GEYA GPS8-06 Manuale utente

-1-

Instruction ManualGEYA ELECTRICAL CO.,LTDAdd:Wenzhou Brige Industrial Zone,Beibaixiang Town,Yueqing,Zhejiang,China 325603E-mail:sale@cngeya.comWeb:www.geya.netVoltage / Current Protector GPS8-06General฀Applications -Overvoltage ,undervoltage and overcurrent protection for household equipment.฀ Function Features -Voltage / current monitoring and protection. -Special metering chips are used to detect voltage, current, electricity, and power. -It is possible to control switches, monitor electrical energy, and set timing for opening and closing through WIFI. -Double bus wiring design stronger ability. -Over / under voltage value and over-current value can be set. -Self reset after fault. -Digital display voltage, current value, fault status can be displayed by LED. -DIN rail mounting. ฀Model and connotationTechnical parametersRated operational currentOFF,230V~300V45~65Hz

AC220V(L-N)

≤1%Rated supply voltageRated supply frequency

Over voltage operation value

Over/under voltage action delay

Reset timePower-up delayMeasurement error-20℃ ~ +60℃-35℃ ~ +75℃Din rail EN/IEC 60715IP40 for front panel/IP20 terminalsany

823668mm××

Operating temperatureStorage temperatureMounting/DIN railProtection degreeOperating positionOvervoltage cathegoryPollution degreeDimensionsWeight

135g

BurdenAC max.3VAGPS8-06Function

Over voltage, under voltage and over current

0.1s~10s140V~210V,OFF

Under voltage operation valueOver current operation value

Over current action delay

Functions DiagramTp：Power-up delay(2~600s)Tr：Reset delay time(2~900s)Tu：Over/under voltage fault action time(0.1~10s)Tc：Overcurrent fault action time(2~600s)

ULED:

<Tu

TpTrTr

ILED:

LED: >I

TpTr

LED: >U

LED: <U

I>Panel DiagramPower open and closeindicatorOver voltage indicatorUnder voltage indicatorOver current indicatorOperating voltage valueOperating current value

32A,40A,50A,63A,80A（AC1）

1~32A,40A,50A,63A,80A

1×101×10Mechanical lifeElectrical life(AC1)4

GPS8

GPS8 SeriesDesign numberU:upper incoming lineD:lower incoming lineIncoming line mode

TuTu

<Tu

Operation voltage range80V~400V(L-N)2s~600s2s~600s2s~900sParameter settingParameterRangeStep valueFactory settingsOver voltage value

OFF,230V~300V

275V1VUnder voltage value

140V~210V,OFF

175V1VOver current value

OFF,1A~32/40/50/63A

32A/40/50/63A0.1AOver current action delay2s~600s5s1sReset time2s~900s30s1sFault resetON-OFFONPower on delay time2s~600s5s1sOver voltage recovery value225V~295V265V1VUnder voltage recovery value145V~215V180V1VVoltage fault action time0.1s~10s0.5s0.1sMPress and hold the setting key for 3 seconds to enter the setting. After modifying the setting, press and hold for 3 seconds to save the setting.1.Used to increase the value when setting parameters.1.Used to reduce the value when setting parameters.2.After exiting the setting, it can be used to manually turn on or off the load.3.If the automatic fault reset function is turned off, this button can be used for manual reset when the fault occurs.

>IU

NOTE:In the power off state, press and hold , and then power on again to restore the factory settings.LCD backlight time10s~900s,ON1s60sM

GPS8-06 63ANNIN>IU

M2.Press and hold for 5 seconds to reconfigure WIFI.

>IU

MWIFI status indication

GPS8-06 63A

-2-

Disposal of Electrical WasteAll electrical waste should bedisposed of in compliance withcurrent WEEE regulations.CautionThe products must be installed by qualified electricians. All andany electrical connections of the time relay shall comply withthe appropriate safety standards.Dimensions(mm)36max67.5

8282

Parameter settingNOTE:Short press to increase or decrease the value, long press can be quickly set.If 60 seconds does not operate the key, it will exit automatically.You can press the for 3 seconds at any time to exit the and save the setting. AC220VC16230V~3000IEC 60 898-112ONOFFC63400V~3000IEC 6 0898- 1ONOFF3412C25400V~3000IE C 6089 8-1ONOFF3412LNLOAD

LOAD

140V~210V,OFFUndervoltage value

OFF,1A~32A/40A/50A/63A

Overcurrent settingLong press 3 second to enter the parameter setting.OFF,230V~300VOvervoltage value2s~900sReset time setting2s~600s

Overcurrent action time

ON-OFFFault reset3s2s~600s

Power on delay setting

225V~295VOvervoltage recovery value145V~215VUndervoltage recovery value0.1s~10s

Over/under voltage fault action time

U

GPS8-02 63ANNIN

MOpen and close manually0.5sUnder normal operation, the load can be switched on or off manually by pressing the power keyfor 0.5 seconds.

NN21

GPS8-06U

NN12

GPS8-06DWiring DiagramPower-on and reset delayDuring the power-on and fault reset of the product, the product will count downand display according to the set delay time, and will enter the running state when the countdown ends.This product does not have isolation function. Please disconnect the superior MCB during maintenance!!!

GPS8-06 63ANNIN>IU

Query electricity and powerLCD backlight time10s~900s,ONM

Power: 1500W

Quantity of electricity : 1234.5kWh

Power: 1500W

Quantity of electricity : 1234.5kWhWIFI configuration

There is a QR code on the side of the product. Please scan, download, and install it.Press and hold for 5 seconds before entering the WIFI configuration state. At this time, the WIFIindicator flashes. Please open the app and pressthe prompt to configure. When the WIFI indicator is always on, it indicates that the WIFI signal is good. When the WIFI indicator flashes, it indicateswaiting for WIFI configuration.When the WIFI indicator is always off, it indicates that the WIFI cannot be connected.

5 second
