Gigabyte GV-AR64S-H Manuale utente

AR64S-H

RADEONTM7500 Graphics Accelerator

REV.1.03

12MD-AR64SH-103

USER'SMANUAL

中文使用手冊

Upgrade your Life

AR64S-HGraphics Accelerator

CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.(“GBT”)Nopartofthismanual

maybe reproduced ortransmitted inanyfromwithoutthe expressed,written permis-

sion ofGBT.

Trademarks

Third-partybrandsand namesarethe propertyoftheirrespectiveowners.

Notice

Due torapidchange intechnology,someofthe specificationsmightbe outofdatebefore

publication ofthisbooklet.

The authorassumesno responsibilityforanyerrorsoromissionswhichmayappearin

thisdocumentnordoesitmakeacommitmenttoupdatethe information contained

herein.

Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGA

card.

March17,2003 Taipei,Taiwan

Chapter1User’sManual

Thisproductincorporatescopyrightprotection technologythatisprotected by

method claimsofcertainU.S.patentsand otherintellectualpropertyrights

owned byMacrovision Corporation and otherrightsowners.Useofthiscopy-

rightprotection technologymustbe authorized byMacrovision Corporation,and

isintended forhomeand otherlimited viewing usesonlyunless otherwise

authorized byMacrovision Corporation.Reverseengineering ordisassemblyis

prohibited.

TableofContent

TableofContents

1.INTRODUCTION

1.1.PREFACE...................................................................................4

1.2.Overview.....................................................................................4

2.HARDWAREINSTALLATION

2.1.UNPACKING...............................................................................5

2.2.BOARD LAYOUT........................................................................6

2.3.HARDWAREINSTALLATION......................................................7

3.SOFTWAREINSTALLATION

3.1Win98/98SE ,WinME,WinXP DriverAnd UtilitiesInstallation .........9

3.1.1Operating systemrequirement ................................................9

3.1.2DirectXinstallation ................................................................ 10

3.1.3Driverinstallation .................................................................. 12

3.1.4Utilitieson driverCD ............................................................. 15

3.1.5TaskbarIcon ......................................................................... 15

3.1.6Propertypages..................................................................... 19

3.2.WINDOWSNT4.0DRIVERINSTALLATION............................. 25

3.3.WINDOWS2000 DRIVERINSTALLATION................................. 26

3.4BIOSFLASHUTILITY................................................................ 26

4.TroubleshootingTips................................................................................. 27

5.Appendix.................................................................................................. 28

5.1.Howtorefashthe BIOS.............................................................. 28

5.2.Resolutionsand ColorDepthTable............................................. 30

AR64S-HGraphics Accelerator

1.INTRODUCTION

1.1.PREFACE

GigabyteARSeriesisapowerfuland versatilegraphicsolution.64MBofpowerful

SDR memoryalong withthe RADEON™7500 GPUprovideshigh performanceaccelera-

tion oftoday’sdemanding 3Dgraphicapplications.Industryleading DVDplayback,sup-

portfordigitalflatpanel(DVI-I)monitorsmeetthe needsofawide range ofhomeand

business graphicusers.

1.2.KEY FEATURES

nPowered bythe RADEON™7500 GPUand 64MBSDR memoryfor

advanced3Dgraphics

nHYPERZ™increasesgraphics memorybandwidth

nHigh-resolution 32-bit3Dgaming up to2048x1536

nFull supportofDirectX®and OpenGL®applications

nCHARISMAENGINE™supportsfull Transformation,Clipping and Lighting

(T&L)at45 million triangles/second peakprocessing capability

nPIXELTAPESTRY™,the RADEON™7500 rendering engine,powersan

incredible1.74 gigatexels/second forthe highestfill ratesin32-bitathigh

resolutions

Chapter 1 User's Manual

HardwareInstallation

2.HARDWAREINSTALLATION

2.1.UNPACKING

The AR64S-Hpackage containsthe following:

lThe AR64S-Hgraphics accelerator

lThisUSER'SMANUAL

l DVDPlayersoftwareincluded

lFull Version gameCD x4(CD x4),Liteversion gamex2(CD x1)

lCD fordriverwithV-Tunerutilities

lS-Videocable

WARNING!

Expansion cardscontainverydelicateIntegrated Circuit(IC)chips.Toprotectthemagainst

damage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou workon your

computer.

1.Turnoff yourcomputerand unplug powersupply.

2.Useagrounded wriststrap beforehandling computercomponents.If you do nothaveone,

touchbothofyourhandstoasafelygrounded objectortoametalobject, suchasthe power

supplycase.

3.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe

componentswheneverthe componentsareseparated fromthe system.

The cardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystatic

electricity,sothe cardshouldbe left initsoriginalpacking until itisinstalled.

Unpacking and installation shouldbe done on agrounded anti-staticmat. The operatorshould

be wearing an anti-staticwristband,grounded atthe samepointasthe anti-staticmat.

Inspectthe cardcarton forobviousdamage.Shipping and handling maycausedamage toyour

card.Besurethereareno shipping and handling damageson the cardbeforeproceeding.

MDONOTAPPLYPOWERTOYOUR SYSTEMIFITHASBEENDAMAGEDONTHE

CARD.

MInordertoensureyourgraphics cardworking correctly,please use officialGigabyte

BIOSonlyUse noneofficialgigabyteBIOSmightcause problemon thegraphics card.

AR64S-HGraphics Accelerator

2.2.BOARD LAYOUT

AR64S-H(4Mx16 64MBSDRAM)

DVIOutput

S-VideoOutput

VGAOutput

S-Video

VGAMonitor

Connector

(15pin)

DVIConnector

AV Output

4Mx16 FrameBufferSDRAM

BIOS

ATI

RADEONTM7500

S-Video

(TV-Out)

VGAMonitor

Connector

(15pin)

DVIConnector

H/WMonitor

ChipFan Connector

HardwareInstallation

2.3.HARDWAREINSTALLATION

Installing YourGraphics card..

Nowthatyou haveprepared yourcomputer,you arereadytoinstall yourgraphics

acceleratorcard.

Toinstall yourgraphics acceleratorcard

1.Poweroff the computerand monitor,then disconnectthe displaycablefromthe

backofyourcomputer.

2.Removethe computercover.If necessary,consultyourcomputer'smanualforhelp

inremoving the cover.

3.Removeanyexisting graphics cardfromyourcomputer.

Or,ifyourcomputerhasanyon-boardgraphics capability,you mayneed todisableit

on the motherboard.Formoreinformation,see yourcomputerdocumentation.

AR64S-HGraphics Accelerator

4.Locatethe AGPslot. If necessary,removethe metalcoverfromthisslot; then align

yourGraphics cardwiththe AGPslot, and press itinfirmlyuntil the cardisfullyeated.

5.Replacethe screwtofasten the cardinplace,and replacethe computercover.

6.Plug the displaycableintoyourcard;then turnon the computerand monitor.If your

Graphics cardcamewithaDVIconnector,you can connectaflatpaneldisplaytothe

appropriateconnector,asshownbelow...

You arenowreadytoproceed withthe installation ofthe Graphics carddriver.For

detailed instructions,selectyouroperating systemfromthe listbelow:

AR64S-HGraphics card

AGPSlot

AR64S-HGraphics card

ToFlatPanelDisplay

ToTVorVCR

ToVGAMONITOR

SoftwareInstallation

3.SOFTWAREINSTALLATION

Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:

3.1.WINDOWS®98 /98SE ,WINDOWSMEand WindowsXP DRIVER

AND UTILITIES INSTALLATION

The installation ofWindows98/98SE orWindowsMEorWindowsXP driversisvery

simple.

When you insertthe driverCD intoyourCD-ROMdrive,you can see the AUTORUN

window(ifitdoesnotshowup,run "D:\setup.exe").Then you can followguidesto

setup yourAR64S-Hdriver(Pleasefollowthe subsection 3.1.3"Step ByStep Installa-

tion"toinstall the driverforyourAR64S-Hgraphics accelerator.

3.1.1.Operatingsystemrequirement

lIf yourOSisMicrosoft Windows,when loading the AR64S-Hdriversforthe

system,pleasemakesureyoursystem(Windows98/98SE orWindowsME)has

installed DirectX8.1orlater.

lIf you install the AR64S-Hdriversforthe mainboard,which

consistofSIS,ALIorVIAchipsets,pleaseinstall the appropriateDriverprogramfor

thatmainboard.OrpleasecontactyourmotherboardnearestdealerforM/BDiver.

AR64S-HGraphics Accelerator

3.1.2.DirectXInstallation

Install Microsoft DirectX8.1toenable3Dhardwareacceleration supportforWin98/

98SE/MEtoachievebetter3Dperformence.

Note:ForsoftwareMPEGsupportinWin98/98SE orWinME,you mustDirectXfirst

install.

MMustbe install DirectX8.1(orlater)

1.Installation DirectXDriver

Click "Install DirectX8.1”Item.

2.Click "Yes"icon.

3.Click "Yes“icon.
