GOAL ZERO Lighthouse Micro Charge Manuale utente

LED LATERN + FLASHLIGHT +

RECHARGER

BEFORE FIRST USE:

Take the Lighthouse Micro Charge out of DEMO mode by

plugging it into a powered USB port.

Not near a USB port? Press the On/Off/Dimmerbutton five

(5) times and hold on the sixth (6). The Battery Indicatorwill

flash, indicating the Lighthouse is out of DEMO MODE.

Table

of Contents

Get

To Know Your Gear

How

It Works

Recharge

Your Lighthouse Micro Charge

Technical

Specifications

Français

eština

Español

GET TO KNOW YOUR

GEAR

Hanger

Flashlight Output: 115 Lumens

USB Charging Tip

1A USB Output

Lantern Output: 150 Lumens

TOPVIEW

Battery Indicator

25%

50%

75%

100%

On/Off/Dimmer

Button

Weatherproof

IPX6 Rated

PHONE USB Hour Runtime

1 Recharge Rechargeable on Lowest

Setting

Push the On/Off/Dimmer Button once for flashlight mode, twice

for full-brightness lantern mode, and three times for half-

brightness lantern mode.

a. Press and hold to dim each mode.

Using the flip-out USB tip, plug Lighthouse Micro Flash Charge

into any powered USB port to charge it up in 3.5 hours. Also

charges from 3.5 hours of full sun from the Nomad®7 (Sold

Separately)

Using an appropriate charging cable, plug into the USB output to

charge your gear. Still in DEMO MODE? See the front cover for

instructions.

HOW IT

WORKS

RUNTIME LUMENS

CHARGE TIME

Lantern - One Side (Low) 170 hours 7 lumens USB source 3.5 hours

Lantern - One Side

(High)

15 hours 75 lumens Nomad 7 3.5 hours

Lantern - Both Sides

(Low) 80 hours 20 lumens

Lantern - Both Sides

(High) 7 hours 150 lumens

Flashlight (Low) 100 hours 15 Lumens

Flashlight (High) 8.5 hours 115 Lumens

3.5 Hours

Full Sun

3.5 Hours

USB Port

Recharge from USB or solar panel.

Nomad®7

Solar Panel

(sold

separately)

RECHARGEYOUR LIGHTHOUSE MICRO

FLASH

TECHNICAL

SPECIFICATIONS

Battery

Cell chemistry Li-ion NMC

Cell type 18650

Cell capacity 9.62Wh (3.7V, 2600mAh)

Lifecycles hundreds of cycles

Shelf-life Charge every 3-6 months

Ports

USB port (input) 5V, up to 1A (5W max)

General

Durability IPX6

Weight 3.07 oz (87g)

Dimensions 4.4 x 1.5in (112 x 37.75mm)

Operating usage temp. 32-104 F(0-40 C)

Certs

Warranty 12 months

Be sure to activate your warranty at goalzero.com/warranty

GET TO KNOW YOUR

GEAR

APPRENDRE ÀCONNAITRE VOTRE

ÉQUIPEMENT

Cintre

Puissance de la lampe de poche :

115 Lumens

Prise de recharge USB

Port de sortie USB de 1A

Puissance de la lanterne :

150 Lumens

VUE DE DESSUS

Indicateur de

batterie

25%

50%

75%

100%

Bouton 'On/Off/

Dimmer'

Étanche

Classé IPX6

Rechargeable Durée de

àl'aide d'un Fonctionnement

port USB en Heure sur les

paramètres les

plus faibles

TÉLÉPHONE

1 recharge

FREQUENTLY ASKED

QUESTI

COMMENT ÇA FONCTIONNE ?

ONS

Appuyez sur le bouton 'On/Off/Dimmer' une fois pour le mode lampe de

poche, deux fois pour le mode lanterne à pleine puissance, et trois fois pour

le mode lanterne tamisée.

a. Pressez et maintenez pour atténuer l'intensité de chaque mode.

En utilisantla prise USB rétractable, branchezvotre Lighthouse Micro

Flash Charge dans un port d'alimentationUSB pour le recharger en 3.5

heures. Il se recharge aussi en 3.5 heures d'ensoleillementtotal depuis

le Nomad®7 (Vendu séparément)

En utilisantun câble de recharge approprié, branchez vos appareils àrecharger

dans sa sortie USB. Toujours en MODE DÉMONSTRATION ? Voirla page de

couverture pour les instructions.

DURÉE DE

FONCTIONNEMENT

LUMENS TEMPS DE CHARGE

Lanterne - Un côté (Faible) 170 heures 7 lumens Source USB 3.5 heures

Lanterne - Un côté (Forte) 15 heures 75 lumens Nomad 7 3.5 heures

Lanterne - Deux côtés

(Faible)

80 heures 20 lumens

Lanterne - Deux côtés

(Forte)

7 heures 150 lumens

Lampe de poche (Faible) 100 heures 15 lumens

Lampe de poche (Forte) 8.5 heures 115 lumens

GET TO KNOW YOUR

GEAR

3.5 Heures

Plein

soleil

3.5 Heures

Port USB

Se recharge à partird’une sourceUSB ou d’un panneau solaire.

Nomad®7

PanneauSolaire

(vendu

séparément)

RECHARGEZ VOTRE LIGHTHOUSE MICRO

FLASH
