GOAL ZERO Escape 30 Manuale utente

1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty

2. Open and remove the foam protector on the solar panel.

3. Prop up the legs and angle the panel towards the sun (see below).

4. Plug charging cable into your GOAL ZERO power pack.

Get to know your gear

How to use your gear

Getting Started

BEST OKAY BAD

Usage

Output

Input

General

12V charging port (4.7mm)

14-16V, 2.0A max (30W), not regulated

Weight (no pkg) 12.2 lbs (5.5 kgs)

Dimensions 16x22x1.75 in (44.6x55.8x2.5 cm)

Warranty 12 months

Certifications FCC and CE

Optimal Operating Temp. 32-104ºF (0-40ºC)

Optimal Storage Temp. 32-86ºF (0-30ºC)

Solar panel Rated wattage: 30W

Cell type: mono-crystalline

Open-circuit voltage: 18-20V

Converting eff.: 17-18%

Charges the following: Approx. charge time:

ESCAPE 150 6-8 hours

EXTREME 350 12-24 hours

Smart phone, GPS 2-4 hours

SOLAR PANEL

Support legs

Metal support legs prop out for ideal positioning.

Power

a. The power plug stores easily around the cable tray. When

using, plug it into the input on you GOAL ZERO power pack.

b. The blue light turns on when power is being received into

the solar panel.

Clean

Wipe it clean with a dry or slightly damp cloth.

Security

Built in locking system secures panel when shut. To open it, push out

on both slide-tabs at the same time.

Technical Specs

BRACE IT

SEE IT

Back legs help with optimum sun

positioning.

The charging light turns on when it is

receiving power.

STORE IT

Panels fold into an easy to carry case with a

comfort grip handle.

POWER IT

Highly efficient monocrystalline solar cells

deliver up to 30 Watts.

SOLAR PANEL

Output Ports

Frequently Asked Questions

Compatible With

Is the ESCAPE 30 waterproof?

Yes, just remember that the devices you are powering might not be.

Does the ESCAPE 30 always deliver 30 Watts?

It can deliver up to 30 watts of power depending on shade, and positioning in the sun.

The ESCAPE 30 will not work indoors.

What kind of solar cells does the ESCAPE 30 use?

Monocrystalline solar cells. It provides more power per square inch than any other available technology.

Can I chain multiple ESCAPE 30 panels together?

Yes. With the use of a GOAL ZERO adapter cord you can charge your power packs faster

with multiple ESCAPE 30 panels.

Toll Free: 888.794.6250

14864 Pony Express Road

Bluffdale, UT, 84065

WWW.GOALZERO.COM

We proudly support Tifie Humanitarian

WWW.TIFIE.ORG

USER GUIDE

GOAL ZERO products:

All GOAL ZERO power packs, but recommended

for use with the ESCAPE 150 or EXTREME 350

SOLAR PANEL

• Fill out your warranty

• Watch demo video

• Download this manual
