Global Sat LT-300 Series Manuale utente
GlobalSat LT-300 Series
User Manual
Version: 1.0
GlobalSat WorldCom Corporation
16F., No. 186, Jian 1st Rd, Zhonghe Dist.,
New Taipei City 23553, Taiwan
Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899
service@globalsat.com.tw
www.globalsat.com.tw
USGlobalSat Incorporated
14740 Yorba Court Chino, CA 91710
Tel: 888.323.8720 / Fax: 909.597.8532
sales@usglobalsat.com
www.usglobalsat.com
1
TABLE OF CONTENTS
1. Warning ................................................................................................................................................. 3
2. Welcome................................................................................................................................................ 4
3. Introduction and Features...................................................................................................................5
3.1 Introduction.....................................................................................................................5
3.2 LED Indicators................................................................................................................6
4. Device Operation.................................................................................................................................. 7
4.1 Device charging ..............................................................................................................7
4.2 Power ..............................................................................................................................8
4.3 Geo-fence button.............................................................................................................9
5. Contact Information ...........................................................................................................................10
6. Safety Information..............................................................................................................................10
7. Limited Warranty ................................................................................................................................ 11
2
1. Warning
USE RESPONSIBLY. READ ALL INSTRUCTIONS AND
SAFETY INFORMATION BEFORE USE.
Globalsat Worldcom Corporation / USGlobalsat, Inc., will not accept any responsibility
whatsoever for accidents or violations of local Laws resulting from failure to observe
common sense precautions and local laws. Your personal judgment, traffic regulations,
and common sense must always take precedence over any directions produced by GPS
receiver or the mapping software.
Indemnification:
User agrees to defend, indemnify and hold harmless GlobalSat WorldCom Corp. and USGlobalsat,
Inc., its officers, directors, employees and agents against and from any third party claims, actions,
damages or demands, including but not limited to, reasonable legal and accounting fees, resulting from
user's use or misuse of this product, violation of these Terms, or any activities related to this product, or
from user's violations of the rights of any other user of this product. Use of this Product is at user's own
risk.
3
2. Welcome
Thank you for purchasing the GlobalSat LT-300. The LT-300 is a sleek, compact and
feature rich asset monitoring tracking device. The LT-300 unit incorporates a wide array of
custom feature, functions and configurations for unique client requirements. We
appreciate your purchase of a GlobalSat Worldcom Product!
4
3. Introduction and Features
3.1 Introduction
LT-300 is set to work with interactive Moving Object Security & Tracking Solution. (iMOST)
Which is a LoRa tracking device with fast GPS acquisition time. It is compact, portable and
stylish in design capable to connect LoRa wireless networks. Users can easily and
remotely configure LT-300 and display GPS locations on remote monitoring / tracking
platforms.
1 Help Notification Button
2 Power LED
3 LoRa LED
4 GPS LED
5 Power Button
6 Battery Charging Contacts
7 Lanyard Holes
5
3. Introduction and Features (Continued)
3.2 LED Indicators
Power Status LED
LED
Orange
Constantly Lit
Orange
Blinking Red
Constantly Lit
Red Blinking
Quickly
State LT-300 is fully
charged. LT-300 is being
charged. Battery power is
low USB
configuration
mode
LoRa LED
LED
Blinking Quickly
State Data transmitting.
GPS LED
LED
Blinking Quickly
(Once per second)
Blinking Slowly
(Once every 3 seconds)
State LT-300 is searching for GPS fix
LT-300 receives GPS fix
6
4. Device Operation
4.1 Device charging
Using the device for the first time, rechargeable battery will require a complete 100%
charge before LT-300 is operable. To maximize your device’s battery life, proceed by
performing the steps listed below.
1. Connect the charging clip to LT-300's battery charging contacts and connect the
USB side to AC adaptor.
2. Allow at least 4 hours of battery charging time.
7
4.2 Power
1. To turn the device “ON”, press and hold the power button for 3 second.
2. To turn the device “OFF”, press and hold the power button for 3 seconds until the
device vibrates.
3. To perform a hard reset, press and hold the power button for 8 to 10 seconds.
8
4.3 Notification button
Help Notification Function:
While pressing and holding the Help Notification button for 3 seconds, LT-300 would be
vibrating and start to get GPS fix. GPS LED indictor would keep blinking till device gets
GPS fix. After getting GPS fix, LoRa LED indicator would keep blinking till the location
data has transmitted. Once iMOST LoRa gateway received Help Notification from LT-300
Tracker node, it would vibrate again to confirm receive.
9
5. Contact Information
GlobalSat WorldCom Corporation
Address: 16F., No.186, Jian 1st Rd., Jhonghe Dist., New Taipei City ,
Taiwan TEL: +886-2-82263799 FAX: +886-2-82263899
6. Safety Information
•Please consult your airline prior to the operation of this product in the aircraft. . Operating this
product in environments emitting intensive radio waves or radiation can affect the operation and
functionality of this product.
•Avoid use in humid or rainy environment. Water ingress can disable or destroy this product beyond
repair.
•Avoid using this product in a dusty environment. Dust ingress can compromise the products ability
to function.
•Avoid situations that include Over-voltage, over charging, power cable damage may cause
overheating or potential fire disaster.
•Never use any chemical or detergent to clean the Personal Tracker to prevent erosion of the surface
or paintwork.
•In order to eliminate the risk of electric shock, make certain the charging cable is completely
inserted / seated, do not touch the power cable plug / connectors with wet or damp hands.
•Do not charge the Device in any extreme cold or hot temperatures, which may cause damage to the
device.
•Keep out of the reach of children during charging.
•Avoid direct prolonged exposure to sunlight and high temperatures to avoid the potential
over-heating of the battery of this product, which may cause damage.
•Please do not attempt to repair this device yourself, contact Globalsat or USGlobalSat for Technical
Support.
•Keep all the wires tidy in order to prevent damage or tangling.
10
