Genius SLIM 311R Manuale utente

English

Table of Contents

Slim 311R Features 1

Installing the Slim 311R 2-3

About Genius Application-WebCAM Mate 4

1. Main Menu 5-10

2. Picture Mode 11-13

3. Video Mode 14-16

4. Security Mode 14-18

Using MSN Messenger,Yahoo Messenger,AOL 18-20

CrazyTalk Avatar Creator 20-42

CrazyTalk CamSuite 43-70

Trouble shooting for web camera 71

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

The Slim 311R is designed as an all-hours web camera. The

red-infrared technology allows you to video chat in a low-light

environment. If you want to chat with a family member or a

friend late in the evening, and don’t want to disturb anyone,

then the Slim 311R is the ideal web camera for those who like

to stay up late.

1.SnapShot Button

You can press the snapshot button to

take still images.

2.Lens

Adjust the focus by twisting the lens.

3.Red-Infrared light

The red-infrared allows you to video

chat in a low-light environment.

4.Microphone

5.Swivel and Clipping Base

The adjustable clipping base fits easily

to almost anything - notebook panel,

CRT, and LCD monitors.

Slim 311R Features

English

-2-

You need to install device drivers and applications before using your

webcam.

Do not connect your webcam to your computer before

installing the drivers.

1. Installing the Slim 311R driver Windows Vista/XP/2000/Me/98SE

Environment

a. Insert the Slim 311R Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Windows Driver” then simply follow the on-screen instructions.

c. Install DirectX from the CD if your pc didn’t have it on your system or

the version was older.

NOTE

If the Autorun screen doesn’t start, please follow these steps

zClick on “Start Menu”

zType D:\SETUP.EXE, then click the Enter key.

(Assume your CD-ROM is in Drive D)

2. Follow the instructions on the screen to complete the installation.

3. Insert the Slim 311R’s USB cable to your desktop or laptop USB

port.

4. Restart your computer after all the applications have been

installed.

Installing the Slim 311R

English

-3-

5. The software and hardware installation is now complete. You can

install the software you would like to use for video conferencing

or chat with your friends.

NOTE

The web camera can work properly with any video chat software that

supports a video feature.

6. Position Camera

Place the camera in the middle of your computer monitor for

optimal eye contact. The camera can pivot vertically or

horizontally, allowing you to find the best position.

Free angle clipper, fits on any screen

ForLCDPanel ForNotebook Desktop

NOTE

To remove the driver installation in Windows 98SE/Me/2000/XP/Vista

Environment:

Please go to the taskbar and follow “Start ÆProgram ÆSlim 311R

ÆClick “Uninstall”, then follow the on-screen instructions to remove the driver.

English

-4-

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or

C:\WINNT\Album)to save the images you take using the Genius

Application.

Genius application available in windows Vista/XP/2000/Me/98SE

About Genius Application-WebCAM Mate

English

-5-

1. Main Menu

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

English

-6-

Item Mode Description

Resolution

Selection

Resolution selections according to

device.

RGB24: 1280x1024 (*), 1024x768 (*),

800x600 (*), 640x480, 352x288,

320x240, 176x144, 160x120

I240: 1280x1024 (*), 1024x768 (*),

800x600 (*), 640x480, 352x288,

320x240, 176x144, 160x120

Property page Preference setting to view your setting

and properties.

Exit Exit the Genius UI.

Remark:

* This resolution is by software interpolation.

English

-7-

-Property page

Settings

Item Description

-You can flip the image horizontally or vertically by choosing

“Image Mirror” or “Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to

get a clear image.

English

-8-

Item Description

You can adjust different values for different circumstances and

environment.

You may adjust values toward image appearance. Before

adjusting values, you have to unclick “Auto” to unlock.

-Press “Reset” to return to the manufacturer’s settings.

-Press “Restore” to return to the previous settings.

-Press “Save” to save the values you set up.

Select the correct frequency according to the country where you

are using the web camera. (Before doing this, you will need to

select “Indoor”.)

-If your web camera is located in backlight position, you may click

“Backlight compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W

Mode”.

Activates the red-infrared light to show images in low-light

environments.

English

-9-

Effect

Item Description

There will be 26 different kinds of video effects/frames for you to

select. The effects can also be applied to the video chat software,

like MSN Messenger.

You can directly connect to this effect page from the web camera

settings in the video chat software.
