Before attempting to connect or operate this product,

please read these instructions carefully and save this manual forfuture use. MFE-QG-A

Quick Start Guide

GV-PFER12800

Under the copyright laws, this manual may not be copied, in whole or in part,

without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind

and assumes no responsibility for errors or omissions. No liability is assumed

for incidental or consequential damages arising from the use of the information

or products contained herein. Features and specifications are subject to

change without notice.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows is the registered

trademark of Microsoft Corporation.

September 2023

Scan the following QR codes for product warranty and technical support

policy:

[Warranty] [Technical Support Policy]

Contents

1. Overview..............................................................................................................1

2. Optional Installation ...........................................................................................2

2.1 Looking Up the Dynamic IP Address.............................................................2

2.2 Configuring the IP Address ............................................................................4

3. The Web Interface...............................................................................................5

4. Upgrading System Firmware .............................................................................8

5. Restoring to Factory Default..............................................................................9

1. Overview

Note:

1. The camera can be powered by DC 12V / PoE power supply. If the PoE switch is used

to power the camera, DC 12V power supply is not required.

2. To load default settings, press and hold the default button for 10 seconds.

2. Optional Installation

2.1 Looking Up the Dynamic IP Address

By default, when the camera is connected to a LAN with the DHCP server, it is

automatically assigned with a dynamic IP address. Follow the steps below to look up its IP

address.

Note:

1. By default, the Administrator’s username is admin and cannot be modified.

2. This function is only applicable on GV-IP Device Utility V8.9.9 or later.

1. Make sure the PC used to configure the IP address is under the same LAN as the camera.

Download and install GV-IP Device Utility from the company website.

2. On the GV-IP Utility window, click the button to search for the IP devices connected in

the same LAN. Click the Name or Mac Address column to sort.

3. Find the camera with its Mac Address, and click on its IP address.

4. For the first-time users, you are requested to set up a password.

5. Type a new password and click OK.

6. Click on its IP address again and select Webpage to open its Web interface.

7. Type the set password on the login page and click Login.

2.2 Configuring the IP Address

If the camera is connected to a LAN without the DHCP server, the default IP address will be

192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other

GV-IP devices on the same LAN.

1. Open your Web browser, and type the default IP address 192.168.0.10.

2. Type the default username admin and your password. Click Login.

3. Select Static IP next to Type.

4. Enter the IP address, subnet mask, and default gateway address. Make sure that the IP

address of the camera is unique in the network.

5. Click Save.

3. The Web Interface

Once you log in the Web interface, you will see the live view as shown below.

Item

Parameter

Description

Dewarping Rule

Hardware Dewarping

Click to select on-board dewarping mode.

Software Dewarping

Click to select client-side dewarping mode.

Installation

Ceiling Mounting

Click to select ceiling mounting.

Wall Mounting

Click to select wall mounting.

Flat Mounting

Click to select flat mounting.

Display

Select live view of original fisheye view.

Select live view of 360° panoramic view.

Select live view of two 180° panoramic views.

Select live view of four regional views.

1O3R

Select live view of one original fisheye

view and three regional views.

1P3R

(Only for Hardware

Dewarping)

Select live view of one 360° panoramic

view and three regional views.

1P3R

(Only for Multi-Channel

Mode of Hardware

Dewarping)

Select live view of one original fisheye

view, one 360°panoramic view and three

regional views.

1P1R

(Only for Software

Dewarping)

Select live view of one 360° panoramic

view and one regional view.

1P4R

(Only for Software

Dewarping)

Select live view of one 360° panoramic

view and four regional views.

Display

1P6R

(Only for Software

Dewarping)

Select live view of one 360° panoramic view

and six regional views.

1O8R

(Only for Software

Dewarping)

Select live view of one original fisheye

view and eight regional views.

Channel

(Only for Multi-Channel

Mode)

Click to play this channel on any window of live

view.

Window

/ /

Window Layout

(Only for Multi-Channel

Mode)

Click to set window layout to “1*1”/ “2*2”/ “1+4”.

Window Size

Click to display images at a window size.

Note:

•Original fisheye view: The whole wide-angle view of the fisheye camera is

displayed.

•Panoramic view: The round fisheye image is transformed to

rectangular image by certain calibration methods.

•Regional view: The close-up view of defined area in the original fisheye

view or panoramic view.

•Select the Installation, Display mode and the most appropriate Window Layout

in sequence.

For detailed information, see the user’s manual.
