AIR PURIFIER
User Manual
Model: GMC120AP
pg. 2 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
CONTENTS
IMPORTANT NOTES ………………………………………………………3
SAFETY INSTRUCTIONS ………………………………………………….4,5
COMPONENTS ………………………………………………………………6
INSTALLATION ………………………………………………………………7
OPERATIONS …………………………………………………………………8,9
MAINTENANCE ……………………………………………………………..10
SPECFICATIONS/FEATURES ……………………………………………11,12
TROUBLESHOOTING ………………………………………………………13,14
SERVICE AND WARRANTY ……………………………………………...15
pg. 3 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
IMPORTANT NOTES
N.B PLEASE REMOVE THE PLASTIC FROM THE
INTERNAL FILTER BEFORE USING THE MACHINE.
Dear Customer
Your new GMC Air Purifier has been manufactured in a state-of-the-art facility and
has passed the strictest quality control procedures. Please read this manual carefully
before using your appliance for the first time and then please store this manual in a
safe place for future reference.
Thank you again for choosing GMC.
If you have any issues at all with your product or any questions then the quickest
route for resolution is to please contact us through our website
www.gmcaircon.co.za or on 012-661-1173.
We will be able to resolve any issues that may arise and our technical team is always
on hand for assistance. We pride ourselves on 100% customer satisfaction and we
trust you will enjoy your new product.
IMPORTANT! PLEASE REMOVE THE PLASTIC FROM
THE INTERNAL FILTER BEFORE USING THE AIR
PURIFIER.
pg. 4 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
Safety instructions
• Check the voltage of 100-240V~ 50-60Hz before use.
• Check the power supply unit and the power cable before plugging them in.
• When not in use, unplug the AC adapter from the wall outlet.
• Do not insert any objects into the air inlets and outlets of the unit. It may cause a
short circuit. Special care must be taken when operating the device within the reach
of children.
• Use the mains and/or power switch to switch the unit "on and off".
• Never use the power supply unit/line to switch the unit "on and off".
• Before changing the device, switch it off and unplug the power supply unit from
the socket.
• Never attempt to clean the air inlets or outlets with sharp objects.
• Never immerse the appliance in water.
• Never spray flammable liquids into the device.
• Never operate the appliance in a damp room (e.g. bathroom). Risk of electric
shock or power transfer.
• Never use hairsprays, thinners or flammable gases in the vicinity of the device, as
there is a risk of fire and explosion.
• If candles or gas ovens burn in the same room during operation, open the window
occasionally.
• Never cover the air inlet or outlet and keep away any moving textiles that may
block the air inlet or outlet. This can damage/destroy the blower motor.
• When handling the appliance, make sure that your hair or clothing does not get
into the air outlet. These could be detected by the fan wheel.
• Always position the device on a flat, horizontal and dry surface.
pg. 5 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
• Never operate the device near heat sources such as heaters, open fires or direct
sunlight. The plastic parts can be deformed.
• The unit does not serve as a fan replacement. This considerably shortens the
service life of the filter.
• The device must not be used in an environment containing high levels of dust or
chlorine.
• Do not place heavy objects on the unit and keep it out of the reach of children.
• The device must not be used in closed, narrow or excessively warm rooms.
• Make sure that the mains cable is not pinched, excessively bent or twisted, as
otherwise the cable wire can be exposed and/or damaged.
• If the mains cable is damaged, stop operation and replace it immediately.
• Only use the power supply included in the scope of delivery. Do not use a power
supply unit from another device.
• Do not use the included power supply for other devices.
• If the device is defective, switch off the mains switch and disconnect it.
• To avoid interference, do not operate the equipment near microwaves or television
sets.
• The device may only be operated by persons who are physically and mentally
capable of correct operation in accordance with these operating instructions, or who
have been instructed on this device by a responsible person.
• Never switch the appliance on or off with wet hands.
• Do not attempt to repair or make any other adjustments, both electrical and
mechanical, to the unit yourself.
• Do not let children play with the packaging, such as plastic films.
• Ensure a minimum distance of 20 cm between the unit and the nearest wall.
pg. 6 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
Components
1 Air outlet
2. Ring
3. Housing
4. Air inlet
5. DC socket
6. Bottom plate
7. Filter
8. Base
9. Power adapter
Packing list
Air purifier
User manual
Adapter
pg. 7 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
INSTALLATION
1. Invert the equipment after unpacking it.
2. Rotate the base cover to take out the filter by the guide arrow.
3. Install the filter after opening the package. Rotate the base cover in revert direction described as step 2.
4. Plug on with the power adapter.
Install the bottom cover
clockwise
Take out the transparent
packaging bag
Turn the bottom cover
counterclockwise and
take out the filter
Place the product on a flat surface,
insert the adapter and connect the
power supply
Remove the packaging bag of
the filter and put the filter back
according to the direction
pg. 8 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
OPERATIONS
Control Panel
1.Speed display
2.PM2.5 display
3.Reset
4.Timer
5.Sleep mode button
6.Auto
7.Ion
8.UV
9.Timer button
10.Power button
Understanding the air quality light
The color of air quality light corresponds to the ambient air quality.
The brightness of air quality light reflects the current running mode.
Air Quality
PM2.5
Color indicator
Very Good
10-60
Green
Moderate
61-150
Orange
Bad
151-300
Red
PM2.5
Fine dust is also known as PM2.5. This refers to the size of the dust particles, half of which
at PM2.5 are particles with a diameter of 2.5μm and a smaller proportion of larger particles
and a larger proportion of smaller particles.
The size of the fine dust is usually less than that of a bacterium and can therefore not be
seen with the naked eye.
pg. 9 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
MODE
MENU
FUNCTIONAL DESCRIPTION
ON/OFF
Press the POWER button to start and stop the unit.
The device starts working in Auto Mode.
After 10 seconds, the air quality indicator will show the air
quality and automatically and select a suitable speed according
to the air quality. The digital display will show the PM2.5 data.
FILTER
RESET
After running for 2000 hours, the RESET light will be light up
on the display to remind user to replace the filter.
After replacing the fitter, long press the POWER button for 5
seconds to reset . the life time of filter will restart .
ION
UV
Negative ions and UV are turn on automatically when turn on
the device. Press this button to switch the UV light and
Negative Ion on or off.
MANUAL
CONTROL/
AUTO MODE
By repeatedly pressing the Speed button, the fan speed
between 1 (low) and 5 (high) and the Auto Mode can be
selected.
If you use the unit in AUTO mode, the fan is controlled via the
air quality sensor (PM2.5).
The Auto mode can be left by simply pressing the speed
button.
SLEEP
MODE
Pressing the Sleep button to activate the sleep function. This
mode behaves as follows:
• The display illumination including all displays, with the
exception of the Sleep display, is switched off.
• The device switches to the lowest and therefore quietest fan
level.
• The LED ambient light is switched off.
• To exit sleep mode, press any key.
TIMER
With the timer you can set the running time of the device.
It can be selected between 1 and 8 hours by repeatedly
pressing the button. If the timer function is activated, the
display shows alternately the PM2.5 value and the remaining
running time.
When the time has elapsed, the unit switches itself off
automatically.
pg. 10 For enquiries or support : visit www.gmcaircon.co.za or contact us on 012-661-1173
Maintenance
Filter change
After some time in operation, the main filter must be replaced. The filter life is 2000
Hours
Filter change indicator:
The unit is equipped with a modern filter change indicator.
If the filter has to be checked/replaced, this is indicated by the RESET light flashing
on the display.
If the filter has been replaced, the filter change indicator must be reset again. long
press the POWER button for 5 seconds to reset the air purifier.
Change the filter:
Switch and disconnect the device for this purpose. Put it upside down and open the
filter cover at the bottom of the unit and remove the filter.
Please note that the replacement filter must be removed from the protective film
before it can be inserted into the device. Finally, the filter must be locked again.
Cleaning the device
Always disconnect the power supply from the socket before cleaning!
Clean the appliance with a dry cloth. Do not use chemicals. You can also clean the
air inlets with a vacuum cleaner (it is best to clean the unit outdoors).
