Genius NAVIGATOR 805 Istruzioni di montaggio

ENGLISH

1

Hardware Installation

1. You can connect the receiver to a USB port of a PC

2. Install two AAbatteries in the mouse.

3. Turn on your computer. The mouse can be worked.

Note: If the mouse does not have connection to the receiver, press the button

on the receiver first and then press the button under the mouse for channel

setting again.

Important: Remember do not put the batteries in the wrong direction; use the

same types of batteries. Also, keep all drinks away! If any spill occurs on the

receiver, unplug the USB connector first and clean the receiver immediately.

Please switch the button to "off" under the mouse once you don't use it for a

long time, and remove the batteries if you do not use this device for at least

two weeks.

Warning: (Troubleshooting)

1. Please do not use wireless laser mouse on a desk, which is made of glass

or mirror. Also, a flat surface is necessary or the laser sensor will error

easily. When you use wireless laser mouse on a desk that is made of

metal, try using a pad and reduce the receiving distance.

2. The wireless laser mouse channel provides 16 channels and 256 ID-codes,

and it automatically selects the ID # for your mouse. You can only set up

one wireless laser mouse at a time.

ENGLISH

2

3. If the power indicator is on (see Button Assignments), then the

batteries have lost their charge, so you need to replace them.

Software Installation

1. Make sure the mouse is connected to the computer.

2. Put the CD driver into the CD drive.

3. Follow the instructions on the screen to finish the software installation.

Security Function Setting:

1. After you install software driver, please click the mouse icon on the task

bar and select “Mouse”.

2. Click “Settings” when the Mouse Properties

appears up and click “Security Options”.

3. Choose a picture from your images to display

when the computer is locked. Also set your

password for unlock computer. Then, press

“OK”, and the security setting will be finished.

ENGLISH

3

4. If you want to start the security function, just

press “ ”, and the picture you set pop up

to hide the screen. For security, the mouse and

keyboard won’t work.

5. If you want to unlock this function, just press

“”again, and install your password.

Factory Setting

ENGLISH

4

Button Assignments

1. Left Button: Provides traditional

mouse functions like click, double

click and drag.

2. Right Button: You can assign this

button to frequently used

keyboard and mouse functions in

addition to features like Easy

Jump, Auto-Panning, Zoom, etc.

3. Magic-Roller: Press the “Magic-Roller” to surf the Internet and

Windows documents.

Horizontal Scroll: Press the roller to the left and the cursor scrolls to the

left; press the roller to the right and the cursor scrolls to the right.

4. Security: Lock your screen, mouse and keyboard unless you install the

password.

5. Power indicator: If your battery power is low, the LED will brighten.
