GINGKO AUDIO
ClaraVu™ 7 Modular Speaker System
Owner’s Manual
Thank you for purchasing Gingko Audio’s ClaraVu 7
speaker system.
These striking speakers are a result of 7 years of intensive
research and development. Each speaker is hand crafted in
the USA using the finest parts in the world. Custom drivers,
high-quality caps and coils, OCC copper cabling and unique
cabinet construction result in superlative resolution and
musicality.
Each ClaraVu speaker is hand-built in the USA instead of coming off a factory line. Each is thoroughly
tested and comes with a 2-year warranty to the original owner.
The ClaraVu 7 modular speaker system consists of a monitor speaker and a matching powered
subwoofer. They are perfect for apartment-size high-end systems, yet their big sound offers more than
satisfying performance in reference-level setups. A combination of 85 dB sensitivity and 8 ohm minimum
impedance means the ClaraVus are easily matched to a wide range of tube or solid state amplifiers.
The ClaraVu speaker enclosures are available in three beautiful finishes: maple, cherry and gloss piano
black. The modular construction of the system means that you can but the monitor speakers with
matching stands first, then add the sub modules to make a full range system.
The ClaraVu 7 monitor is a two-way speaker using a 1” soft dome tweeter and twin 6.5” paper cone
woofers in a unique isobaric configuration. Two woofers are mounted one in front of the other in a
sealed paperboard tube inside a rigid cabinet. The same design is used in the drivers of the sub module.
This design minimizes vibration and standing waves and results in the ClaraVu’s high-resolution and
extreme musicality.
The ClaraVu 7 speakers will show you a “clear view” into your music by capturing all the details and
nuances of the recording and performance.
SPECIFICATONS:
Monitor Speakers –Retail $3995/pair Powered Sub Modules –Retail$1495 each
Tweeter: 1” silk dome using patented technology Woofers: 2 custom drivers, 6.5” paper cone
Woofers: 2 custom drivers, 6.5” paper cone Sub amp: 75w into 8 ohms, 100w/ into 4 ohms
Frequency Response: 45Hz-20KHz +/- 3dB Options for hookup: low-level via interconnects or
Impedance: 10 ohms nominal, 8 ohms minimum high-level via speaker wires
Sensitivity: 85 dB Adjustments: Volume, Crossover frequency, Phase
Recommended power: 30 watts
Dimensions: 22”h x 9”w x 15”d Sensitivity: 85 dB
Weight: 45 lbs. each Weight: 48 lbs. each
Cabinet finish - maple, cherry, and piano black Cabinet finish - maple, cherry, and piano black
Stands –Retail $500/pair
Dimensions: 27”h x 13”w x 14”d
Weight: 38 lbs each
Finish: Gloss Piano Black
2
Set Up tips for best performance
1. We highly recommend the matching stands for the ClaraVu monitors. They complete the elegant streamlined
look that can be proudly displayed in any décor and place the speakers at optimum height. You can add the
sub modules when you want to upgrade to a full range system. The following instructions refer to setup for a
full range system.
2. In placing the speakers in a room, there are several considerations:
a. Place the sub modules on a firm foundation. It is a good idea to use the included bubble leveler to
ensure the top plate of each stand is level. Use the adjustable spikes under the sub’s feet to level the
sub modules and monitors.
b. Place the included metal discs under the sub spikes on hardwood floor to protect it.
c. Place the monitor speaker on top of the sub module, aligning them to make an integrated system.
d. A good starting point for setting up speakers is using the golden rule, explained on this page on the
Internet: http://www.cardas.com/content.php?area=insights&content_id=26&pagestring=Room+Setup
e. In general, an equilateral triangle set up where the listener’s position and the 2 speakers are at the
apexes of the triangle is a good starting point.
f. The distance between the 2 speakers should be at least 6 feet apart for good stereo channel
separation and imaging.
g. In some instances, a near field set up, with the distance between the listener and each speaker is less
than the distance between the 2 speakers, could work well. Experiment with the speaker toe-in to fill
in the middle of the soundstage image.
h. A good starting point for toeing is when the insides of the speaker cabinets are just visible from the
listener’s position.
i. For best results in soundstage depth, experiment with the distance from the speakers to the wall
behind them. Pulling them further out into the room will add more depth to the soundstage.
j. Toeing the speakers in and out with respect to the listener’s position can affect the width of the
soundstage image. Make sure that you achieve good channel separation with a strong center image.
k. Moving the speakers closer to the wall can help to strengthen the bass. Pull the speakers away from
the wall can fix boomy bass problems.
3. The ClaraVu speakers are easy to set up but do take time to dial in the best position for them.
4. In some instances, turning the monitors upside down on the sub modules so that the tweeters are on the bottom
may help bass performance and soften the high frequencies. Experiment to see which suits you best.
5. There are three ways to hook up the sub modules in a full range system:
a. The preferred method is via a low-level connection out of the preamp outputs. This option allows for
the full use of the volume, crossover frequency, and phase adjustments. If your preamp has two sets
of RCA outputs, use one set to drive the main amp and the second set to drive the sub amps. If the
preamp has only one set if outputs, use line splitter connectors to create two sets of outputs. Connect
the preamp outputs to the RCA inputs of the sub amps in the back of the cabinets. Connect the
speaker wires from the main amp to the monitor speaker binding posts. Make sure that the On-Off
switch of the sub amp is Off and plug the sub amp power cord into the wall socket. Turn the On-Off
switch to the Auto position. Set the Phase switch to the Normal position. Turn the crossover
frequency knob all the way to the right and the volume knob to the 10 o’clock position. Using an SPL
meter like the Digital-Display Sound-Level Meter Model: 33-2055 found at a Radio Shack store and a
test disc with lower frequency tracks such as the Stereophile Test Disc Number 1, measure the SPL
level for frequencies from 20 Hz to 500 Hz. Use the volume and crossover frequency knobs on the
sub amp to adjust for the flattest frequency response possible. Experiment with the crossover and
volume adjustments on the subwoofer for best results.
b. An alternative method is via a high-level connection from the main amp speaker binding posts. This
option uses a fixed crossover frequency of 125 Hz and only allows volume adjustment. Connect the
speaker wires from the main amp to the lower set of the sub module binding posts. Use a set of
speaker jumpers to connect the upper set of the sub module binding posts to the monitor binding
posts, making sure that the positive and negative wires are properly aligned. Use the volume knob to
adjust for the best sound possible.
c. The third way to hook up the subs is to use a set of biwire speaker cables to connect to the binding
posts of the monitors as well as the LOWER set of binding posts on the subs. This way, both the
monitors and the subs are being driven in full range mode and the only control is the sub volume.
3
Do not use household cleaners such as Windex or an alcohol-based cleaner to clean the finish as they
may dull and craze the shiny surface. We recommend using Novus plastic cleaner and scratch remover that
can be purchased at any Harley Davidson store (used to clean shiny surfaces on motorcycles).
WARRANTY
The Gingko Audio ClaraVu 7 carries a two-year warranty against manufacturing
defects. Please complete, detach, and return the bottom of this page to:
GINGKO AUDIO
8 Nicklaus Lane
Farmingdale, NJ 07727
USA
Should your ClaraVu 7 ever need warranty or repair service, please contact us by
calling 732-946-9439 or send an email to gingko@gingkoaudio.com. Do not attempt
to repair the speakers yourself as it will void the warranty. Make sure you obtain a
Return Authorization Confirmation before sending the speakers back to us. Please
keep and reuse the speaker boxes and packing material to ensure safe shipping to us.
GINGKO AUDIO CLARAVU WARRANTY REGISTRATION
NAME:
ADDRESS:
EMAIL:
I BOUGHT THE GINGKO AUDIO CLARAVU 7 FROM:
AUDIO STORE ______ DIRECT FROM GINGKO AUDIO _____
OTHERS ______
I PLAN TO USE THE CLARAVU IN A SYSTEM WITH THE FOLLOWING COMPONENTS:
SOURCES
__________________________________________________________________________________
PREAMP
__________________________________________________________________________________
AMPLIFIER
__________________________________________________________________________________
OTHERS
__________________________________________________________________________________
