Gigabyte P35 Manuale utente

English

Congratulations on your purchase of the GIGABYTE Notebook.

This manual will help you to get started with setting up your notebook. The final product

conguration depends on the model at the point of your purchase. GIGABYTE reserves the

right to amend without prior notice. For more detailed information, please visit our website at

www.gigabyte.com

1Connect the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the right side of the notebook.

3Connect the power cord to the power outlet.

Switching on the Power

After you turn on the Notebook for the very rst time, do not turn it off until the operating system

has been congured. Please note that the volume for the audio will not function until Windows®

Setup has completed.

Booting Up the Notebook for the First Time

Depending on your conguration, the Microsoft® Windows® Boot Screen will be the rst screen that

you will see as the notebook starts up. Follow the on-screen prompts and instructions and enter

your personal information to complete the setup of the Windows®Operating System.

Using GIGABYTE Notebook for the First Time

English

Top View & Front View

Left View

21 3 6

4 5

1Webcam Status LED Indicator

2Webcam

3Light sensor

4Microphone

5Power Button

6TouchPad

7LED Indicators 

8Swappable Storage Bay

9Power Check Button 

Bluetooth Status LED

Wireless Lan Status LED

HDD Status LED

Battery Status LED

Power Status LED

As shown below, the battery life indica-

tor is available when the laptop is shut

down, in stand-by or hibernation.

(Battery mode)

<10%

11-30%

31-50%

51-70%

71-90%

>90%

1Kensington Lock Slot

2Ethernet Port

3USB 2.0 Port

4Headphone Jack

5Microphone Jack

6SD Card Reader

Your GIGABYTE Notebook Tour

8 9

English

1 4 5 6

2 3

1MiniDisplayPort

2USB 3.0 Port

3USB 3.0 Port (USB Charge)

4HDMI Port

5External Display (VGA) Port

6DC-in Jack

1Memory Compartment

2Subwoofer

3Speakers

Base View

Right View

Warning:

DO NOT remove the built-in lithium battery. For any service needs, please contact your local GIGABYTE

Authorized Service Center.

English

The computer employs hotkeys or key combinations to access most of the computer’s controls like

screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before

pressing the other key in the hotkey combination.

Hotkey Function Description

Fn+ESC Eject ODD Eject ODD

Fn+F1 Sleep Put the computer in Sleep mode.

Fn+F2 Wireless LAN Enables/disable the Wireless LAN function.

Fn+F3 Brightness Down Decrease the screen brightness.

Fn+F4 Brightness Up Increase the screen brightness.

Fn+F5 Display Toggle Switche display output between the display

screen, external monitor (if connected) and both.

Fn+F6 Touchpad Toggle Turn the internal touchpad on and off.

Fn+F7 Speaker Toggle Turn the speaker on and off.

Fn+F8 Volume Down Decrease the sound volume.

Fn+F9 Volume Up Increase the sound volume.

Fn+F10 Screen Display Toggle Turn the screen display on and off.

Fn+F11 Bluetooth Enable/disable the Bluetooth function.

Fn+F12 Webcam Turn the internal webcam on and off.

Fn+Space Keyboard Backlight

Toggle Turn the keyboard backlight on and off.

Hotkeys

English

Swappable bay Application

1Unlock swappable bay locker.

2Draw the swappable bay out.

Connect the HDD or SSD pin by sliding it into the connecter.

9.5mm HDD/SSD only

English

1Pull swappable bay back to slot.

2Lock swappable bay locker.

Gently push the plastic frame outwards. Slide in the HDD or SSD until it locks into place. There will

be a slight click.

English

GIGABYTE Smart Manager

You can activate GIGABYTE Smart Manager by double clicking on the shortcut icon on the

desktop if the machine you purchased has the operation system built-in. GIGABYTE Smart

Manager is an icon-based control interface, enabling users to intuitionally access common

system setup as well as GIGABYTE exclusive utilities. Please be noted that the GIGABYTE

Smart Manager interface, icons, utilities and software versions may vary based on the

purchased models. Please operate GIGABYTE Smart Manager according to the actual version

built-in.

GIGABYTE Software Application

English

8Setup Your System for RAID 0/1

WARNING

●Please backup your data before you build and run RAID 0/1 on your system.

●RAID 1 needs two storage drives of the same specication and capacity in your laptop.

● RAID 0 needs two storage drives of the same specification in your laptop. Different capacity is

acceptable.

• Press F2 when computer starts to Enter

BIOS setup utility.

• Go to Advanced > SATA conguration.

• Change "SATA Mode selection" from

"AHCI" to "RAID".

• Press F10 to save and exit. The system

will restart automatically.

• Once the system restarts. Go to "All

Apps" found at the bottom of the screen

on Windows 8 and execute Intel Rapid

Storage program.

4• You will see the Intel Rapid Storage

Technology Screen, Click> Create.

• Under Select Volume Type choose

Optimized disc performance (RAID 0/1),

Click > NEXT.

• Under Configure Volume you may set

Name to your preferred name and select

both controllers.

• Click > Next. You will see Confirm

Volume Creation. Click > Create volume.

• Wait until the system migration is

complete and restart the laptop.

English

Smart USB Backup Guide (Original: Recovery Image USB)

WARNING

●You can backup original recovery image through this application in case of losing by device damage.

● You can backup original recovery image to USB disk and restore the system if any storage system

replacement with the recovery USB disk.

● Before you restore the system through the recovery USB disk, please make sure that you have already

made the backup of your data.

●Please DO NOT shut down or un-plug the system when performing backup through recovery USB disk.

>20G

• Please plug in the USB disk which is

at least 20GB in capacity to make the

original image (backup the data in USB

rst. All data will be eliminated during

the creation of recovery USB disk)

• Insert the driver disk to your optical

drive and run the install of “Smart USB

Backup” (for none-ODD model, please

use USB ODD device or download

from http://www.gigabyte.com

• Run the “Smart USB Backup” after

nishing the install.

• Select your USB disk from the drop-

down list and start to create the

recovery USB disk.

• The window will pop out when the creation of recovery disk is done.

• Please press F12 on starting the system when you need to restore the system. Select

“boot from recovery USB disk” and the system will be restored.

• The time needed for restore will be around 30 mins(time needed may vary by USB disk

model) .
