Goclever TAB R76.2 Manuale utente
TAB R76.2
OWNER’S MANUAL
TAB R76.2
MANUALE UTENTE
VISITA IL NS WEBSITE
WWW.GOCLEVER.COM
TABLET, SMARTPHONE, NAVIGATORI, DVR, DVB-T
Prima di utilizzare il dispositivo, leggere il presente manuale
e salvarlo per il futuro
2
Contents / Contenuto
English
3
Italiano
11
Garanzia
20
3
Introduction
Thank you for your trust and your decision to buy our product!
As we constantly update and improve our device, there may be small differences between
the printed manual and your pad in some cases.
This user manual contains important safety instructions and information for proper
use of the device. Please follow the instructions in this manual carefully.
1. Please keep the device away from places with high temperatures, high humidity or
dust.
2. In particular please avoid leaving the device in the car during summer if the doors are
closed.
3. Avoid shocks and do not let the device fall, as otherwise it may cause damage to the
device.
4. The Standby Time of the batteries may vary due to different environmental influences.
5. We are not responsible for data losses that are caused by damage to the product,
repairs or any other reasons.
6. Do not open the housing of the device. Doing this will void your warranty claims.
7. Do not use alcohol, thinners or petrol to clean the display – use only a dry cloth.
4
Device Overview
1. Reset
7. Power button
2. miniHDMI
8. Volume -
3. microSD slot
9. Volume +
4. DC-in 5V
10. Speaker
5. microUSB
6. Audio out
Description of the buttons
Volume Buttons:
Here you can increase or reduce the volume.
Power Button:
Press the button for two seconds to switch on or switch off
the device. Press the button briefly to activate or end the Standby-Mode. Reset: Press the
button for seven seconds to restart the device.
5
Power Monitoring and Charging the Batteries
The battery charge symbol in on the status bar indicates the charging status of the batteries.
If the power goes down, the device shuts itself off automatically. If less power is shown,
use the power adapter to charge the device.
The charging time for the battery is approximately four hours.
Screen Lock
If the device is not used for specified time or the ‘Power’ button is pressed briefly, the screen
is switched off and display lock is activated.
By pressing the ‘Power’ button briefly the screen will be reactivated. For locking the screen
press the ‘Lock’ button in the specified direction.
Language Settings
English is a default language. To change the language setting, please do the following:
Applications Icon Settings Icon
Press on the applications icon on the right side of the screen.
Select ‘Settings’.
Scroll to the end of the list.
Select ‘Language & keyboard’.
Select ‘Select language’.
Type your preferred language.
Press the ‘Home’ button to return to the home screen.
6
Connecting to the Computer and Data Transfer
The device is equipped with a High-Speed USB2.0 interface. After you connect the device to
a computer, it appears in the status display. Pull the status bar down and press ‘USB
Connection’ to activate the USB Memory. When using the device for data transfer, you
cannot access to the internal flash and the microSD on your device.
Functions of the Buttons on the User Interface
Icon
Definition
Icon
Definition
Google search
Applications list
Back
Navigate between different
desktops
Back to the start screen
Wi-Fi signal
System current time
Mass storage status
Applications List
ApkInstaller. Program for installing and uninstalling Apps that were not downloaded from
the Android Market.
Market. Load Apps (programs) from the Android Market. You can download and install
apps, games and other applications. Many are free.
Explorer. Open the Explorer to access Micro SD TF Cards, USB sticks and other storage
media. The Explorer is a practical manager for documents and all types of data.
7
Internet browser
Camera
E-mail. Program for retrieving, processing and sending e-mails.
G-mail. Program for retrieving, processing and sending e-mails through Google account.
Google Maps. Program for the display of maps or satellite images – Route planner.
Skype. Program to chat with other Skype users or to make telephone calls via Internet.
Twitter. Application for Microblogging – Facilitates the display of public diaries or create
a public diary of your own.
Facebook. Program for using the social network site Facebook.
Calendar. Managing schedules – can be synchronized automatically with a Google
account.
Pocket Calculator
Time. Time display and setting alarm functions.
Settings. Changing the basic settings of the device.
Sound Recorder. Dictation Device Function.
Video Player
8
Gallery. Manage and display images and videos.
E-book. A program for reading and managing e-books.
System Settings
Wi-Fi
Click the main interface shortcut, select “Internet connection manager”, click “Wi-Fi settings”,
enter Wi-Fi setting interface and turn on the Wi-Fi switch (see the picture).
•The device will automatically scan for wireless networks
•Select your network
•Enter the password when prompted and connect to the network to get access to the
Internet
Data usage
Set data limit.
9
Sound
Set the volumes, system sounds
Display
Set the brightness, wallpaper, screensaver etc.
Storage
Show all storage and space of apps in internal memory/ SD card.
Battery
Show battery time.
Apps
Show all apps you installed.
Accounts & Sync
Sync your accounts you setup.
Location services
Determine your location by Intel.
Security
Set the screen security/Encryption/Passwords etc.
Language & Input
Set the language of device and input language you want.
Backup & reset
Recover factory data reset.
Date & Time
Set the date & time of device.
Accessibility
Set the font, auto-rotate etc.
Developer options
10
Show pointer location, screen updates, CPU usage etc.
About tablet
Show the model number, version etc.
USB Connections
You can connect your device to your computer, use it as a removable disk and open any files
saved on your device.
Browsing the Internet
Touch this icon to open the Internet browser. Google is the default start page.
Touch the input field to display the keyboard:
After entering a website address, touch this key to open the website.
