Giant TCR 1 Manuale utente

Spec Features

— Shimano 105, 5700-series component group w/ compact crankset

— Giant Connect handlebar, stem, & seatpost

— Wheelset: Giant CR41 rims/ Formula Alloy hubs

Speciﬁcations and availability subject to change without notice.

Specifications

frame

SIZES XS,S,M,M/L,L,XL

COLOUR Black / White / Blue

FRAME ALUXX SL-Grade aluminum

FORK Advanced-Grade composite w/

alloy OverDrive steerer

SHOCK N/A

componentS

HANDLEBAR Giant Connect 31.8mm

STEM Giant Connect

SEATPOST Giant Connect 30.9x375mm

SADDLE Giant Racing

PEDALS Not included

DriVetrain

SHIFTERS Shimano 105

FRONT DERAILLEUR Shimano 105

REAR DERAILLEUR Shimano 105

BRAKES Tektro TK-R540

BRAKE LEVERS Shimano 105

CASSETTE Shimano 105 11-28T 10SPD

CHAIN KMC X10SL

CRANKSET Shimano R600 34/50T compact

BOTTOM BRACKET Shimano internal press ﬁt

WHeeLS

RIMS Giant P-R2 F:24H / R:28H

HUBS Formula Alloy

SPOKES Sapim Race 14g

TIRES Michelin Dynamic 700x23c

EXTRAS

*Seat angle is actual

**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube

***Standover height is based on the largest size tire that will ﬁt the bike, not necessarily the included size tire

frame geometry

A B C D E F G H

$

on-road | performance | Competition

TCR 1

Actual

Frame Size Part

Number Head

Angle Seat

Angle* Toptube** Headtube Chainstay Wheelbase Standover

Height***

centimeters degrees degrees centimeters centimeters centimeters centimeters inches

XS 43.0 2115600 71.0 74.5 52.0 12.0 40.5 97.7 28.5

S 46.5 2115601 72.0 73.5 53.5 13.5 40.5 97.4 29.2

M 50.0 2115602 73.0 73.0 55.5 15.0 40.5 98.0 30.1

M/L 53.5 2115603 73.0 72.0 57.0 17.0 40.5 98.6 31.0

L 55.5 2115604 73.0 72.0 58.5 18.5 40.5 100.1 31.7

XL 58.5 2115605 73.0 72.0 60.5 20.0 40.5 102.1 32.4

29
