Global Sat DG-200 Manuale utente

Quick Start Guide

DG-200

GPS DATA LOGGER

Appearance

Power LED Red / orange

Mini USB Charging / transmitting

Memory LED Blue

GPS LED Green

Power/ Save button

Accessories

Note:

If any item is missing or damaged, please contact with your local retailer.

DG-200 Unit USB CableCD Quick Guide AC Charger Hang Tape

Optional:

DG-200 Operation

1. Press and hold the power button for three seconds to turn on DG-200.Then you would see GPS LED on.

2. After getting GPS fix and starting to record traveled path, GPS LED would flash.

3.When DG-200 could get GPS fix, you could short click power button to save the present location to inner memory flash.

You could see memory LED flash once to show the present location is saved.(You could not save location if it could not

get GPS fix.

DG-200 Power Off

Under power-on status, press and hold power button for three seconds to turn off device. GPS LED would be off after

device is powered off.

DG-200 Connection with PC

1. Connect DG-200 and PC by USB cable.

2.Turn on DG-200 PC Utility.

3. Run“PC Utility” program and you could use the functions of the program.

DG-200 Power Button LED status after turning on device

USB Cable connection

Start to Use

DG-200 PC Utility Operation

Menu bar:

Tool bar:

Traveled path data list:

List the traveled path data loaded from DG-200 or from file

Traveled path information field:

Show the information of traveled data, including date, time, longitude, latitude, speed, and height

(according to the DG-200 data setting)

Google Map Display:

Show the selected point of the traveled data list on Google Map

5

12

3

4

1

2

3

4

5
