genexis Netherlands B.V. declares that the product FiberTwist-PX is

in compliance with Directives EU, EU, EU, Delegated

Directive  and Ecodesign Directive EC.

The full text of the EU declaration of conformiy is available at the following

internet address: htps:genexis.euproductibewistredibewist-px

EU Declaration of Conformiy

Connecting the FiberTwist

. If required, connect your personal devices to the LAN pots via an RJ

nework cable. A CAT cable or beter is recommended.

. Connect the supplied power adapter to the FiberTwist and plug the adapter

into a power socket.

. Press the ONOFF buton to power on the device.

Warning: The FiberTwist is a Class  laser product.

If at some point in the future it becomes necessay to uninstall the FiberTwist,

please place the Blind Cover back on the FTU immediately and put the dust cap

back on the FiberTwist.

Genexis assumes no responsibiliy for any inaccuracies in this document. Genexis reseves

the right to change, modify, transfer, or othewise revise this publication without notice.
