Gigabyte T1006 Manuale utente
1
2
English
1
This manual will help you to get started with setting up your netbook. The nal product
conguration depends on the model at the point of your purchase. GIGABYTE reserves
the right to amend without prior notice. For more detailed information, please visit our
website at http://www.gigabyte.com.
Using GIGABYTE Netbook for the First Time
Check Supplied Items
1
2
Congratulations on your purchase of the GIGABYTE netbook!
AC Adapter Battery Pack Manual Handy Bag (Optional)
Power Cord Driver CD Global Warranty
Card
Stylus (Optional)
* The illustrations in this document may appear differently from your model.
To install the battery please follow these steps:
1Insert the battery pack into the compartment.
2Remember to slide the switch to the “Lock” position.
1
3
2
English
2
Switching on the Power:
After you turn on the T1006 for the very rst time, do not turn it off until the operating
system has been configured. Please note that the volume for the audio will not
function until Windows® Setup has completed.
Booting Up the T1006 for the First Time:
Depending on your conguration, the Microsoft® Windows® Boot Screen will be the rst
screen that you will see as the netbook starts up. Follow the on-screen prompts and
instructions and enter your personal information to complete the setup of the Windows®
Operating System.
1Connect the the power cord to the AC adapter.
2Connect the AC adapter to the DC-in jack on the left side of the Netbook.
3Connect the power cord to the power outlet.
34 5 6
1 2
1
5
4
3 2
English
3
1Webcam
2LED Indicators
3Touchpad
4LED Indicators
5Microphone
Bluetooth Status Indicator
Wireless LAN Status Indicator
HDD Status Indicator
Battery Status Indicator
Power Status Indicator
Num. Lock Indicator
Caps Lock Indicator
3.5G Status Indicator(Optional)
Left View
Your GIGABYTE Netbook Tour
3
Panoramic View
1External Display (VGA) Port
2USB Port
3Air Vent
4HDMI Port
5Headphone Jack
6Microphone Jack
3 4 5 6
2
1
4
1
2 3
English
4
Base View
Right View
1Multi Card Reader
2eSATA/USB Combo
3USB Port
4Power Button
5Ethernet Port
6DC-in Jack
Supports Secure Digital (SD),
Multi Media Card (MMC),
Memory Stick (MS),
Memory Stick PRO (MS PRO) Card.
1Kensington Lock
2Battery Bay
3SIM card slot
4Speakers
To insert of a mobile SIM card for 3.5G
function (Optional)
English
5
The computer employs hotkeys or key combinations to access most of the
computer’s controls like screen brightness and volume output. To activate
hotkeys, press and hold the <Fn> key before pressing the other key in the
hotkey combination.
Hotkey Function Description
Fn+F1 Sleep Puts the computer in Sleep Mode.
Fn+F2 Wireless LAN Enables/disables the Wireless LAN function.
Fn+F3 Brightness Down Decrease the screen brightness.
Fn+F4 Brightness Up Increases the screen brightness.
Fn+F5 Display Toggle
Switches display output between the display
screen, external monitor (if connected) and
both.
Fn+F6 Touchpad Toggle Turns the internal touchpad on and off.
Fn+F7 Speaker Toggle Turns the speaker on and off.
Fn+F8 Volume Down Decreases the sound volume.
Fn+F9 Volume Up Increases the sound volume.
Fn+F10 WWAN (Optional) Enables/disables the WWAN fucntion.
Fn+F11 Bluetooth Enables/disable the Bluetooth function.
Fn+F12 Webcam Turns the internal webcam on and off.
4
Hotkeys
English
6
The screen of T1006 is convertible to simulate a Tablet PC. Follow the Steps to
use this function:
Use your T1006 as a Tablet PC
5
1Open the lid (the screen display of T1006.)
2On the top center above the keyboard is the pivot connecting the display
panel to the bottom case. There Is a sign
3Follow the sign to turn the screen clockwise up to 180 degree so that the
screen is facing out.
4FLay the turned screen down into the flat position. The keyboard will be
covered by the display. Use the stylus or simply touch the screen to operate
T1006 as a Tablet PC.
5When done with Tablet PC. Reverse the screen to 90 degree,turn counter-
clockwise set T1006 back to original position.
Attention:
Please note that the screen can only rotate at 180 degree Clockwise. Be
sure to turn the screen according to the sign. Forcing the screen to turn at the
wrong angle will cause serious damage to the T1006.
English
7
●GIGABYTE Smart Manager:
You can activate GIGABYTE Smart Manager by double clicking on the
shortcut icon on the desktop if the machine you purchased has the operation
system built-in. GIGABYTE Smart Manager is an icon-based control interface,
enabling users to intuitionally access common system setup as well as
GIGABYTE exclusive utilities. Please be noted that the GIGABYTE Smart
Manger interface, icons, utilities and software versions may vary based on the
purchased models. Please operate GIGABYTE Smart Manager according to
the default built-in version.
●GIGABYTE Smart Recovery:
If the machine you purchase already has operating system built-in, you
can restore the system back to factory default by using GIGABYTE Smart
Recovery. Please be noted that the GIGABYTE Smart Recovery according to
the default built-in version.
1.If the machine you purchase already has operating system built-in, you
can restore the system back to factory default by using GIGABYTE Smart
Recovery. Please be noted that the GIGABYTE Smart Recovery according
to the default built-in version.
2.Please be noted that personal data will be lost after recovery, do remember
to backup any data before operating this function.
Therefore will briey describe how to launch the Recovery Tool and to get the
recovery started.
1.Turn off or restart the netbook.
2.Turn the netbook on and press and hold the F9 key to launch the tool.
3.There shows the “Recovery” and “Exit” in Recovery System, click the
“Recovery” to start the restore back to factory default. 1
4.Recovery window shows the processing status. 2
5.You could restart the computer when restore has been done. 3
GIGABYTE Software Application
6
12 3
English
8
SKU Type Specication
CPU Intel® Atom™ Processor
Operation System Microsoft® Windows® 7 Compliant
LCD 10.1” Multi-Touch Panel.1366X768/1024X600, with LED
back-light
System Memory DDRIII SO-DIMM 1 slot (Max 4GB)
Chipset Mobile Intel® NM10 Express Chipset
Hard Disk Drive 2.5” 9.5mm SATA HDD 5400rpm
Audio 1.5 Watt Speaker*2, Internal Microphone
I/O Port
USB 3.0*1, USB 2.0*1, eSATA/USB 2.0 Combo*1, HDMI,
D-Sub, RJ45, Mic-in, Earphone-out, 4-in-1 Card Reader
(SD/MMC/MS/MS Pro) and DC-in Jack.
Communications
10/100/1000Mbps Ethernet
802.11b/g/n Wireless
Bluetooth v2.1 + EDR
3.5G Antenna built-in, 3.5G Module supported (Optional)
Webcam 1.3 Megapixel
Battery Li-ion 6-cell
Dimensions 265(W) x 214(D) x 41.4 (H)mm
Weight ~1.48kg (w/battery)
Specication
7
Appendix
8
■ Warranty & Service:
Warranty and service and related information please refer to the warranty card
or GIGABYTE service website as the below link :
http://www.gigabyte.com/support-downloads/technical-support.aspx
■ FAQ:
For FAQ (Frequent Asked Questions), please refer to the following link:
http://www.gigabyte.com/support-downloads/faq.aspx
