Glowworm Swift flow 100e Manuale utente

100e 80e 75e

221062A.02.97

Installation Instructions

Tobeleftwiththeuser

Hepworth Heating Ltd.,

Nottingham Road, Belper, Derbyshire. DE56 1JT

General/Sales enquiries :

Tel: (01773) 824141 Fax: (01773) 820569

One Contact Total Service

Customer Services:

Tel: (01773) 828100

Fax: (01773) 828070

Digital Clock/Timer

Kit Style 2

These instructions are for the installation and setting of

the digital clock/timer Style 2.

Instructions on how to use and service are supplied with

the boiler.

Note. The boiler Installation Instructions will be

required should the clock/timer be fitted to an already

fitted boiler.

If the literature is not to hand, copies can be obtained

from:-

Hepworth Heating Ltd

Nottingham Road

Belper

Derbyshire

DE56 1JT

Telephone 01773 824141.

It is important to quote the model, size and serial

number.

This is a Cat I 2H Appliance

100 80 75

Digital Clock / Timer

221062A

5653

CONTENTS OF KIT

1 Casing label

2 Instructions sheet

3 Clock/timer

4 Spacer

5 Clock/timer bracket

6 Clock/timer harness

7 “Snapin” cable bush

Digital Clock / Timer

221062A

Diagram 3

100 ILLUSTRATED

Diagram 2

3910

100 ILLUSTRATED

CLOCK/TIMER

MOUNTING

BRACKET

FASCIA

SECURING

SCREWS

3887

CONTROL

HOUSING

COVER

SECURING

SCREWS (2)

3909

CONTROL

HOUSING

COVER

SECURING

SCREW

Diagram 1100 ILLUSTRATED

FASCIA

SECURING

SCREWS (2)

CONTROL

HOUSING

COVER

Diagram 4

CONTROL

HOUSING

SECURING

SCREW

4 WAY

TERMINAL

BLOCK

*Remove yellow link

BBRYY

BRBYY

5346

continuation of “Boiler Fixing”

Remove two of the fascia securing screws,

see diagram 1.

Remove the control housing securing screw and cover,

see diagram 1.

Fit the clock/timer bracket and loosely secure with the

two previously removed fascia securing screws, see

diagram 2.

Remove the control housing securing screws,

see diagram 3.

Secure the control housing to the frame with one of these

screws, see diagram 4.

Remove the four way terminal block from the top left

hand side of the control box, see diagram 4.

Fit the clock/timer to the bracket, see diagram 5.

Route wiring harness through the keyhole slot in the side

of the control box, insert the “snap in” cable bush and

connect to the clock/timer and four way terminal block

connector, see diagram 6.

Remove the clock/timer blanking plate from the outer

case and use the new blanking plugs supplied.

Stick the casing label, from the loose items pack, to the

right hand side of the clock/timer.

Note. Some adjustment of the clock/timer bracket may

be required to allow for a satisfactory alignment of the

outer casing.

Now continue with “Boiler Fixing”, as described in the

Installation Instructions.

Digital Clock / Timer

221062A

AUTO RUN

MT WThFSSu

DAY HR MIN

Diagram 5

CLOCK/TIMER

MOUNTING

BRACKET

RETAINING

CLIP (2)

5657

SPACER

Because of our constant endeavour for improvement details may vary slightly from those in the instructions.

DIGITAL CLOCK/TIMER STYLE 2

5650

Diagram 7

Setting Instructions for SWIFT-FLOW

Digital Timer Style 2.

The following instructions are provided so that, if the

Instructions for Use are missing the clock/timer can be

set working.

This is a twenty four hour clock, that is 1pm is 1300.

1. Press “R” Reset.

2. Set switch to “ ”.

3. Set time of day “HR” “MIN”.

4. Set day of week “DAY.

5. Set switch to “RUN” - colon will flash.

Once this is done the following preset times will

operate:-

MON to FRI - “ON” 06.30

“OFF” 08.30

“ON” 16.30

“OFF” 22.30

SAT and SUN - “ON” 07.00

“OFF” 09.00

“ON” 16.00

“OFF” 23.00

COMMON

MAINS

NEUTRAL

(N)

HEATING ON

MAINS

LIVE (L)

KEY

BROWN

BLUE

YELLOW

YDiagram 6

BR B

ELECTRICAL

CONNECTORS

CLOCK/

TIMER

4 WAY

TERMINAL

BLOCK

*Remove yellow

*link

BBRYY

BRBYY

5347

RESET

BUTTON
