GO Systemelektronik BlueSense Manuale utente

Manual

BlueSense

Transducer

Version of the manual: 3.1 en

www.go-sys.de

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 2 / 55

www.go-sys.de info@go-sys.de

This Manual contains information which is the intellectual property of GO Systemelektronik GmbH. The user

is obliged to use this information exclusively to run the instrument. It is not permitted to pass this information

to third parties. Reproducing, copying, editing or extracting the manual contents is only allowed with the ex-

press permission of GO Systemelektronik GmbH.

Changes

GO Systemelektronik GmbH retains the right to modify the contents of the manual without prior notice.

Liability Exclusion

GO Systemelektronik GmbH takes no responsibility for correct system operation under all possible operating

conditions. It is not possible to guarantee that the software will function completely without error under all

possible circumstances. GO Systemelektronik GmbH can not therefore accept liability for direct or indirect

damage resulting from system operation or the contents of this manual.

Product Observance

Within the scope of our obligation for product observance GO Systemelektronik GmbH will endeavour to warn

third parties about all identified dangers which could arise from the interaction between hardware and soft-

ware and from the use of other components. Effective product observance is only possible with adequate

information from the end user about the planned field of application and the hardware and software used. If

the conditions of use change or if the hardware or software has changed, due to the complex relationships

between hardware and software it is no longer possible to describe all possible dangers and their effects on

the total system, in particular on our system. This manual does not describe every possible property and

combination of the system. For further information, please contact GO Systemelektronik GmbH.

Manufacturer's declaration

In setting up the device it is important amongst other things to note the correct electrical connections, protec-

tion against connections to foreign bodies, humidity, protection against excessive moisture due to condensa-

tion and to the overheating of the device in proper and improper use.

The implementation of these measures is the responsibility of the installers who setup this device.

Faluner Weg 1

24109 Kiel

Allemagne

Tel.: +49 431 58080-0

Fax: +49 431 58080-11

www.go-sys.de

info@go-sys.de

Creation date: 27.5.2015

Described firmware version: 3.00

Manual version: 3.1 en

Article number of the manual: DOC 485 0001-E-3.1-BDA

File name: Manual BlueSense Transducer V3p1 en.pdf.pdf

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 3 / 55

www.go-sys.de info@go-sys.de

blank page

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 4 / 55

www.go-sys.de info@go-sys.de

Table of contents

1 Overview..........................................................................................................................................................................6

2 Technical data and connection diagrams....................................................................................................................8

2.1 Technical data .........................................................................................................................................................8

2.2 Connection diagram 1 control parameter.............................................................................................................9

2.3 Connection diagram 2 control parameter.............................................................................................................9

2.4 Sensor terminal connection diagram ..................................................................................................................10

3 Commissioning .............................................................................................................................................................11

4 Turning on the system..................................................................................................................................................13

4.1 Parameter Display and Main Menu......................................................................................................................13

4.1.1 Parameter Display..........................................................................................................................................13

4.1.2 Main Menu.......................................................................................................................................................14

5 Setup .............................................................................................................................................................................15

5.1 Sensors ...................................................................................................................................................................16

5.1.1 Oxygen sensor setup (control parameter) ....................................................................................................17

5.1.1.1 Calibration ...............................................................................................................................................18

5.1.1.1.1 Example 1-point-calibration oxygen...............................................................................................18

5.1.1.1.2 Example 2-point-calibration ORP....................................................................................................19

5.1.1.2 Relay.........................................................................................................................................................20

5.1.1.3 Current Output.........................................................................................................................................21

5.1.1.4 Change Name ..........................................................................................................................................22

5.1.1.5 Parameter ................................................................................................................................................22

5.1.1.5.1 Minimum value and Maximum value ..............................................................................................23

5.1.1.5.2 Average and Interval ........................................................................................................................24

5.1.2 Temperature sensor setup (associated parameter) ....................................................................................25

5.1.3 Digital In..........................................................................................................................................................25

5.2 Reset .......................................................................................................................................................................26

5.3 Comport .................................................................................................................................................................27

5.3.1 Protocol selection...........................................................................................................................................28

5.3.2 Modbus address input....................................................................................................................................28

5.4 Language setting...................................................................................................................................................29

5.5 Time / Date.............................................................................................................................................................30

6 Screen............................................................................................................................................................................31

7 Memory Card.................................................................................................................................................................32

7.1 Save Data ...............................................................................................................................................................32

7.2 Adjustment of the storage interval.......................................................................................................................33

7.3 Update (Firmware) ................................................................................................................................................33

7.4 Read Data ..............................................................................................................................................................34

8 Programs.......................................................................................................................................................................35

8.1 Flushcontrol Parameters ......................................................................................................................................37

8.2 Parameter PID .......................................................................................................................................................38

8.2.1 Parameter PID (Sensor selection)..................................................................................................................40

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 5 / 55

www.go-sys.de info@go-sys.de

9 Info Transducer.............................................................................................................................................................40

10 Version notice .............................................................................................................................................................41

11 Installation notes........................................................................................................................................................41

12 Maintenance instructions ..........................................................................................................................................41

Appendix A - Modbus .......................................................................................................................................................42

Appendix B - Connection to a BlueBox...........................................................................................................................45

Appendix C - Adjustment of the touch display...............................................................................................................46

Appendix D - Housing dimensions..................................................................................................................................47

Appendix E - Status and error messages .......................................................................................................................48

Appendix F - DIP switch configuration ...........................................................................................................................50

Appendix G - Differentiation motherboard Version AB.............................................................................................50

Appendix H - Multipoint calibration ...............................................................................................................................51

Appendix I - Menu structure ............................................................................................................................................53

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 6 / 55

www.go-sys.de info@go-sys.de

1 Overview

This user manual describes a BlueSense-Transducer.

The Transducer

•receives the signals of the connected sensors,

•generates there from measurement values,

•displays the measurement values,

•transduces the measurement values into analogue current values (4 – 20 mA),

•transmits the current values to a signal processing systems,

•transmits the measurement values via CAN-bus to a BlueBox,

•is able to network with PLC1-Systems via RS-232 or RS-485,

•stores the measurement values on a SD Memory Card,

•switches relays by overrun or underrun of settable alarm values,

•converts the measurement values of a conductivity sensor into salinity2,

•switches two internal relays at adjustable times (here called Flushcontrol),

•executes a relay control program and a PID controller

•and executes customer-specific programs.

Connectable sensors:

•Conductivity: measuring principle: inductive 0 to 4000 µS/cm

with integrated temperature sensor: measuring principle: NTC 0 to 80°C

•Temperature: measuring principle: NTC -5 to +80°C

Standard temperature sensor SEMI 833 25°C ≙83 kΩ

•Dissolved oxygen: measuring principle: galvanic cell 0 - 20 mg/l

•Dissolved oxygen: measuring principle: fluorescence 0 - 25 ppm

•pH glass electrode pH3 - pH13

•Ion-selective electrode

•Turbidity submersible: scattered light 90°, wave length 860 nm 0 - 3000 FNU

•Turbidity flow through: scattered light 90°, wave length 860 nm 0 - 100 FNU

•ORP -2000 to +2000 mV

•Current input, resistance 50 Ohm 4 - 20 mA

•Voltage input 0 - 50 V and other

•All established sensors with current or voltage outputs, e.g.: Cl, ClO2, NH4, etc.

The number of sensors that can be connected is determined by the delivered Transducer configuration.

There are two configurations:

•1 Control parameter = 1 analogue input

One sensor is connected. One control parameter is measured and where applicable the temperature

as an associated parameter.

•2 Control parameters = 2 analogue inputs

Two sensors are connected. Two control parameters are measured and where applicable the tem-

perature for each sensor as associated parameters.

To determine if your Transducer has 1 or two 2 control parameters please

refer to the shipping note, the serial number of the transducer is on the

right hand side of the housing.

1Programmable Logic Controller

2Salinity according to the general formula of the UNESCO for seawater

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 7 / 55

www.go-sys.de info@go-sys.de

The Transducer has 4 relays:

•2 relays with a switching capacity of 24 V / 0.5 A (only low-voltage)

•2 relays with a switching capacity of 230 VAC / 2 A or 24 VDC / 6 A

The transducer can store the states of the inputs (and therefore also the measured values) and the error mes-

sages on an SD Memory Card. The Transducer itself has no memory.

The Transducer is operated via a touch screen. Through a few steps one can, for example, undertake calibra-

tions and set switching values.

The menu options are displayed in simple to understand text.

Basic structure of the menu navigation:

see Appendix I - Menu structure

1 Oxygen

8.0 mg/l

2 Temperature 1

18.4 °C

3 Conductivity

414 µS/cm

4 Temperature 2

19.0 °C

5 Salinity

5.4 ‰

6 Pulse 1

10 1/m

11 : 21 : 57 10 . 04 . 2013

Digital In

1432

Relais

1432

Parameter Display

Main Menu

Comport

Sensors

Setup

Memory Card

Programs

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 8 / 55

www.go-sys.de info@go-sys.de

2 Technical data and connection diagrams

2.1 Technical data

Article-Nr. 485 0001-X

Inputs:

•1 or 2 analogue inputs (1 Control parameter or 2 Control parameters)

The particular configuration is on the shipping note, the serial number

of the transducer is on the type plate at the right hand side

of the housing.

•2 digital inputs (static), potential-free contacts, switching current

approx. 6 mA

•2 pulse inputs selectable to PNP/NPN (optional: static), switching current approx. 6 mA,

measurement range 0.05 Hz – 1000 Hz

Outputs:

•2 current outputs (4 to 20 mA), active

•2 relays with a low-voltage (only) switching capacity of 24 V / 0.5 A

•2 relays with a switching capacity of 230 VAC / 2 A or 24 VDC / 6 A

Communications interfaces:∗

•RS-232 or RS-485, each with 9600 Baud, selective EMC or Modbus

•CAN-bus connector for connection to the BlueBox-System

Voltage feed:*

•12 VDC (9 V – 18 V), received power max. 7 W

•24 VDC (18 V – 36 V), received power max. 7 W

•230 VAC (90 V – 260 V), received power max. 7 W

Display: LCD Touch Panel: 240 x 128 pixels; secure temperature range -10 °C to +45 °C

Housing: Polycarbonate, 235 mm x 185 mm x 119 mm; protection code IP65;

secure temperature range -10 ° C to +45 °

Weight: 1.35 kg

∗The equipment of your transducer is documented on the sticker on the inside of the cover for the cable connections.

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 9 / 55

www.go-sys.de info@go-sys.de

2.2 Connection diagram 1 control parameter

BlueSense

GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49 431 58080-0 Fax: -58080-11 Page 10 / 55

www.go-sys.de info@go-sys.de

2.3 Connection diagram 2 control parameter

Altri manuali per BlueSense

Indice

Altri manuali GO Systemelektronik Trasduttore

GO Systemelektronik

GO Systemelektronik BlueSense Manuale utente

Manuali Trasduttore popolari di altre marche

HBM

HBM AD101B Manuale utente

Camille Bauer

Camille Bauer SINEAX F534 Manuale utente

Trane

Trane KIT 16724 Istruzioni per il montaggio

Lumel

Lumel P18 Manuale utente

B&C Speakers

B&C Speakers DE75PTN Manuale utente

MAMAC SYSTEMS

MAMAC SYSTEMS PR-243 Manuale

Mianyang Weibo Electronic

Mianyang Weibo Electronic WB Series Manuale utente

ProMinent

ProMinent Dulcometer DMT Manuale utente

MKS

MKS MicroPirani 925 Series Come usare

WIKA

WIKA WU-20 Manuale utente

Alcatel Vacuum Technology

Alcatel Vacuum Technology BARATRON 622A Manuale utente

Camille Bauer

Camille Bauer SIRAX CH-5610 Manuale utente

WIKA

WIKA F2802 Manuale utente

Veris Industries

Veris Industries PW Series Manuale utente

HBM

HBM TJ1-S6 Manuale utente

Simrad

Simrad ES120-7C - REV D Guida utente

HBM

HBM C18 Manuale utente

Airmar

Airmar M260 Manuale di istruzioni
