Global American Inc. 3007680 Manuale utente
User’s Manual
Version 1.0
PC/104 CPU Module 3007680
Table of Contents
Chapter 1 - Introduction
1.1 Copyright Notice.............................................................1
1.2 About User’s Manual .....................................................2
1.3 Warning.............................................................................2
1.4 Replacing the lithium battery ......................................3
1.5 Technical Support ..........................................................3
1.6 Warranty............................................................................4
1.7 Packing List .....................................................................5
1.8 Ordering Information .....................................................5
1.9 Specication....................................................................6
1.10 Board Dimensions........................................................7
Chapter 2 - Installation ......................................................9
2.1 Block Diagrams............................................................ 10
2.2 Jumpers and Connectors ...........................................11
Jumpers................................................................................. 12
JRS1: COM 2 RS-232/422/485 Select.....................12
LLED1: LAN LED Indicators...................................12
JFRT1: Switches and Indicators............................12
JBAT1: CMOS Setup ...............................................13
CON1: RS-422/ 485 Connector...............................13
Connectors ........................................................................... 14
KBM1: Keyboard & Mouse Connector ..................14
LAN1: Fast Ethernet Connector.............................14
IDE1: 44 pin IDE Connector....................................15
PWR1: Power Supply Connector...........................15
PC/104: PC/104 ISA Interface .................................16
IR1: Intrared Connector ..........................................17
VGA1: CRT Connector............................................17
USB1: USB Connector............................................17
FDD1: 20-pin FDD Connector.................................18
CON1: RS-422/ 485 Connector...............................18
LPT1: 20-pin Parallel Port Connector....................18
LCD1: TTL LCD Connector.....................................19
COM1/ COM2: Serial Port Connector ....................19
CFD1: CompactFlash II Socket ..............................20
1Chapter 1
Introduction
Chapter 1 - Introduction
1.1 Copyrights
This manual is copyrighted and all rights are reserved. It does not allow any non
authorization in copied, photocopied, translated or reproduced to any electronic or
machine readable form in whole or in part without prior written consent from the
manufacturer.
In general, the manufacturer will not be liable for any direct, indirect, special, incidental
or consequential damages arising from the use of inability to use the product or
documentation, even if advised of the possibility of such damages. The manufacturer
keeps the rights in the subject to change the contents of this manual without prior
notices in order to improve the function design, performance, quality and reliability. The
author assumes no responsibility for any errors or omissions, which may appear in this
manual, nor does it make a commitment to update the information contained herein.
Trademarks
Intel is a registered trademark of Intel Corporation.
Award is a registered trademark of Award Software, Inc.
All other trademarks, products and or product's name mentioned herein are mentioned
for identification purposes only, and may be trademarks and/or registered trademarks of
their respective companies or owners.
1
1.2 About User’s Manual
This User’s Manual is intended for experienced users and integrators with
hardware knowledge of personal computers. If you are not sure about any
description in this User’s Manual, please consult your vendor before further
handling.
1.3 Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should always follow
the following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside.
2. Hold the board by the edges and try not to touch the IC chips, leads or
circuitry.
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that came
with the Single Board Computer, whenever components are separated
from the system.
2
1.4 Replacing the lithium battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery
type recommended by the manufacturer.
Do not throw lithium batteries into the trashcan. It must be disposed of in
accordance with local regulations concerning special waste.
1.5 Technical Support
If you have any technical difculties, please consult the user’s manual rst.
Please do not hesitate to call or e-mail our customer service when you still
can not nd out the answer.
3
1.6 Warranty
This product is warranted to be in good working order for a period of two
years from the date of purchase. Should this product fail to be in good
working order at any time during this period, we will, at our option, replace
or repair it at no additional charge except as set forth in the following terms.
This warranty does not apply to products damaged by misuse, modications,
accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of,
or inability to use this product. Vendor will not be liable for any claim made
by any other related party.
Vendors disclaim all other warranties, either expressed or implied, including
but not limited to implied warranties of merchantibility and tness for
a particular purpose, with respect to the hardware, the accompanying
product’s manual(s) and written materials, and any accompanying hardware.
This limited warranty gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.
4
1.7 Packing List
If any of the above items is damaged or missing, contact your vendor
immediately.
1.8 Ordering Information
3007680
PC/104 CPU module with AMD Geode™
LX800 (500MHz), 1 x SO-DIMM, CRT/
LCD & LAN
1208420 (Optional)
Cable Kit
1 x USB Cable
2 x COM Port Cable
1 x FDD Flat Cable
1 x IDE Cable
1 x Parallel Port Cable
1 x LAN Cable
1 x VGA Cable
1 x KB/MS Cable
1 x 3007680 PC/104 CPU Module
1 x CD-ROM
1 x Quick Installation Guide
5
1.9 Specication
Form Factor PC/104 CPU module
Processor AMD Geode™ LX Series processor
Cache 64K L1 cache and 128K L2 cache
Chipset AMD LX800 + CS5536
System Memory 1 x 200-pin DDR SO-DIMM socket up to 1GB
SDRAM
VGA/ LCD Controller
AMD Geode LX series CPU integrated VGA
controller with 2D Engine (Shared memory Max.
64MB)
Ethernet Realtek 8100CL 10/100 base-T Ethernet
LCD Supports 18/24-bit TTL up to 1280 x 1024
I/O Chips W83627HG
BIOS Phoenix-Award PnP Flash BIOS
IDE Interface 1 x Ultra DMA 33, support 2 IDE devices
Serial Port 2 x RS-232 ports
COM2: RS-422/RS-422/RS-485 selectable
Parallel Port / Floppy 1 x SPP/EPP/ECP mode
1 x Floppy connector
KBMS Standard PS/2 Keyboard and Mouse
Universal Serial Bus 2 x USB 2.0 ports
PCI to ISA bridge ITE8888G
Expansion Bus 1 x PC/104 interface
Flash Disk 1 x Type II Compact Flash Disk Socket up to 4GB
Hardware Monitor Integrated in W83627HG
RTC AMD Geode CS5536 built-in RTC with lithium
battery
Power Input Connector 1*4-pin power connector
Operation Temp. -40 ~ 80ºC (-40 ~ 176ºF)
Watchdog Timer 1 - 255 Level (Sec. or Min.)
Dimension (L x W) 96 x 90 mm (3.8” x 3.5”)
6
